Summary of Contents for Asus ROG STRIX XG27WCMS
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Notices ......................iv Safety information ..................vi Care & Cleaning ..................viii Takeback Services ..................ix Product information for EU energy label ..........ix Chapter 1: Product introduction Welcome! ..................1-1 Package contents ................. 1-1 Monitor introduction ..............1-2 1.3.1 Front/side view .............. -
Page 4: Notices
All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 10 and 30 minutes of user inactivity. -
Page 5: Canadian Department Of Communications Statement
NOTE: Energy Star is NOT supported on FreeDOS and Linux-based operating system. Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. -
Page 6: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. - Page 7 Prevent Tipping When using the display, fasten the monitor to a wall using a cord or chain that can support the weight of the monitor in order to prevent the monitor from falling. Cord or chain • Display design may differ from those illustrated. •...
-
Page 8: Care & Cleaning
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. -
Page 9: Takeback Services
About Flicker https://www.asus.com/Microsite/display/eye_care_technology/ Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. -
Page 11: Welcome
Welcome! Thank you for purchasing the ROG gaming monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual... -
Page 12: Monitor Introduction
Monitor introduction 1.3.1 Front/side view 5-way) button: • Turns on the OSD menu. Enacts the selected OSD menu item. • Increases/Decreases values or moves your selection up/down/left/ right. • Turns on the OSD menu when the monitor enters standby mode or displays the “NO SIGNAL“... -
Page 13: Back View
USB Type-C cable, which supports USB power delivery (depending on the signal source). The monitor is Super-Speed USB 3.2 Gen 1 compatible (5Gbps). The port offers 15W power delivery with output voltage of 5V/3A. ROG STRIX XG27WCMS Series Gaming LCD Monitor... -
Page 14: Other Function(S)
Earphone jack. This port is only available when an HDMI/DisplayPort/USB Type-C cable is connected. AC-IN port. This port connects the power cord. Kensington lock slot. Control buttons. 1.3.3 Other Function(s) • Tripod socket atop 1/4-inch tripod socket on the monitor stand allows you to mount a camera, audio equipment or additional display. -
Page 15: Assembling The Monitor Arm/Base
We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. Base screw size: M6 x 15 mm. Cable management You can organize the cables with the help of the cable management hole. • Arranging the cables ROG STRIX XG27WCMS Series Gaming LCD Monitor... -
Page 16: Adjusting The Monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. •... -
Page 17: Detaching The Arm (For Vesa Wall Mount)
• The VESA wall mount kit (100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 22.7kg (Screw size: M4 x 10 mm) ROG STRIX XG27WCMS Series Gaming LCD Monitor... -
Page 18: Connecting The Cables
When these cables are connected, you can choose the desired signal from the Input Select item in the OSD menu. If you need to replace the power cord or the connection cable(s), please contact ASUS customer service. • To use the earphone: connect the audio cable to the monitor’s earphone jack. -
Page 19: Osd (On-Screen Display) Menu
) button up/down to change the settings of the selected function. To exit and save the OSD menu, press the button or move the ) left repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-3. ROG STRIX XG27WCMS Series Gaming LCD Monitor... -
Page 20: Osd Function Introduction
3.1.2 OSD function introduction Gaming GameVisual Input Select ROG STRIX XG27WCMS Racing Mode DisplayPort 2560x1440 60Hz Overclocking Gaming Variable OD Variable Refresh Rate Image ELMB Setup GamePlus Color GameVisual Shadow Boost Input Select ASUS DisplayWidget Center MyFavorite Back Enter Exit Volume •... - Page 21 Night Vision: This is the best choice for dark scenery playing with GameVisual Video intelligence Technology. User Mode: More items are adjustable for color adjustments. • When this function is activated, the following function(s) are not available: HDR. ROG STRIX XG27WCMS Series Gaming LCD Monitor...
- Page 22 This function is only available in Scenery Mode, Racing Mode, Cinema Mode, RTS/RPG Mode, FPS Mode, Night Vision or User Mode. • ASUS DisplayWidget Center: Displays a QR code for you to access the information about ASUS DisplayWidget Center. Image...
- Page 23 Repeating look up and down (2) Slowly roll your eyes (3) Move your eyes diagonal. • High energy blue light may lead to eye strain and AMD (Age-Related Macular Degeneration). Blue light Filter reduces 70% (max.) harmful blue light to avoid CVS (Computer Vision Syndrome). ROG STRIX XG27WCMS Series Gaming LCD Monitor...
-
Page 24: Input Select
Color GameVisual Input Select ROG STRIX XG27WCMS Racing Mode DisplayPort 2560x1440 60Hz Display Color Space Gaming Color Temp. Saturation Image Six-axis Saturation Gamma Color Input Select MyFavorite Volume Back Enter Exit • Display Color Space: Selects the color space for the monitor color output. -
Page 25: System Setup
Volume (Earphone Out): The adjusting range is from 0 to 100. Mute: Toggles the monitor sound between on and off. • Power Indicator: Turns the power LED indicator on/off. • Power Key Lock: Enables or disables the power key. ROG STRIX XG27WCMS Series Gaming LCD Monitor... - Page 26 • Key Lock: To disable all function keys. Move and hold the (5-way) button downward for over 5 seconds to cancel the key lock function. • Power Setting: Standard Mode: Standard mode setting may result in higher power consumption. Power Saving Mode: Power saving mode may cause limited luminance performance.
-
Page 27: Specifications Summary
4.5 kg (without stand); 7.2 kg (Net); 9.8 kg (Gross) Multi-languages 23 languages (English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesian, Persian, Ukrainian, Vietnamese) ROG STRIX XG27WCMS Series Gaming LCD Monitor... - Page 28 Accessories Quick start guide, warranty card, power cord, DisplayPort cable (optional), HDMI cable (optional), USB Type-C cable (optional), ROG sticker, ROG pouch Compliance and standards CB, CE, CU, CCC, cTUVus, FCC, RCM, BSMI, VCCI, RoHS, WEEE, J-MOSS, ErP, PSE, CEL, Windows 10/11 WHQL, KCC, Korea MEPS, TUV-Flicker Free, TUV-Low Blue Light, UkrSEPRO, ICES-003, CEC, PC Recycle, Ukraine Energy, KC ,PSB, Vietnam MEPS,...
-
Page 29: Outline Dimensions
130.8 [5.15] 139.05 [5.47] 176 [6.93] 370.16 [14.57] 164.96 [6.49] 167.83 [6.61] 218.33 [8.6] 335.66 [13.22] Active Area 510.36 [20.09] 120 [4.72] 333.8 [13.14] 394.75 [15.54] 140.2 [5.52] 100 [3.94] 117 [4.61] ROG STRIX XG27WCMS Series Gaming LCD Monitor 3-11... -
Page 30: Troubleshooting (Faq)
3.4 Troubleshooting (FAQ) Problem Possible Solution Power LED is not ON • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. The power LED lights white and there is no •... -
Page 31: Supported Operating Mode
60Hz 60Hz 640 x 480 75Hz 75Hz 800 x 600 60Hz 60Hz 800 x 600 75Hz 75Hz 1024 x 768 60Hz 60Hz 1024 x 768 75Hz 75Hz 1280 x 1024 60Hz 60Hz ROG STRIX XG27WCMS Series Gaming LCD Monitor 3-13... - Page 32 Resolution Frequency HDMI DisplayPort Refresh rate Refresh rate 1280 x 960 60Hz 60Hz 1280 x 720 60Hz 60Hz 1600 x 1200 60Hz 60Hz 1920 x 1080 60Hz 60Hz 1920 x 1080 100Hz 100Hz 1920 x 1080 120Hz 120Hz 1280 x 960 240Hz 240Hz 1152 x 864...
-
Page 33: Video Timing
1280 x 720P 59.94Hz/60Hz 1920 x 1080P 24Hz 1920 x 1080P 25Hz 1920 x 1080P 30Hz 1920 x 1080P 50Hz 1920 x 1080P 60Hz 1920 x 1080P 100Hz 1920 x 1080P 119.88Hz/120Hz ROG STRIX XG27WCMS Series Gaming LCD Monitor 3-15... - Page 34 3-16 Chapter 3: General Instructions...
