CONTENTS
1. TECHNICAL CHANGE················································································OC185A- 1
2. FEATURES ··································································································OC185A- 2
3. PART NAME AND FUNCTIONS ·································································OC185A- 3
4. SPECIFICATIONS ·······················································································OC185A- 4
5. DATA············································································································OC185A- 5
6. OUTLINES AND DIMENSIONS ··································································OC185A-12
7. REFRIGERANT SYSTEM DIAGRAM ·························································OC185A-14
8. WIRING DIAGRAM······················································································OC185A-15
9. OPERATION FLOW-CHART·······································································OC185A-16
10. MICROPROCESSOR CONTROL ·······························································OC185A-19
11. TROUBLESHOOTING ·················································································OC185A-28
12. DISASSEMBLY PROCEDURE····································································OC185A-31
13. PARTS LIST·································································································OC185A-34
1
1
1
1
OC185A-1
