STYLE 3530 INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS
The following is intended to provide the basic instructions for installation, operating and maintenance of the Manual Elevated Moni-
tor. Read and understand these operating instructions before use.

PRODUCT RATINGS:

Maximum Flow:
Maximum Operating Pressure:
(at the nozzle inlet – see page 5
for approximate inlet flange pressures)

PRODUCT WARNINGS:

The reaction force when flowing at the maximum operating pressure and flow listed above is 380 pounds. The center of the waterway
is 10 feet, 15 feet, or 20 feet (depending on the model chosen) from the bottom of the inlet flange. Ensure these values plus an appro-
priate safety factor are used to determine a proper support structure (See the overturning moment chart on page 5.
WARNING:
INSUFFICIENT STRUCTURAL SUPPORT CAN LEAD TO A FAILURE, WHICH HAS POTENTIAL TO CAUSE SERIOUS
INJURY. THEREFORE, SUFFICIENT STRUCTURAL SUPPORT AT THE INLET FLANGE IS REQUIRED AND IS THE
RESPONSIBILITY OF THE OWNER. NO SUPPORT STRUCTURE IS TO BE ADDED DIRECTLY TO THE
MONITOR OR ROTATION GUIDE TUBE. (Contact Akron Brass Customer Service for assistance.)
WARNING:
When mounting the Manual Elevated monitor to the customer provided base structure always use Grade 8 flange
bolts. After installation protect these bolts from corroding by applying a suitable protective coating.
WARNING:
Charge the monitor slowly. Rapid charging may cause a pressure surge which has the potential to cause an injury
or damage the monitor.
WARNING:
Aim the monitor in a safe direction before pumping water through it.
WARNING:
DO NOT exceed the maximum pressure or flow ratings of the monitor. Exceeding these ratings has the potential to
cause serious injury and/or damage the monitor.
WARNING:
DO NOT install shutoffs on the outlet of the monitor. Shutoffs increase the potential for pressure surges due to
water hammer, which have the potential to cause injury or damage the monitor.
WARNING:
Drain the monitor after use to prevent "freeze damage".
MANUAL ELEVATED MONITOR
750 gpm (2850 lpm)
100 psi (700kpa)
120826

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STYLE 3530 and is the answer not in the manual?

Questions and answers

Summary of Contents for Akron Brass STYLE 3530

  • Page 1 INJURY. THEREFORE, SUFFICIENT STRUCTURAL SUPPORT AT THE INLET FLANGE IS REQUIRED AND IS THE RESPONSIBILITY OF THE OWNER. NO SUPPORT STRUCTURE IS TO BE ADDED DIRECTLY TO THE MONITOR OR ROTATION GUIDE TUBE. (Contact Akron Brass Customer Service for assistance.) WARNING: When mounting the Manual Elevated monitor to the customer provided base structure always use Grade 8 flange bolts.
  • Page 2 CAUTIONS: Your monitor and nozzle should be inspected prior to and after each use to ensure it is in good operating condition. Potentially, an unanticipated incident may occur where the unit is used in a manner that is inconsistent with standard operating practices.
  • Page 3 Step 11 - Align the bracket on the nozzle as shown on the assembly drawing. Ensure that this is a tight connection by using a suitable spanner wrench. Note: After final assembly and installation, the nozzle body must not rotate when the cables are activated to change the water stream pattern. NOTE: The nozzle pattern sleeve should rotate. Step 12 –...
  • Page 4 To change the nozzle Stream/Pattern function of the Manual Elevated Monitor: There is a cable that is attached to the pattern sleeve of the nozzle. Pulling on either side of this cable changes the nozzle pattern - Fog or Straight Stream. When standing behind the Manual Elevated Monitor i.e.
  • Page 5 Manual Elevated Moni- Manual Elevated Monitor O.T Moment at Recommended Maximum tor Height Weight Pressure (100 psi) and Flow (750 gpm) 10 Foot 270 lbs. 3,800 ft-lbs. 15 Foot 350 lbs. 5,700 ft-lbs. 20 Foot 425 lbs. 7,600 ft-lbs. APPROXIMATE PRESSURE REQUIRED AT THE INLET FLANGE TO THE MANUAL ELEVATED MONITOR TO ACHIEVE 100 PSI AT THE NOZZLE INLET.
  • Page 6 Figure 2 PHONE: 330.264.5678 or 800.228.1161 I FAX: 330.264.2944 or 800.531.7335 I akronbrass.com REvISED: 4/14 WARRANTY AND DISCLAIMER: We warrant Akron Brass products for a period of five (5) years after purchase against defects in materials or workmanship. Akron Brass will repair or replace product which fails to satisfy this warranty. Repair or replacement shall be at the discretion of Akron Brass. Products must be promptly returned to Akron Brass for warranty service. We will not be responsible for: wear and tear; any improper installation, use, maintenance or storage; negligence of the owner or user; repair or modification after delivery; damage; failure to follow our instructions or recommendations; or anything else beyond our control. WE MAKE NO WARRANTIES, EXPRESS OR IMPLIED, OTHER THAN THOSE INCLUDED IN THIS WARRANTY STATEMENT, AND WE DISCLAIM ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. Further, we will not be responsible for any consequential, incidental or indirect damages (including, but not limited to, any loss of profits) from any cause whatsoever. No person has authority to change this warranty. © Akron Brass Company. 2014 All rights reserved. No portion of this can be reproduced without the express written consent of Akron Brass Company. ISO 9001 REGISTERED COMPANY...
