ELECTRIC RETRACTABLE TRUCK BED COVER
NISSAN TITAN
INSTALLATION INSTRUCTIONS
TABLE OF CONTENTS
Tools Required for Assembly ............................ 2
Before You Start .............................................. 2
Drain Hole Locations ....................................... 2
STEP 1: Remove Contents from Box ............. 2
Packaging Contents ......................................... 3
STEP 2: Install Wiring Harness ....................... 3
STEP 3: Place Canister ................................... 3
STEP 4: Install Rails ........................................ 4
(800) 338-3697
STEP 5: Installing Clamps & Shims ................ 4-5
www.paceedwards.com
STEP 6: Lubricating the Sweep Seals ............. 6
STEP 7: Connecting the Electronics ............... 6
Pace Edwards Company
STEP 8: Installing Drain Tubes ........................ 6
2400 Commercial Blvd.
STEP 9: Install Top Cover ............................... 6
Centralia WA 98531
Operating the Release Handle ......................... 7
Helpful Maintenance Hints ............................... 7
BLN1-2302
Warranty Statement .......................................... 8
Advertisement
Table of Contents
Related Manuals for Leer Pace Edwards BEDLOCKER
Summary of Contents for Leer Pace Edwards BEDLOCKER
-
Page 1: Table Of Contents
ELECTRIC RETRACTABLE TRUCK BED COVER NISSAN TITAN INSTALLATION INSTRUCTIONS TABLE OF CONTENTS Tools Required for Assembly ......2 Before You Start ..........2 Drain Hole Locations ........2 STEP 1: Remove Contents from Box ..... 2 Packaging Contents ......... 3 STEP 2: Install Wiring Harness ....... -
Page 2: Tools Required For Assembly
TOOLS REQUIRED FOR ASSEMBLY: 7/16” wrench or socket #2 Phillips screwdriver 3/8” wrench or socket Side Cut Pliers Tape measure Note: There should be no drilling into the truck body needed on most standard or full-size trucks BEFORE YOU START: Read the instructions carefully before you start. -
Page 3: Packaging Contents
PACKAGING CONTENTS: Rails Rails Come in a (left & right) separate Box. Top Cover CAUTION! Complete Canister Assembly Drain DO NOT USE A KNIFE TO OPEN Tubes THE RAIL BOX. OPEN THE RAIL BOX ALONG THE LENGTH OF THE BOX AND LIFT RAILS OUT TO AVOID Clamp Pack... -
Page 4: Step 4: Install Rails
STEP 4: INSTALLING RAILS REMOVE PROTECTIVE PAPER UNDERSIDE RAILS. THIS PACKAGING PURPOSES ONLY. The machined end of the rail attaches to the canister. You will need to lift the hanging portion of the ribbed blanket and thread it in the rail while sliding the rail into the rail grip mounted to the ends of the canister (the underside of the blanket ribs Rail Grips... - Page 5 STEP 5: INSTALLING CLAMPS ON TRUCK WITH UTILI-TRACK CHANNEL SYSTEM HARDWARE USED: FIG. 5A RAIL TRUCK BED RAIL (1) CLAMP RAIL GRIP (8) ALLEN SCREWS (5, 6 & 7) CLAMP RAIL BOLT, LOCK & (1) CLAMP RAIL GRIP x 4 FLAT WASHER UTILI-TRACK CHANNEL SYSTEM...
- Page 6 STEP 5: INSTALLING CLAMPS ON TRUCK WITH OUT UTILI-TRACK CHANNEL SYSTEM HARDWARE USED: FIG. 5A RAIL TRUCK BED RAIL (1) CLAMP RAIL GRIP (8) ALLEN SCREWS (1) CLAMP RAIL GRIP x 4 (4, 5 & 6) CLAMP RAIL BOLT, LOCK & FLAT WASHER (2) CLAMP SHIM (3) CLAMP SPACER...
-
Page 7: Step 6: Lubricating The Sweep Seals
STEP 6: LUBRICATING & PLACING THE SWEEP SEALS Locate the sweep seals (rubber weather strips) on the rails. Use the provided UV protectant to wipe the underside of the sweep seal and RAIL SWEEP SEAL the top of the wear strip on each rail. The UV protectant can be found adhered to the underside of the top cover lid or in the hardware pack. -
Page 8: Release Handle Instructions
You have now completed the installation of the Bedlocker Electric hard tonneau cover. If you have any questions RELEASE HANDLE INSTRUCTIONS please do not hesitate to call us at: (800) 338-3697 and ask for our technical service department. If power is lost to the Bedlocker unit or the electric drive system fails to operate and you have to use the cover right away you can do the following to open or close the cover: RELEASE HANDLE 1. -
Page 9: Warranty
Address _______________________________________________________________________________________________________________________________ City ______________________________________________________________ State ______________________________ Zip _____________________________ Vehicle Year _____________________Make ______________________________________ Model______________________________________________________ Model Number _____________________________________________________ Serial Number ________________________________________________________ Email _____________________________________________________________ Phone _______________________________________________________________ Date of Purchase ______________________ Purchased From _______________________________________________ Price Paid _________________________ Customer Signature _____________________________________________________________________________________________________________________ ©2023 Pace Edwards by LEER®... - Page 10 2400 Commercial Blvd, Centralia, WA 98531 USA Thank you for choosing products by… (360) 736-9991 (360) 736-9992 (main) (fax) (800) 338-3697 (toll-free) www.paceedwards.com...
