- Page 1 The Classic User Manual...
- Page 2 Meet Mycle. Your New Best Mate. Equipped with motor-powered assistance, the Mycle Classic brings a boost to every journey. To get the most out of your bike – and ensure you’re using it safely and correctly – make sure you read this manual before you get out on the road.
-
Page 3: Table Of Contents
Contents General Safety Meet Your Mycle 10-11 Quick Set-Up 12-13 Power Assist 14-15 On Board Display 16-17 Charging The Battery 18-19 Charger Safety Precautions 20-21 Additional Comments Maintenance Warranty 24-25 Servicing Intervals How To's... - Page 4 If you experience any of the following, cease use immediately and contact Mycle support : • Your charger’s flexible power cord or output cable or any of the electrical cables on your bike is frayed, has broken insulation, or any other signs of damage •...
- Page 5 Mycle Support. Failure to do so may result in damage to the part or bike, serious injury to yourself or others, pose a fire risk and even cause death.
- Page 6 Mycle General Safety Always wear a helmet Watch the weather...
-
Page 7: General Safety
Mycle General Safety General Safety Your Mycle Classic has been built and tested in the UK by our trained Cytech bike technicians. However, before trying out your Classic, make sure you carry out the routine checks listed in the MAINTENANCE section of this manual. -
Page 8: Meet Your Mycle
Mycle Meet Your Mycle Meet Your Mycle... - Page 9 Mycle Meet Your Mycle Get started by understanding all the parts and components of Your Mycle Classic. Vehicle Saddle Seat/Battery Seat Clamp Rear Brake Hub Motor Rear Derailleur Handlebar Frame Fork Front Brake Crankset Handlebars Shift Lever Brake LCD Display...
-
Page 10: Quick Set-Up
Mycle Quick Set Up Quick Set-up Before you get out on the road, make sure your bike is correctly set up and aligned to your height. - Page 11 Mycle Quick Set Up Handlebar Release the lever Set the brakes and gears to a position that suits you Re-fix the lever Seatpost Open the lever to release the seatpost Set the height of your saddle Re-fix the lever...
-
Page 12: Power Assist
Mycle Power Assist Power Assist The Power Assist feature is what makes Mycle special. You can switch from fully manual to high speed assistance at the push of a button. Power Assist is initiated by the pedals and operated through the On Board Display. Simply pedalling the bike will create an additional level of power to increase your riding speed or help you tackle hills. - Page 13 Mycle Power Assist Level 0 fully manual for low speeds Level 1 & f lat riding for low speeds Level 2 & gentle slopes Level 3 for faster speeds & slopes for faster speeds Level 4 & uphills for high speeds Level 5 &...
-
Page 14: On Board Display
Mycle On Board Display On Board Display Everything you need to know about your bike appears on the On Board Display. It’s also equipped with a USB interface so you can charge your phone as you ride. Battery Front Light On... - Page 15 Mycle On Board Display Get Started Hold the Power button for two seconds to switch on and off. Use The Light Hold down the Level Up button for two seconds to switch on the front light. Hold down the Level Up button for two seconds to switch off the front light.
-
Page 16: Charging The Battery
Mycle Charging The Battery High Power Uniformly Balanced... - Page 17 Mycle Charging The Battery Your Mycle Classic’s innovative design means that the battery is hidden in the seat post. The battery can be charged both with the seat post connected to the bike, or by itself. The battery is delivered with a minimum charge. Before riding for the first time, you must fully charge it for at least 5 hours.
- Page 18 Mycle Charging The Battery Battery Battery Life Range The range can vary depending on; Battery performance will decline after prolonged • The level of assistance use. Depending on usage • The weight of the user patterns, the energy • The gradient of the road capacity can reduce by •...
-
Page 19: Charger Safety Precautions
Mycle Charging The Battery Charger Safety Precautions • Only use the charger supplied with this bike. • Avoid contact with water while charging the battery. If a plug becomes wet, dry thoroughly before use. • For indoor use, do not expose the battery charger to rain. -
Page 20: Additional Comments
The correct psi is on the side wall of the tyre. The Spokes Whilst your Mycle bike has been built and tested to the highest standard by Cytech certified technicians, it is important that your bike is serviced regularly, including the tightness of your spokes. - Page 21 Cracks, scratches and discoloration can indicate that a component has exceeded its service life and should be replaced. If in doubt, seek professional advice or contact Mycle.
-
Page 22: Maintenance
√ Check the condition of the battery cable and connection. If any wires are exposed, stop using the battery immediately and contact Mycle support √ You should still carry out a pre-ride check before every ride. You can find more details at www.mycle.co.uk/pre-ride-check... -
Page 23: Warranty
Warranty Your Mycle Classic comes with a 12 month warranty covering parts and labour (if returned to Mycle). Should you opt to have your bike worked on by an independent qualified bike repairer we will happily send you replacement parts subject to the terms of our warranty and with prior authorisation from us. -
Page 24: Servicing Intervals
You should still carry out a pre-ride check before every ride. You can find more details at www.mycle.co.uk/pre-ride-check Weekly (100-200 miles/ 160-320 km) Inspect... - Page 25 Monthly (250-750 miles/ 400-1200 km) Service Replace Inspect Check brake pad Clean and alignment, brake cable tension. lubricate drive Check bike is shifting train . properly, proper derailleur cable Check crank Replace brake tension. set and pedal and shift cables Check chain stretch.
-
Page 26: How To's
How To's To keep your e-bike in top condition, we've put together the following how to guides. If you are unsure, you should always seek advice from a reputable, qualified technician to make sure the tuning or fix is properly executed. - Page 27 Gears How to use your gears It might seem obvious, but using your gears effectively can make a massive difference to how your e-bikes perform up will and the pedaling effort required. Follow our top tips on using your gears: On the right-hand side of the handle bar you will find a gear shifter trigger and gear selection display integrated with the brake...
- Page 28 3- Using the limit screws 4- Using the trigger with 2- Using the gear shifter ‘H’ screw using a Philip’s large thumb panel on the press the trigger with the small thumb panel. Click screwdriver turn counter shifter click through until it through all the gears till it or clockwise to align the stops.
- Page 29 Display How to change the display unit Knowing how the caballing on your display unit is really helpful if you ever need to change your display or check your display connection. Find out how below: Tools you will need: --19mm socket or spanner -10mm socket or spanner...
- Page 30 Display 5. Following down from 6. Tie a 3ft length of string 4. Using a 3mm Hex key the display unit find the remove the controller to the disconnected cable cover box. 4 screws. 2 at correct connection inside and using a small zip tie, the top of the cover and 2 the controller box and secure it to the cable (be...
- Page 31 Display 10. Untie the string from old cable and remove zip tie. Reattach the string and add a new zip tie to the new cable end. Repeat steps 1-10 in reverse order. How to change your display from km to m Here's how to get into the setup screen where you can configure the bike parameters: •...
- Page 32 Brakes How to tune your brakes You should always check your brakes are in full working order before each ride and as part of weekly, monthly and 6 monthly servicing by a professional qualified technician. The rate of wear is quicker on a E bike to a manual bike due to motorized parts.
- Page 33 Brakes 4. Return to the break 6. Turning the piston 3. When turning the barrel adjuster counter clockwise leave to check the feel of adjuster be sure to not will draw the pads away the brake on every half turn the thread part of from the disc giving a later turn of the barrel adjuster.
- Page 34 Tools you will need: -5mm hex key. -Pliers. -15mm spanner or socket (front wheel) 19mm spanner or socket (rear wheel). -New pads which can be found at www.mycle.co.uk/collections/brake-pads - Very small flat head screwdriver or pick. - Disc brake cleaner. Brakes...
- Page 35 1. On the main calliper body you will find a rectangular opening where the disc spins through the pads. Within this opening you will find your brake pads. To do a quick pad level check you will first need to remove your wheel.
- Page 36 Brakes A health pad will look similar to the image right. The braking surface of the pad clearly sits proud of the backplate of the pad. 5. When inspecting your 7. You are now ready to replace or refit your brake pads. brake pads look for any Place the pads back into the caliper body with the eyelet damage to the pad surface...
- Page 37 Brakes 8. Fit your wheel back in being careful to line up the disc to fall in-between the pads. Tighten up the wheel nuts or quick release. “I have fitted new pads, but my wheel won't spin and making a rubbing noise!” For new pads.
- Page 38 Mycle Our Mission Moving People And Planet Forward...
- Page 39 Mycle Our Mission Our Mission The biggest change starts small, and we believe that a better planet isn’t a million miles away. Change is just on your doorstep – get out on your Mycle and go find it! Connected Cleaner Transport Communities We’re on a mission to challenge the health issues facing the world...
- Page 40 The Classic User Manual...
