USER MANUAL

HYBRID INVERTER

HEC1.5-T6Hr2 / T8Hr2 / T10Hr2 / T12Hr2 / T15Hr2

Table of Contents

Need help?

Do you have a question about the HICONICS HEC1.5-T6Hr2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea HICONICS HEC1.5-T6Hr2

Page 1 USER MANUAL HYBRID INVERTER HEC1.5-T6Hr2 / T8Hr2 / T10Hr2 / T12Hr2 / T15Hr2...
Page 2 User Manual STATEMENT HICONICS ECO-ENERGY DRIVE TECHNOLOGY CO., LTD. ( hereinafter"HICONICS" ) reserves the right to modify the frame dimensions, function- ality, technical data, parameters, standards without prior notice. The contents of this manual have been checked for accordance with its described hardware and software.
Page 3: Table Of Contents
User Manual CATALOG 1 Safe 1.1 Important Safety Instructions 1.2 Manual Description 1.3 Cautions 2 Introduction 2.1 Model Description 2.2 Basic Functions 2.3 Work Modes 2.4 Dimensions & Weight 2.5 Interface Deﬁnition 2.6 Product Performance 3 Installation Instructions 3.1 Installation Preparation 3.2 Installation 3.3 Electrical Connection 3.4 Cover installation...
Page 4: Safe
User Manual 1 Safe 1.1 Important Safety Instructions This section gives an explanation of all the symbols shown on the inverter and on the type label. Symbol Explanation CE mark. The inverter complies with the requirements of the applicable CE RCM remark SAA certiﬁcation Beware of hot surface. The inverter can become hot during operation. Avoid contact during operation.
Page 5: Manual Description
User Manual Disposal information can be found in the enclosed documentation. Do not operate inverter until it is isolated from battery, mains and on-site PV generation suppliers. Beware of hot surface. The inverter can become hot during operation. Avoid contact during operation.
Page 6: Cautions
User Manual 1.3 Cautions 1.3.1 Installation principles The inverter must only be installed by professional technicians. The professional technician is required to meet requirements as follows: Know electronic, electrical wiring and mechanical expertise, and be familiar with electrical and mechanical schematics. Be familiar with local standards and relevant safety regulations of electrical systems.
Page 7 User Manual Important Safety Instructions Danger to life due to a high voltage inside the inverter! All work must be performed by a qualiﬁed electrician. • DANGER Children and persons with reduced physical sensory abilities, mental • capabilities, or lack of experience and knowledge should not use this equipment unless supervised or instructed.
Page 8 User Manual Make sure the input DC voltage is less than the maximum value. Over- voltage may cause permanent damage to the inverter or other losses, WARNING which will not be covered by the warranty! Before attempting any maintenance, cleaning or working on any circuits connected to inverter, authorized service personnel must disconnect WARNING both AC and DC power from inverter.
Page 9 User Manual • Authorized service personnel must use insulated tools when installing or working with this equipment. • PV modules should have IEC 61730 Class A rating. • Do not touch either the positive or negative pole of PV connecting device.
Page 10 User Manual • Lightning will cause a damage either from a direct strike or from surges due to a nearby strike. • Induced surges are the most likely cause of lightning damage in majority or installations, especially in rural areas where electricity is usually provided by long overhead lines.
Page 11 User Manual • Spark gap devices are not suitable to be used in DC circuits once conducting, they won’t stop conducting until the voltage across their terminals is typically more than 30 volts. Anti-Islanding Effect The islanding effect is a special phenomenon where a grid-connected PV system still delivers power to the nearby grid when voltage losses occur in the power system.
Page 12: Introduction
User Manual 2 Introduction 2.1 Model Description The model description is as follows (take HEC1.5-T8Hr2 as an example): H E C 1 . 5 - T 8 H r 2 HEC1.5-T:HICONICS Generation1.5 T: Three phase 8: output power, 8kW H: battery high voltage r2: split system 2.2 Basic features HEC1.5-T Hybrid Series is a high performance inverter that converts solar energy to DC...
Page 13 User Manual E-Version applies to wiring rules that require the N (neutral) wire of the EPS to be disconnected from the N (neutral) wire of the grid (applicable to most countries). E-Version-system diagram Normal Loads PE BAR The grounding screw hole of inverter is at the lower right corner. Introduction...
Page 14 User Manual I-Version applies to wiring rules that require that the N (neutral) wire of other power sources must not be isolated or switched (applicable to Australian and New Zealand wiring rules AS/NZS_3000:2012). I-Versionsystem diagram N BAR Link Normal Loads PE BAR The grounding screw hole of inverter is at the lower right corner.
Page 15: Work Modes
User Manual • Please control the household load and make sure it is within the "EPS output rating" in EPS mode, otherwise the inverter will shut down and issue an "overload fault" warning. • Please check with the main grid operator for any special grid connection regulations.
Page 16 User Manual Solar energy provides power to the loads as GRID ﬁrst priority, if solar energy and battery are not sufﬁcient to power all connected loads, utility energy (Main Grid) will supply power to the loads with solar energy at the same time. When PV, Grid is available(without battery): Solar energy provides power to the loads GRID...
Page 17 User Manual Work mode: peak shift When PV, Grid, Battery is available: On charge time,solar energy will charge battery GRID as ﬁrst priority.The excess energy will supply power to the loads.If solar energy is sufﬁcient to supply loads and charge battery.and If there's still some extra energy.then the excess power will feed the power to grid.
Page 18 User Manual On charge time,grid will charge battery and GRID supply power to the connected loads at the same time. On discharge time,if load power is less than GRID battery power,battery will supply power to loads as ﬁrst priority.the excess power will be feed to grid.
Page 19: Dimensions & Weight
User Manual Grid will supply power to load and charge GRID battery at the same time. If the anti-reverse function is set to be allowable, the system will not feed power to grid in self-use, peak shift, battery priority modes. 2.4 Dimensions &...
Page 20 User Manual HEC1.5-T6/8/10/12/15Hr2 Mounting hole dia. Unit, mm HEC1.5-T6Hr2 T8Hr2 T10Hr2 T12Hr2 T15Hr2（Weight） Unit,（Weight） kg Introduction...
Page 21: Interface Definition
User Manual 2.5 Interface Deﬁnition Terminals PV String Input BAT Port COM1 PV1+ PV2+ COM2 PV1- PV2- BAT+ BAT- DRY10 DRY IO GRID BACKUP 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 BACKUP 2 UPDATE BMS Signal Line Interface...
Page 22 User Manual Terminals PV1+ PV string 1 positive input PV1- PV string 1 negative input PV2+ PV string 2 positive input PV2- PV string 2 negative input COM1 WIFI port 1 (optional) COM2 WIFI port 2 (optional) BAT+ Battery positive input BAT- Battery negative input UPDATE...
Page 23: Product Performance
User Manual Backup 1 Backup1 line A phase Backup1 line B phase Backup1 line C phase Backup1 line null line Backup1 line ground electrode Backup 2 Backup2 line A phase Backup2 line B phase Backup2 line C phase Backup2 line null line Backup2 line ground electrode 2.6 Product Performance Parameters...
Page 24 User Manual Battery Model T6Hr2 T8Hr2 T10Hr2 T12Hr2 T15Hr2 Battery type Lithium and Lead Acid Battery Battery voltage range 125V ~ 600 V Max. charging current / Max. discharging 50 A / 50A current Rated. charging current / Rated. 40A/40A discharging current AC output Model...
Page 25 User Manual Backup output Model T6Hr2 T8Hr2 T10Hr2 T12Hr2 T15Hr2 Nominal output voltage 3W+N+PE, 220 / 380 V; 230 / 400 V; 240 / 415 V Rated output frequency 50 Hz / 60 Hz Rated active power 6kVA 8kVA 10kVA 12kVA 15kVA Max.
Page 26 User Manual General data Model T6Hr2 T8Hr2 T10Hr2 T12Hr2 T15Hr2 Power factor at rated power / adjustable 0.99 / 0.8 leading to 0.8 lagging displacement Dimensions (W / H / D) 530 / 560 / 220 mm Installation Wall-mounted Operating temperature range -25 °C~+60 °C Noise emissions (typical) <...
Page 27: Installation Instructions
User Manual 3 Installation Instructions 3.1 Installation Preparation Please install the Product in strict accordance with steps in the Manual; otherwise, Hiconics does not bear any legal liability due to improper assembly and operation. 3.1.1 Environmental Conditions HEC1.5-T Series inverter is designed for outdoor installation (IP 65). Please ensure that the installation location meets the following conditions: •...
Page 28 User Manual No direct sunlight No rain exposure No snow accumulation Direct sunlight Snow accumulation Rain exposure Space requirement FRONT BOTTOM Directions BOTTOM LEFT RIGHT FRONT Min. size (mm) 3.1.2 Unpack Make sure that the inverter is intact during shipment. If there is any visible damage, such as cracks, please contact your dealer immediately.
Page 29 User Manual Terminal blocks, RJ45 crimping pliers, screwdrivers, hand wrenches and drills, etc. 3.1.4 Check Accessories Open the package and take out the product, please check the accessories ﬁrst. The package list is shown below. USER MANUAL Parts list No. Description Description Inverter WIFI module (optional)
Page 30: Installation
User Manual 3.2. Installation 3.2.1 Structure Installation Step 1: Mounting the wall bracket on the wall Place the bracket on the wall, mark the location of the four holes and then remove it. Drill holes with an drill, making sure they are deep enough (at least 60mm) to support the inverter.
Page 31 User Manual 3.2.2 Inverter installation Step 1: Place the inverter on the wall-mounted bracket by holding the handle on the side. Step 2: Tighten the ﬁxing screws on both sides of the inverter. Step 3: If necessary, an anti-theft lock can be installed on the lower left side of the inverter.
Page 32: Electrical Connection
User Manual 3.3 Electrical Connection 3.3.1 PV connection HEC1.5-T series Hybrid can be connected in series with 2-strings PV modules for 6KW, 8KW,10KW,15KW Select PV modules with excellent function and reliable quality. The open circuit voltage of module arrays connected in series should be less than Max. DC input voltage. Operating voltage should be in accordance with MPPT voltage range.
Page 33 User Manual The following PV connection mode is NOT allowed! PV array Inverter Connection steps: Step 1 : Inspect PV modules Measure the module array voltage with a voltmeter. Check the PV+ and PV- from the PV string combiner box correctly. Please make sure the impedance between the positive pole and negative pole of PV to ground should be MΩ...
Page 34: Grid Connection
User Manual 10mm 12AWG Crimp! 10mm 12AWG Step 4 : Insert the pin contact through the nut and into the male or female plug, when a "click" is felt or heard, the pin contact assembly is properly seated. Then tighten the nut. Insert Step5 : Plug the PV connector into the corresponding interface on the inverter.
Page 35 User Manual should be connected directly to the inverter. Connection steps: Step 1 : Check the grid voltage Check the grid voltage and compare it with the allowed voltage range (Refer to technical data). Disconnect the board from all phases and ensure that it is not reconnected. Step 2: Remove the waterproof lid from the grid port on the inverter.
Page 36 User Manual 10mm Insert & Crimp 3.3.3 EPS Connection (apply to I Version and E Version only) The HEC1.5-T series hybrid inverters have both off-grid and on-grid functions. The inverters output power through the AC port when the grid is on and through the EPS port when the grid is off.
Page 37 User Manual Auto & Manual For the "E version" inverters, the EPS function can be triggered automatically or manually, depending on the user's preference. For the "I version" inverter, the EPS function can only be triggered automatically. If the user wants to use this function manually, an external switch needs to be installed.
Page 38 User Manual E-Version-system diagram Normal Loads PE BAR The grounding screw hole of inverter is at the lower right corner. Installation Instructions...
Page 39 User Manual I-Version system diagram N BAR Link Normal Loads PE BAR The grounding screw hole of inverter is at the lower right corner. If you have a request for a compatible contactor, please contact our sales. Installation Instructions...
Page 40 User Manual If local policies dictate a wiring pattern that is inconsistent with the above operating guidelines, especially for N (neutral) wire, earth and RCD, please contact us before operating! This wiring diagram is for reference only and complete electrical connections should be made in accordance with local regulations.
Page 41 User Manual Disassemble the waterproof connector and waterproof cover and thread the cable through the waterproof connector. Step 2 : Insert the terminals into the EPS port of the inverter (loosen or tighten the crimp terminal screws with a one-way screwdriver). 10mm Insert &...
Page 42 User Manual Requirements for EPS loads Make sure the rated load power of the EPS is within its rated output range, WARNING otherwise the inverter will shut down with an "overload" warning. When an "overload" occurs, adjust the load power to ensure it is within the EPS output power range before turning on the inverter.
Page 43: Battery Connection
User Manual For example: Power Equipment Start Rated 100VA (W) 100VA (W) Incandescent lamp : 100W 80VA (W) 60VA (W) Fluorescent lamp: 40W 450~750VA (W) 300VA (W) Fridge: 150W 3.3.4 Battery Connection The charge/discharge system of HEC1.5-T series hybrid inverters is designed for high voltage lithium batteries.
Page 44 User Manual Battery connection diagram Battery connection BATTERY BMS PIN Deﬁnation The communication interface between the inverter and the battery is RJ45, and its protocol is CAN. BMS PIN deﬁnition RS485 × × × × × BMS_485A BMS_485B × × ×...
Page 45 User Manual The battery communication can only work when the battery BMS is compatible with the inverter. Battery connection steps: Step 1: Select the 10mm wire and remove 15mm of insulation from the end of wire. Step 2: Thread the end of the wire into the tubular terminal and use crimping pliers to crimp it tightly.
Page 46 User Manual 3.3.5 CT Connection and Phase instruction CT is used for monitoring the power usage for entire house, at the meantime, inverter will also need the data from Meter to achieve the Export Control Function. CT connection and phase wiring diagram Grid GRID Arrow...
Page 47 User Manual CT connection steps: Step 1: Disassembly of waterproof connector and waterproof cover. Step 2: Prepare a communication cable (without sheath) and pass the cable through the waterproof connector. Step 3: Insert RJ45 end of the CT cable into the CT port of the inverter. Step 4: Assemble waterproof connectors and waterproof cover.
Page 48 User Manual 3.3.6 Meter installation (optional) If you do not want to use a CT and wish to install a meter, we recommend installing a slide-in type. As shown in the picture below. 3.3.7 DRM Connection (Function temporarily retained) The DRM supports several demand response modes by transmitting control signals as shown below.
Page 49 User Manual DRM PIN deﬁnition Deﬁnition DRM1/5 DRM2/6 DRM3/7 DRM4/8 DRM0 DRM connection steps: Please refer to CT steps for DRM connection. Please kindly note that the deﬁnition of PIN and the location of the port will be slightly different. Seal The seal is for waterprooﬁng.
Page 50: Wifi Connection
User Manual 3.3.8 WiFi Connection The inverter provides a WIFI port that allows data to be collected from the inverter and transmitted to a monitoring website via WIFI. WIFI connection diagram Battery WIFI port Wiﬁ adapter port WIFI connection steps: Step 1 Assemble WIFI Module to COM2port at the bottom of the inverter.
Page 51: Cover Installation
User Manual 3.4 Cover installation Assemble the trim cover to the inverter and bolt it in place as shown in the diagram below. 3.5 System Overview The ﬁgure below shows the effect of a typical system application of inverter. Most important Sub- important Generator Solar...
Page 52: Product Debugging
User Manual 4 Product Debugging 4.1 Electrical inspection and start-up Start inverter after checking all the following steps: Make sure the inverter is ﬁxed well on the wall. Make sure all DC wiring and AC wiring is complete. Make sure the meter/CT is well connected. Make sure the battery is well connected.
Page 53: Setting
User Manual If the light on the left is not blue, please check the following three items: • All the connections are correct. • All the external breakers are switched on. • The DC switch on the inverter is in the “ON” position. Step 2: If it is the ﬁrst time to start, please follow this procedure.
Page 54: Product Maintenance
User Manual 6 Product Maintenance The inverter should be opened, repaired or dismantled by workers or personnel authorized by manufacturer only. For any consequences or liabilities due to violation against the safety operation, design, production and equipment safety standard, we do not bear any legal responsibilities. 7 Product Discontinuation Move the inverter switch to the OFF position Disconnect the inverter from the PV, grid and battery breakers...
Page 55 User Manual • The cooling and natural airflow are minimized due to insufﬁcient ventilation and circulation • Installed in corrosive environment • Damage during transport • Unauthorized maintenance • External factors, including abnormal physical or electrical pressure (blackout surge, surge current, etc.) •...
Page 56 HICONICS ECO-ENERGY DRIVE TECHNOLOGY CO., LTD. Add: No.3 Boxing 2nd Road, E-Town, Daxing District, Beijing, China, 100176 Tel: +86 10 5918 0033 Fax: +86 10 5918 0035 Email: huchu@midea.com...

This manual is also suitable for:

Hiconics hec1.5-t8hr2 Hiconics hec1.5-t10hr2 Hiconics hec1.5-t12hr2 Hiconics hec1.5-t15hr2
