Summary of Contents for Asus ROG Strix XG27WCS
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Asus ROG Strix XG27WCS o cerca il tuo prodotto tra le migliori offerte di Monitor...
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Notices ......................iv Safety information ..................vi Care & Cleaning ..................viii Takeback Services ..................ix Product information for EU energy label ..........ix Chapter 1: Product introduction Welcome! ..................1-1 Package contents ................. 1-1 Monitor introduction ..............1-2 1.3.1 Front/side view .............. -
Page 4: Notices
All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 10 and 30 minutes of user inactivity. -
Page 5: Canadian Department Of Communications Statement
NOTE: Energy Star is NOT supported on FreeDOS and Linux-based operating system. Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. -
Page 6: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. - Page 7 Prevent Tipping When using the display, fasten the LCD to a wall using a cord or chain that can support the weight of the monitor in order to prevent the monitor from falling. Cord M4 or M6 screw Cord or chain •...
-
Page 8: Care & Cleaning
This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury-containing button cell battery) should not be placed in municipal waste. Please check local regulations for disposal of electronic products. AEEE yönetmeliğine uygundur Care & Cleaning •... -
Page 9: Takeback Services
About Flicker https://www.asus.com/Microsite/display/eye_care_technology/ Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. -
Page 11: Welcome
Welcome! Thank you for purchasing the ROG gaming monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual... -
Page 12: Monitor Introduction
Monitor introduction 1.3.1 Front/side view 5-way) button: • Turns on the OSD menu. Enacts the selected OSD menu item. • Increases/Decreases values or moves your selection up/down/left/ right. • Turns on the OSD menu when the monitor enters standby mode or displays the “NO SIGNAL“... -
Page 13: Back View
USB Type-C cable, which supports USB power delivery (depending on the signal source). The monitor is Super-Speed USB 3.2 Gen 1 compatible (5Gbps). The port offers 7.5W power delivery with output voltage of 5V/1.5A. ROG STRIX XG27WCS Series Gaming LCD Monitor... -
Page 14: Other Function(S)
Earphone jack. This port is only available when an HDMI/DisplayPort/USB Type-C cable is connected. AC-IN port. This port connects the power cord. Kensington lock slot. Control buttons. 1.3.3 Other Function(s) • Tripod socket atop 1/4-inch tripod socket on the monitor stand allows you to mount a camera, audio equipment or additional display. -
Page 15: Assembling The Monitor Arm/Base
We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. Base screw size: M6 x 15 mm. Cable management You can organize the cables with the help of the cable management hole. • Arranging the cables ROG STRIX XG27WCS Series Gaming LCD Monitor... -
Page 16: Adjusting The Monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. •... -
Page 17: Detaching The Arm (For Vesa Wall Mount)
• The VESA wall mount kit (100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 22.7kg (Screw size: M4 x 10 mm) ROG STRIX XG27WCS Series Gaming LCD Monitor... -
Page 18: Connecting The Cables
When these cables are connected, you can choose the desired signal from the Input Select item in the OSD menu. If you need to replace the power cord or the connection cable(s), please contact ASUS customer service. • To use the earphone: connect the audio cable to the monitor’s earphone jack. -
Page 19: Osd (On-Screen Display) Menu
) button up/down to change the settings of the selected function. To exit and save the OSD menu, press the button or move the ) left repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-3. ROG STRIX XG27WCS Series Gaming LCD Monitor... -
Page 20: Osd Function Introduction
3.1.2 OSD function introduction Gaming GameVisual Input Select ROG STRIX XG27WCS Racing Mode DisplayPort 2560x1440 60Hz Variable OD Gaming Variable Refresh Rate ELMB Setup Image GamePlus GameVisual Color Shadow Boost ASUS Display Widget Center Input Select MyFavorite Back Enter Exit Volume •... - Page 21 Color Temp., Contrast, ASCR, Saturation, Gamma Blue Light Filter. • Shadow Boost: Dark color enhancement adjusts monitor gamma curve to enrich the dark tones in an image, making dark scenes and objects much easier to be seen. ROG STRIX XG27WCS Series Gaming LCD Monitor...
- Page 22 This function is only available in Racing Mode, RTS/RPG Mode, FPS Mode, sRGB Mode, Night Vision or User Mode. • ASUS DisplayWidget Center: Displays a QR code for you to access the information about ASUS DisplayWidget Center. Image GameVisual Input Select...
- Page 23 Saturation: The adjusting range is from 0 to 100. • Six-axis Saturation: Adjusts the saturation for R, G, B, C, M, Y. • Gamma: Allows you to set the color mode to 1.8, 2.0, 2.2, 2.4 or 2.6. ROG STRIX XG27WCS Series Gaming LCD Monitor...
-
Page 24: Input Select
Input Select In this function, you can select your desired input source. GameVisual Input Select ROG STRIX XG27WCS Racing Mode DisplayPort 2560x1440 60Hz Auto Input Detection Gaming USB-C DisplayPort Image HDMI Color Input Select MyFavorite Back Enter Exit Volume •... -
Page 25: System Setup
DisplayPort Stream: Compatibility with graphic card. Select DisplayPort 1.2 or DisplayPort 1.4 by graphic card DP version. • Information: Shows the monitor information. • All Reset: Selecting “Yes” allows you to restore the default settings. ROG STRIX XG27WCS Series Gaming LCD Monitor... -
Page 26: Specifications Summary
3.2 Specifications summary Panel type TFT LCD Panel size 27”W (68.5 cm) wide screen Max. resolution 2560 x 1440 Pixel pitch 0.2331 mm x 0.2331 mm Brightness (Typ.) 400 cd/m Contrast ratio (Typ.) 3000:1 Viewing angle(H/V) CR>10 178˚/178˚ Display colors 16.7 M Response time 1ms (GTG) Color temperature selection... - Page 27 MEPS, TUV-Flicker Free, TUV-Low Blue Light, UkrSEPRO, ICES-3, CEC, PC Recycle, Ukraine Energy, KC ,PSB, VN MEPS, EnergyStar 8.0 *Specifications are subject to change without notice. **Measuring a screen brightness of 200 nits without audio/USB/Card reader connection. ROG STRIX XG27WCS Series Gaming LCD Monitor...
-
Page 28: Outline Dimensions
3.3 Outline dimensions 130.8 [5.15] 139.05 [5.47] 176 [6.93] 370.16 [14.57] 164.96 [6.49] 167.83 [6.61] 218.33 [8.6] 335.66 [13.22] Active Area 510.36 [20.09] 120 [4.72] 333.8 [13.14] 394.75 [15.54] 140.2 [5.52] 100 [3.94] 117 [4.61] 3-10 Chapter 3: General Instructions... -
Page 29: Troubleshooting (Faq)
• Turn off the monitor by disconnecting the power cord and then turn on the monitor. • Reactivate the HDR function on your device. ROG STRIX XG27WCS Series Gaming LCD Monitor 3-11... -
Page 30: Supported Operating Mode
3.5 Supported operating mode • • Native timings Native timings Resolution Frequency HDMI DisplayPort Refresh rate Refresh rate 640 x 480 60Hz 60Hz 640 x 480 67Hz 67Hz 640 x 480 72Hz 72Hz 640 x 480 75Hz 75Hz 720 x 400 70Hz 70Hz 720 x 480 60Hz... - Page 31 1920 x 1080 100Hz 100Hz 1920 x 1080 120Hz 120Hz 1920 x 1440 180Hz 180Hz 2560 x 1440 60Hz 60Hz 2560 x 1440 120Hz 2560 x 1440 165Hz 2560 x 1440 180Hz ROG STRIX XG27WCS Series Gaming LCD Monitor 3-13...
- Page 32 • • For 16:9 (24.5” Simulation) aspect control timings For 16:9 (24.5” Simulation) aspect control timings Resolution Frequency HDMI DisplayPort Refresh rate Refresh rate 640 x 480 60Hz 60Hz 640 x 480 67Hz 67Hz 640 x 480 72Hz 72Hz 640 x 480 75Hz 75Hz 720 x 400...
-
Page 33: Video Timing
1920 x 1080P 50Hz 50Hz 1920 x 1080P 59.94Hz 59.94Hz 1920 x 1080P 60Hz 60Hz 1920 x 1080P 100Hz 100Hz 1920 x 1080P 120Hz 120Hz 3840 x 2160p 50Hz 3840 x 2160p 60Hz ROG STRIX XG27WCS Series Gaming LCD Monitor 3-15... - Page 34 3-16 Chapter 3: General Instructions...
