digitalview IE-2000 Instructions Manual

Image enhancer add-on board
Hide thumbs

Advertisement

Quick Links

Download this manual
IMAGE ENHANCER ADD-ON BOARD
CONTENTS
Page: 2. Introduction, How to Proceed, Usage Note, Disclaimer
3. System design - Diagram of a suggested system
4. Assembly notes - Important information about system elements
6. Connection & Operation - How to use the IE-2000
7. Connectors, pinouts & jumpers - Essential connection information
21.Warranty, Caution & Limitation of Liability, Trademarks
It is essential that these instructions are read and understood before connecting or
powering up the IE-2000
Specifications subject to change without notice
© Digital View Ltd - Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc)
FOR 120Hz PANEL
Model: IE-2000
Part number : 41756002X-3 or up
INSTRUCTIONS
1 of 22
Page

Advertisement

loading
Need help?

Need help?

Do you have a question about the IE-2000 and is the answer not in the manual?

Questions and answers

Related Manuals for digitalview IE-2000

Summary of Contents for digitalview IE-2000

  • Page 1: Table Of Contents

    It is essential that these instructions are read and understood before connecting or powering up the IE-2000 Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 1 of 22 Page...
  • Page 2 The IE-2000 is a Digital View add-on board providing:  10 bit panel support and 120Hz panel support. The IE-2000 is currently matching with Digital View SVX-4096 controller to provide support for:  Displays up to 4096x2160, 10 bit, 120Hz.
  • Page 3 SYSTEM DESIGN A typical LCD based display system utilizing the IE-2000 is likely to comprise the following: Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 3 of 22 Page...
  • Page 4 Preparation: Before proceeding it is important to familiarize yourself with the parts making up the system and the various connectors, mounting holes and general layout of the IE-2000. As much as possible connectors have been labeled. Guides to connectors and mounting holes are shown in the following relevant sections.
  • Page 5  Servicing: The board is not user serviceable or repairable. Warranty does not cover user error in connecting up to the IE-2000 and is invalidated by unauthorized modification or repairs.  Board Mounting: It is recommended that a clearance of at least 10mm is provided above and 5mm below the board when mounted.
  • Page 6 Connection and usage is quite straight forward (it is useful to have the relevant connection diagram available at this time): 1. Connect the LCD panel & IE-2000 : Use the appropriate panel cable as indicated in the relevant Digital View Connection Diagram.
  • Page 7 External panel power input Molex 43045-0400 compatible (Matching connector type : Molex 43025-0400 compatible) (Matching power cable : P/N 426013710-3,1000mm) Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 7 of 22 Page...
  • Page 8 1-2 & 3-4 1-2 & 3-4 CLOSE OPEN OPEN CAUTION: Incorrect setting can damage panel & controller Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 8 of 22 Page...
  • Page 9 Byte length = 4 Reserved Reserved Tcon mode Pos #7 Pos #8 Description 1 division 2 divisions 4 divisions Reserved Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 9 of 22 Page...
  • Page 10 ON = "Low", OFF = 'High' Pin 28 Pin 24 Note: * The functions of pin are defined in the panel specification. Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 10 of 22 Page...
  • Page 11 Positive differential LVDS data bit A2 Ground LVDS_OUT1_AC- Negative LVDS clock for A channel LVDS_OUT1_AC+ Positive LVDS clock for A channel Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 11 of 22 Page...
  • Page 12 High/Low state control (15) High/Low state control (14) Ground (13) Ground (12) Ground (11) Ground (10) Ground No Connection Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 12 of 22 Page...
  • Page 13 J8_OUT – V-by-One panel signal output connector: JAE FI-RE41S-HF (Matching type : JAE FI-RE41HL) SYMBOL DESCRIPTION No connection No connection No connection No connection No connection No connection Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 13 of 22 Page...
  • Page 14 PP1 - 12V/24VDC power input: Molex 43045-0400 or compatible (Matching type : Molex 43025-0400 or compatible) DESCRIPTION +12VDC / 24VDC in Ground +12VDC / 24VDC in Ground Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 14 of 22 Page...
  • Page 15 PP6 – External panel power input: Molex 43045-0400 or compatible (Matching type : Molex 43025-0400 or compatible) DESCRIPTION External panel power Ground External panel power Ground Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 15 of 22 Page...

  • Page 16: Board Dimensions

    BOARD DIMENSIONS The maximum thickness of the IE-2000 is 20.65mm with or without video add-on board (measured from bottom of PCB to top of components, including any underside components & leads). We recommend clearances of:  5mm from bottom of PCB - if mounting on a metal plate we also recommend a layer of suitable insulation material is added to the mounting plate surface.

  • Page 17: Troubleshooting

     Incorrect jumper settings on the controller & IE-2000 may cause everything from total failure to incorrect image. CAUTION: Do not set the panel power input incorrectly.

  • Page 18: Specifications

     Re-layout and custom development services are available. Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 18 of 22 Page...

  • Page 19: Appendix I - Mapping Definition

    Appendix I – Mapping definition  Definition of VESA : Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 19 of 22 Page...
  • Page 20  Definition of JEIDA : Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 20 of 22 Page...
  • Page 21 TRADEMARKS The following are trademarks of Digital View Ltd:  Digital View  IE-2000 Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 21 of 22 Page...

  • Page 22: Contact Details

    52 Hung To Road Kwun Tong Hong Kong Tel: (852) 2861 3615 Fax: (852) 2520 2987 Sales: hksales@digitalview.com WEBSITE www.digitalview.com Specifications subject to change without notice © Digital View Ltd – Doc Ver 1.1: April 11, 2016 (IE-2000 manual.doc) 22 of 22 Page...
