Akron Brass TUCKAWAY 3354 Installation, Operating And Maintenance Instructions

Electric monitor with u2

Advertisement

Quick Links

INSTALLATION, OPERATING, AND MAINTENANCE INSTRUCTIONS
The following is intended to provide the basic instructions for installation, operation and maintenance of the TuckAway electric
monitor, and to assist in attaining the best possible performance from the unit. Read and understand these operating instructions
before use.
TOOLS REQUIRED
• Utility Knife
• Medium Phillips screwdriver
• Small Phillips screwdriver
• Electrician's pliers (multipurpose, stripping and crimping)
PRODUCT RATINGS
Maximum Motor Current Draw:
12 volt versions
24 volt versions
Normal Operating Current: (Depending on operating conditions–pressure, flow, etc.)
12 volt versions
24 volt versions
Minimum Voltage: (Truck engine must be operating for proper voltage requirement.)
All 12 volt motors: 11.5 volts while operating
All 24 volt motors: 23 volts while operating
Maximum Flow: 1000 gpm (3800 lpm)
Maximum Pressure: 200 psi (14 bar)
PRODUCT WARNINGS
WARNING:
For fire fighting use only by trained fire fighters.
WARNING:
Charge the unit slowly. Rapid charging may cause a pressure surge that has the potential to cause an injury, or
damage the monitor.
WARNING:
DO NOT stow or deploy the TuckAway monitor while flowing. Pressing the stow or deploy buttons causes the
nozzle to move automatically and the water stream may cause damage to equipment or injury to personnel
could result.
WARNING:
Aim the unit in a safe direction before pumping water through it. (i.e. Away from power lines)
STYLE 3354 TUCKAWAY™ ELECTRIC MONITOR WITH U2
• Medium flat screwdriver
• Small flat screwdriver
15.0 amps each for elevation and rotation motors
3.0 amps for nozzle pattern motor
7.5 amps each for elevation and rotation motors
1.5 amps for nozzle pattern motor
3.0 to 10.0 amps each for elevation, rotation, and stow motors
0.7 amps for nozzle pattern motor
2 - 5 amps each for elevation and rotation motors
0.4 amps for nozzle pattern motor
/
inch hex head wrench
1
2
122608

Advertisement

loading
Need help?

Need help?

Do you have a question about the TUCKAWAY 3354 and is the answer not in the manual?

Questions and answers

Summary of Contents for Akron Brass TUCKAWAY 3354

  • Page 1 STYLE 3354 TUCKAWAY™ ELECTRIC MONITOR WITH U2 INSTALLATION, OPERATING, AND MAINTENANCE INSTRUCTIONS The following is intended to provide the basic instructions for installation, operation and maintenance of the TuckAway electric monitor, and to assist in attaining the best possible performance from the unit. Read and understand these operating instructions before use.
  • Page 2 WARNING: Although the logic circuit board includes a water-resistant coating, it is important to keep water out of the control and logic boxes. Prolonged exposure to water will cause damage. When the cover of the control or logic box is removed, check that the O-ring under the cover is intact and free of dirt and debris. WARNING: The TuckAway monitor uses current limiting for both the monitor and nozzle. Use only appropriate Akron Brass Company nozzles. WARNING: Do not use the electric controls when the override cranks are being used or are in position for use.
  • Page 3 OPERATING INSTRUCTIONS A. PANEL CONTROLLER OPERATION The panel controller is used to control the monitor and nozzle. 1. To deploy the monitor for use: Press the STOW/DEPLOY toggle switch up and hold for approximutely 2 seconds until the moniter begins to (stow) then release. 2. To stow the monitor after use: Press the STOW/DEPLOY toggle switch down and hold for approximutely 2 seconds until the moniter begins to (deploy) release. 3. To change the horizontal monitor position toward the right or left: Press the proper toggle switch toward “RIGHT” or “LEFT” respectively, as labeled on the controller, until the desired position is reached. 4. To change the vertical monitor nozzle position upward or downward: Press the proper toggle switch toward “RAISE” or “LOWER” respectively, as labeled on the controller, until the desired position is reached. 5. To change the nozzle pattern toward the straight stream or fog position: Press the proper toggle switch toward “STRAIGHT” or “FOG” respectively, as labeled on the controller, until the desired nozzle position is reached. B. EMERGENCY STOP DURING DEPLOY OR STOW If it is necessary to immediately stop the TuckAway monitor during the deploy or stow sequence, activate any switch on the control panel and the unit will stop moving. To complete the stow or deploy sequence after an emergency stop, activate and release the stow/deploy toggle switch. This will automatically continue the stow/deploy sequence. Be sure to completely deploy the monitor before flowing water.
  • Page 4: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS Your TuckAway monitor and nozzle should be inspected prior to and after each use to ensure it is in good operating condition. Periodically, an unanticipated incident may occur where the unit is misused in a manner that is inconsistent with standard operating practices. A partial list of potential misuses includes: • Operating above the maximum rated pressure or flow. • Prolonged exposure to temperatures above 130°F, or below -25°F. • Operating in a corrosive environment. • Having the TuckAway nozzle hit a fixed object during operation or transportation. • Other misuse that might be unique to your specific environment. Also, there are many “tell tale” signs that indicate repair is in order, such as: • Controls that are either inoperable or difficult to operate. • Excessive wear • Poor discharge performance • Water leaks. If any of the above situations are encountered, the TuckAway monitor should be taken out of service, repaired, and tested by a qualified technician before placing back in service.
  • Page 5 Figure 1 TOP VIEW -STOWED TOP VIEW - DEPLOYED 9-9/16 5/16-18 UNC-2B X 1/2 DEEP (TYP 4) 5.250 45° 45° 2-1/2 2-1/4 11-7/8 2-1/2 NH THREAD SCALE 0.625 GROOVE TO FIT SIZE 2-153 O-RING 5-1/2 3-1/8 Ø4-3/8 B.C. 3/8-16 UNC-2B THREAD TYP 4 ON 4.375 B.C.
  • Page 6: Side View

    Figure 2 SIDE VIEW - DEPLOYED FRONT VIEW - DEPLOYED 90° Upper 30° Limits Upper Limits 30° VERTICAL STOPS DETAIL 30° Stop Upper 90° Stop 90° Below Horizontal Stop 90° 45° Plug Stop 45° Plug Plug 90° Stop 45° ROTATION 90° ROTATION (Factory Set) SIDE VIEW...
  • Page 7 REvISED: 4/12 WARRANTY AND DISCLAIMER: We warrant Akron Brass products for a period of five (5) years after purchase against defects in materials or workmanship. Akron Brass will repair or replace product which fails to satisfy this warranty. Repair or replacement shall be at the discretion of Akron Brass. Products must be promptly returned to Akron Brass for warranty service.
