digitalview IE-1000 Manual

Image enhancer add-on board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
Page: 2. Introduction, How to Proceed, Usage Note, Disclaimer
3. System design – Diagram of a suggested system
4. Assembly notes – Important information about system elements
6. Connection & Operation – How to use the IE-1000
8. Connectors, pinouts & jumpers – Essential connection information
13. Board dimensions
14. Troubleshooting
15. Specifications
16 Appendix I – Mapping definition
18. Warranty, Caution & Limitation of Liability, Trademarks
19. Contact details
It is essential that these instructions are read and understood before connecting or
powering up the IE-1000
Specifications subject to change without notice
© Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc)
IMAGE ENHANCER ADD-ON BOARD
FOR 120Hz PANEL
Model: IE-1000
Part number : 417190021-3 or up
[Firmware version : V1.80.00]
INSTRUCTIONS
1 of 19
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IE-1000 and is the answer not in the manual?

Questions and answers

Related Manuals for digitalview IE-1000

Summary of Contents for digitalview IE-1000

  • Page 1 It is essential that these instructions are read and understood before connecting or powering up the IE-1000 Specifications subject to change without notice 1 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...

  • Page 2: How To Proceed

    • 10 bit panel support and 120Hz panel support with motion compensation frame interpolation for smoother motion The IE-1000 can currently be matched with the Digital View SVH-1920 and upcoming SVX-1920 controllers to provide support for: • Displays up to 1920x1200, 10 bit, 120Hz.

  • Page 3: System Design

    SYSTEM DESIGN A typical LCD based display system utilizing the IE-1000 is likely to comprise the following: Summary: LCD panel Image Enhancer board, IE-1000 LCD controller card Interconnect LVDS cable (P/N 426497600-3, 200mm) Panel power cable (if required) Panel cable for LVDS panel...

  • Page 4: Assembly Notes

    Guides to connectors and mounting holes are shown in the following relevant sections. 1. LCD Panel: The IE-1000 is designed for driving 10 bits 120Hz up to 1920x1200 LVDS panels. Due to the variation between manufacturers of panels signal timing and other panel...
  • Page 5 Other system design issues that may affect safety or performance. IMPORTANT: Please read the Application Notes section for more information. Specifications subject to change without notice 5 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...

  • Page 6: Connection And Operation

    Connection and usage is quite straight forward (it is useful to have the relevant connection diagram available at this time): 1. Connect the LCD panel & IE-1000 : Use the appropriate panel cable as indicated in the relevant Digital View Connection Diagram.
  • Page 7 (LED2 GREEN, a box with yellow border appear in the CENTRE of the screen); Mode 4 = whole screen without smoothed motion (LED2 RED) IE-1000 will not memorize the demo mode after you turn off the IE-1000. It will resume back to mode 1 always.

  • Page 8: Connectors, Pinouts & Jumpers

    (Matching power cable : P/N 426013800-3, 160mm) PP2/PP3 Alternative power input DC power Molex 2 pin 0.156” pitch Specifications subject to change without notice 8 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...
  • Page 9 1920x1080 NEC NL192120AC25-02 1920x1200 For additional and recent added panels, see panel support table at http://www.digitalview.com/controllers/csg.php Specifications subject to change without notice 9 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...
  • Page 10 Panel power supply (+12V/18V) from front end controller VLCD_HV Panel power supply (+12V/18V) from front end controller Specifications subject to change without notice 10 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...
  • Page 11 Negative differential LVDS data bit B3 LVDS_OUT2_B4+ Positive differential LVDS data bit B4 LVDS_OUT2_B4- Negative differential LVDS data bit B4 Specifications subject to change without notice 11 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...
  • Page 12 +12V / +24VDC Ground PP2/PP3 – Alternate 12V/24VDC power supply DESCRIPTION +12VDC / 24VDC in Ground Specifications subject to change without notice 12 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...

  • Page 13: Board Dimensions

    BOARD DIMENSIONS The maximum thickness of the IE-1000 is 20.65mm with or without video add-on board (measured from bottom of PCB to top of components, including any underside components & leads). We recommend clearances of: • 5mm from bottom of PCB - if mounting on a metal plate we also recommend a layer of suitable insulation material is added to the mounting plate surface.

  • Page 14: Troubleshooting

    Incorrect jumper settings on the controller & IE-1000 may cause everything from total failure to incorrect image. CAUTION: Do not set the panel power input incorrectly.

  • Page 15: Specifications

    • Re-layout and custom development services are available. Specifications subject to change without notice 15 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...

  • Page 16: Appendix I - Mapping Definition

    Appendix I – Mapping definition • Definition of VESA : Specifications subject to change without notice 16 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...
  • Page 17 • Definition of JEIDA : Specifications subject to change without notice 17 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...

  • Page 18: Warranty

    TRADEMARKS The following are trademarks of Digital View Ltd: • Digital View • IE-1000 Specifications subject to change without notice 18 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...

  • Page 19: Contact Details

    Kwun Tong Hong Kong Tel: (852) 2861 3615 Fax: (852) 2520 2987 Sales: hksales@digitalview.com WEBSITE www.digitalview.com Specifications subject to change without notice 19 of 19 © Digital View Ltd – Doc Ver 1.4: 26 March, 2009 (IE-1000 -2X manual.doc) Page...
