- Page 1 Translated from original operating instructions manual PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Operating instructions September 2024 READ THE USER OPERATING GUIDE CAREFULLY BEFORE USE...
-
Page 3: Table Of Contents
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C TABLE OF CONTENTS 1. INTRODUCTION ........................5 2. GENERAL SAFETY RULES ....................6 2.1. INTENDED USAGE .......................... 2.2. SAFETY MEASURES ASSOCIATED WITH THE USE OF THE TOOL ......... 2.3. SAFETY MEASURES ASSOCIATED WITH BATTERY USE ............ - Page 4 10. WARRANTIES ........................28 10.1. GENERAL WARRANTIES ......................10.1.1. STATUTORY WARRANTY ......................10.1.2. PELLENC COMMERCIAL WARRANTY ................... 10.1.3. PAID AFTER-SALES SERVICE ...................... 11. STATEMENTS OF COMPLIANCE ..................31 11.1. "EU" DECLARATION OF CONFORMITY: POWER PACK M, M+, L & L+ ........
-
Page 5: Introduction
56_159267-C 1. INTRODUCTION Dear Customer, Thank you for purchasing your PELLENC Power Tool battery Power Pack M, M+, L, L+. Properly used and maintained, this equipment will give you years of satisfaction. Warning In accordance with product liability laws, we are not responsible for damage caused by our product if the product includes an accessory that is not from the manufacturer or is not approved by the manufacturer. -
Page 6: General Safety Rules
2.1. INTENDED USAGE • The PELLENC Power Tool battery Power Pack M, M+, L, L+ is designed to work with the Olivion or Power 48 shaker rake (SOLO or DUO heads). • The PELLENC Power Tool battery Power Pack M, M+, L, L+ must be operated from the ground or from a suitable platform that is completely stable and safe. -
Page 7: Safety Measures When Using The "Pellenc" Charger
• Battery alone: product that is classified as class 9, UN3480. 14. Use of a battery other than that provided by Pellenc SA is dangerous (risk of serious injury). If a different battery is used, Pellenc SA cannot be held responsible for any consequences. -
Page 8: Safety Signage
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 2.5. SAFETY SIGNAGE Power Pack M Power Pack M+ Power Pack L Power Pack L+ Do not expose to any source of Tool compliant with Moroccan water (rain, flooded fields, water standards. - Page 9 PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C This equipment must be used at a Independent Communications temperature of -5° to +35°C. Authority of South Africa The product complies with the strict radio interference standards set by ICASA at the approved frequency.
-
Page 10: Description And Technical Features
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 3. DESCRIPTION AND TECHNICAL FEATURES 3.1. DESCRIPTION OF THE BATTERY Gauge display Charge connector cap Charging connector Tool power connector ON/OFF switch Charger Charging connector Indicator light Power cord... -
Page 11: Technical Characteristics - Battery
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 3.2. TECHNICAL CHARACTERISTICS - BATTERY Equipment Power Pack M Power Pack M+ Power Pack L Power Pack L+ Nominal 43.2V 43.2V 43.2V 43.2V \battery voltage Type of battery 12 x 3 cells per pack 12 times 4 elements... -
Page 12: Start-Up
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 4. START-UP 4.1. PACKAGE CONTENTS Check that the package is delivered with: • 1 M, M+, L or L+ battery • 1 battery operating instructions manual • 1 CB5022HV (2.2A) charger •... - Page 13 PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Caution Before connecting the charger to the mains, check that your power system characteristics comply with the specifications given on the charger. See 3.3. Technical characteristics - Charger, page 11.
-
Page 14: Battery Display
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Fit the charging connector plug (4). 4.3. BATTERY DISPLAY The battery has a gauge display showing the remaining capacity it holds. The capacity is expressed as a percentage. • If the gauge display shows , the battery is fully charged. -
Page 15: Fitting The Battery On The Harness
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Turn the harness so that the battery (1) is in front of you. Unclip the top of the battery (1) by pressing simultaneously on the two upper hooks of the battery holder (2). -
Page 16: Connecting The Tool To The Battery
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Clip the top of the battery (3) onto the top hooks of the battery holder (2). Make sure the battery switch is in the "0" off position. Connect the tool to the battery. -
Page 17: Adjustment Of The Harness
4.8. ADJUSTMENT OF THE HARNESS Caution The adjustment of the harness ensures the working comfort of the user of the Power Pack M, M +, L, L+. It must be adjusted before each use of the tool. To protect your back, take the time to adjust your harness properly. - Page 18 PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Method 2: fitting the power cord on the bottom of the carrying harness Open the Velcro fastening on the chest strap of the harness. Fit the power cord. Close the Velcro fastening on the chest strap of the harness.
- Page 19 PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C Adjustment of the harness Slip the harness over your back. The adjustment straps must be relaxed so as not to interfere with the user's adjustment. Close the waist strap of the harness at hip level.
-
Page 20: Using The Tool
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 5. USING THE TOOL 5.1. SWITCHING ON THE BATTERY • Turn switch (1) to "1". 5.2. SWITCHING OFF THE BATTERY • Set switch (1) to "0" off position. -
Page 21: Maintenance
Daily maintenance of the machine is meant for daily use, before and after each working day. Important Have the battery serviced at least once a year by a PELLENC authorised distributor. Always store the charged and clean battery in a dry place. -
Page 22: Verification
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 6.2. VERIFICATION 6.2.1. VISUAL CHECK OF THE GENERAL CONDITION OF THE BATTERY • Visually check the general condition of the battery and its connections. 6.2.2. VISUAL CHECK OF THE GENERAL CONDITION OF THE CHARGER •... -
Page 23: Cleaning The Battery
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 6.3. CLEANING THE BATTERY Caution The battery must not be connected to the charger or the tool. Switch off the tool. See 5.2. Switching off the battery, page 20. -
Page 24: Incidents And Troubleshooting
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 7. INCIDENTS AND TROUBLESHOOTING Caution Never attempt to open or repair the battery pack or the charger 7.1. TABLE OF INCIDENTS AND BREAKDOWNS - TROUBLESHOOTING... - Page 25 PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C...
-
Page 26: Summary Of Charge Indicator And Beep Messages
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 7.2. SUMMARY OF CHARGE INDICATOR AND BEEP MESSAGES Normal messages Using the tool Battery charge level (0 to 99) fixed Battery empty, recharge immediately with 1 beep per minute... -
Page 27: Battery Replacement
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 7.3. BATTERY REPLACEMENT Important The battery must be replaced only by an approved distributor. 8. STORAGE AND TRANSPORT 8.1. BATTERY STORAGE CONDITIONS • Store the battery unit and its charging device in a place away from any heat, dust or dampness, and ensure that the switch is on the "0"... -
Page 28: Accessories And Consumables
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 9. ACCESSORIES AND CONSUMABLES 9.1. ACCESSORIES INCLUDED For a list of accessories included with the tool, see 4.1. Package contents, page 12. 9.2. OPTIONAL ACCESSORIES Name Reference 10.3 m extension cord 100994 10. -
Page 29: Pellenc Commercial Warranty
PELLENC products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products. -
Page 30: Paid After-Sales Service
Paid after-sales service also covers PELLENC original spare parts, excluding labour and outside the legal and commercial warranty period. In case of replacement of original PELLENC spare parts in the context of after-sales service, said latter are covered by a warranty of one year as from the installation date. -
Page 31: Statements Of Compliance
PELLENC POWER TOOL BATTERY POWER PACK M, M+, L, L+ 56_159267-C 11. STATEMENTS OF COMPLIANCE 11.1. "EU" DECLARATION OF CONFORMITY: POWER PACK M, M+, L & L+ MANUFACTURER / PERSON AUTHORISED TO COMPILE PELLENC THE TECHNICAL FILE ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) - Page 36 PELLENC Quartier Notre Dame - 84120 Pertuis (France)
