Page 1 ES1000 Series Installation Guide ES1000 Series Installation Guide...
Page 2 T T able of Contents able of Contents ES1000 ES1000 ....................................................1 1 Pr Preface eface ....................................................2 2 System Specifications System Specifications ........................................3 3 T T able of A able of Attributes ttributes ..........................................4 4 F F r r ont P ont Panels anels ........................
Page 3 Contact Information Contact Information ........................................40 ii ii...
Page 4 This reference document provides important legal disclaimers and notices for ES1000 products. Disclaimer Copyright © 2024 by Celestica. All Rights Reserved. "Celestica" refers to Celestica Inc. and its subsidiaries. For additional information, please visit our website at www.Celestica.com. All trademarks, trade names, service marks, and logos mentioned belong to their respective owners.
Page 5 Pr Preface eface Document Scope This installation guide details the design features of, and provides instructions for the ES1000enterprise access switch. Intended Audiences ▪ System architects ▪ Firmware engineers ▪ System application engineers Document Conventions The following table describes various types of notes used within this installation guide. T T ype Gener Generaliz...
Page 6 Introduction The ES1000 series comprises 1U, 19” enterprise access switches with 24 or 48 ports of 1GbE, optional PoE++ 803.3bt Type 4 Class 8, and 4 x 10/25GbE-SFP28 ports, MACsec, and high availability through multiple fans and redundant power supplies.
Page 7 T T able of A able of Attributes ttributes 1GbE 1GbE SKU ID SKU ID POE++ POE++ CPU type CPU type Memor Memory y SSD Airflow Airflow ports ts ES1000-24 int. ARM 32GB dual core 550W ES1000-24P 24 POE++ int. ARM 32GB dual core 920W...
Page 8 F F r r ont P ont Panels anels The front panel includes 24/48 network ports and multiple management ports. Figur Figure 1. e 1. F F r r ont panel - ES1000-24, ES1000-24P ont panel - ES1000-24, ES1000-24P Figur Figure 2.
Page 9 System Status LEDs System Status LEDs The ES1000 supports the following LEDs. System Status LEDs Four bi-colored LEDs on the front of the unit to indicate overall system status (FAN, PSU, ALM, SYS) RJ45 Network ports Each port supports two LEDs to indicate link, traffic, PoE status SFP 28 Uplink ports Each port supports two bi-colored LEDs to indicate link and traffic status...
Page 10 Figur Figure 4. e 4. ES1000-48/48P/48C/48CP F ES1000-48/48P/48C/48CP Fr r ont LEDs ont LEDs System LED Indicator Description...
Page 11 T T able of P able of Por orts ts SKU ID Port PoE SFP28 Combo Combo Console USB3.0 USB2.0 port RJ45 port port port ES1000-24 ES1000-24P 24 POE++ 4 ES1000-48 ES1000-48P 48 POE++ 4 ES1000-48C 48 ES1000-48CP48 POE++ 4 The USB port(s) do not provide power, only data transmission.
Page 12 P P or ort Descriptions t Descriptions P P or ort type t type SKU-ID SKU-ID Description Description Combo RJ45 ES1000-24 ▪ 10/100/1000Mbps auto negotiation ES1000-24P ▪ MDI/MDI-X cable mode auto negotiation ES1000-48 ▪ 1000Mbps auto negotiation ES1000-48P ES1000-48C ES1000-48CP Serial ES1000-24 ▪...
Page 13 P P or ort type t type SKU-ID SKU-ID Description Description RJ45 data ES1000-24 ▪ Port 1-24: 10/100/1000Mbps auto negotiation port ES1000-24P ▪ Port 1-24: 10/100/1000Mbps auto negotiation ▪ All ports support PoE Type 4 Class 8 ES1000-48 ▪ Port 1-48: 10/100/1000Mbps auto negotiation ES1000-48C ES1000-48P ▪...
Page 14 P P or ort LEDs t LEDs T T able 1. able 1.P P or ort Indicat t Indicator LEDs or LEDs Indicat Indicator or F F r r ont P ont Panel anel State State Description Description Sign Sign Power Green LED on 2 PSU are normal...
Page 15 Indicat Indicator LED or LED Description Description Management right side. Port 1. Use the left side dual color LED to indicate link status: a. Port link active in 1000M mode: Green On b. Port link active in 10/100M mode: Amber On c.
Page 16 Indicat Indicator LED or LED Description Description status: a. Port link active and there is traffic: Blink LED (Green or Amber per PoE State) b. Port PoE power Disabled: Green ON c. Port PoE power Enabled : Amber ON d. Port PoE power Denied: Alternate Blink Amber/Green for 1 minute then return to normal operation e.
Page 17 Rear P Rear Panel anel The rear panel of all ES1000 systems are identical and feature two hot-swappable AC/DC power supply units (PSUs) for redundancy, along with three fixed fans. Figur Figure 5. e 5. ES1000-24/24P and ES1000-48/48P/48C/48CP ES1000-24/24P and ES1000-48/48P/48C/48CP Figur Figure 6.
Page 18 Suppor Supported Cables ted Cables The ES1000 provides four (4) SFP28 ports and supports DAC (Direct Attach Cable) and Optical module. User can select the cables in the below table. T T able 2. able 2.Suppor Supported Cables ted Cables T T ype Manufactur Manufacturer er...
Page 19 PSU P PSU Power Options ower Options ES1000 supports redundant hot-swappable AC power supply units. The power supply support input voltage from 100V-240V. Multiple power supply wattage options are offered to match the desired Power Over Ethernet requirement of the end user. 1600W PSU 2x1600W PSUs are used in the ES1000-48P and the ES1000-48CP, supporting F2B and B2F airflow.
Page 20 PoE Description ES1000-24, ES1000-48 and ES1000-48C are non-PoE SKUs. ES1000-24P, ES1000-48P, and ES1000-48CP are PoE SKUs. These SKUs support PoE Type 4 Class 8. CAUTION: UTION: The PSU does not support 1+1 redundancy if the total system power demand   exceeds the power capacity of a single PSU .
Page 21 P P oE P P oE A oE Av v ailable ailable SKU ID SKU ID System System Note Note Reser Reserv v ed P P ower ower time 1 x 920W 200W 630W Up to 7 ports x 90W at the same time ES1000-48P 200W...
Page 22 PSU LEDs PSU LEDs T T able 5. able 5.PSU Indicat PSU Indicator LED Description or LED Description Rear Rear Indicat Indicator or P P anel anel State State Description Description Sign Sign 550W P-1/P-2 Green LED on PSU output ON and OK Amber LED on PSU failure or AC in power lost, but a...
Page 23 PSU Remo PSU Remov v al and Installation al and Installation Pr Procedur ocedure e 1 1 Disconnect the power cord. 2 2 Press the black tab next to the power receptacle to release the latch.
Page 24 3 3 Lift the handle, then pull straight out of chassis. 4 4 Reverse the steps to reinstall.
Page 25 Chassis Installation Chassis Installation ES1000 is designed to be installed in a standard 19'' square hole, four post rack. The bracket kit is only for 19 inch (483mm) wide, standard square hole racks, with a depth ranging from 22 inches ~ 33.5 inches (558mm ~ 850mm) as measured from rack post to rack post. This chapter covers the tools and procedures necessary to correctly and safely install the ES1000 enterprise access switch.
Page 26 Reduced Air Flow Reduced Air Flow Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised. Open Rack Mounting Open Rack Mounting Care should be taken to prevent the rack frame from obstructing the ventilation openings. Be sure to check the chassis positioning after installation to avoid overheating.
Page 27 NOTE: The following illustrations may display a different product. However, the installation   process is similar to other Celestica rack-mountable networking products. Pr Procedur ocedure e 1 1 Attach the two outer brackets with M4 screws provided in the accessory kit.
Page 28 Figur Figure 7. e 7. Secur Secure Br e Brack acket t et to Chassis o Chassis Figur Figure 8. e 8. Inner Rail Br Inner Rail Brack acket Installed t et Installed to Chassis o Chassis 4 4 Push the chassis with the outer bracket locked in step 1 above from the front side by one person, and push the inner bracket into the outer brackets (sleeve) slot on the chassis...
Page 29 from the rear side by another person at the same time, until guide pin (detail 1) and inner bracket guide pin (detail 3) fit in rack square holes. Then, lock them with M6 screws (PH#3 slotted screwdriver). 5 5 Press chassis and inner bracket until M6 screws fully lock. 6 6 Save enough space around the switch for good air circulation.
Page 30 Gr Ground L ound Lug Installation ug Installation Context Context The ground lug assembly (GLA) is used to safely and effectively ground the ES1000's chassis to the rack in which it is installed. This is an important task in the overall installation process of the enterprise access switch.
Page 31 2 2 Verify the part numbers as listed within image.
Page 32 CAUTION: UTION: The image shows the ground lug assembly and the grounding wire   terminal. The terminal must have a #10 AWG wire (not shown) crimped within it. The other end of the grounding wire must be securely attached to an unpainted metal surface on the rack.
Page 33 4 4 Remove both nuts and washers from grounding bracket.
Page 34 5 5 Attach the grounding wire terminal and reinstall the washers and nuts.
Page 35 6 6 Tighten both nuts to 4.5 inch/pounds (+/- 0.5 in/lb).
Page 36 7 7 The GLA installation process is complete.
Page 37 8 8 When crimping the 10AWG cable to the lug, remove 0.38" of shielding to expose the metal wire. Slide it into the lug and ensure metal-to-metal contact before crimping. The terminal must have a #10 AWG wire (not shown) crimped within it. CAUTION: UTION: ...
Page 38 UTION:   The Celestica ES1000 does not produce or have any laser-related functions. If you connect and install a device that supports laser functions such as an optical transceiver, we recommend that you choose a product certified to the relevant standards as shown below.
Page 39 P P ower ower Depending on the type of power system your device has, the following symbols may be used. On - On - Connects power to the system. This can be AC or DC power depending on product and model. Off - Off - Disconnects power to the system.
Page 40 NOTE:   This symbol is used when multiple power supplies are installed in a system. This warning label is typically found on the back of the device near the PSU. Power Connection Installation of this equipment must comply with local and regional electrical regulations governing the installation of information technology equipment by licensed electricians.
Page 41 Any modifications made to this device that are not approved by Celestica may void NOTE:  ...
Page 42 In accordance with European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), the presence of the above symbol on the product or on its packaging indicates that this item must not be disposed of in the normal unsorted municipal waste stream. Instead, it is the user's responsibility to dispose of this product by returning it to a collection point designated for the recycling of electrical and electronic equipment waste.
Page 43 Customers can register and request support (as well as search information in the knowledge base) at:https://customersupport.celestica.com/csm In case there are any questions or issues using the customer portal visit: https://www.celestica.com/contact-us. For immediate questions, please feel free to call your responsible account manager.
