Summary of Contents for digitalview SP6-133
- Page 1 Quick Start Guide SP6-133 with E Ink Spectra 6 13.3", EL133UF1...
-
Page 2: Function Description
Function Description l 13.3 Spectra 6 EPD l SP6-133 driver board Ø Show image Ø Initialize EPD and control display l Rendering tool and writing image tool Ø A. Color Rendering program Ø B. Write converted image file to SP6-133 board... -
Page 3: Connection Method
Connection method SP6-133 board +5VDC input via USB-C cable connected to the Computer... - Page 4 Render_Image Tool 1. Execute the 〝Color Rendering V1.00〞 program. 2. Choose Panel Size : 13.3＂: 1200x1600. 3. Add or Drag image to the program. 4. Choose｀Convert:Save Image＇...
- Page 5 Render_Image Tool 5. Save Rendered image to the folder.
- Page 6 Writing image to SP6-133 board 1. First connect the SP6-133 board to the EPD via USB and turn on the power 2. Execute Spectra 6_Image_Tool.exe 3. Click "connect＂. If the connection is successful, there will be a WF00KWR message on the Device.
- Page 7 Writing image to SP6-133 board 5. LoadImage(resolution: 1200x1600) 6. Select the Image storage location (13.3＂can store Image 01~05)
- Page 8 Writing image to SP6-133 board 7. Click "Write_Image"to write the Image file to the SP6-133 board and wait for the Process Bar to complete. 8. Aft er the writing is completed, click "Display_Image",and the EPD will display the Image xx...
- Page 9 www.digitalview.com...
