- Page 1 Laser EGA Series 8559 Digital CO Meter Handheld Exhaust Gas Analyser Stock No: MAN8559 Rev: 1.00123 January 2023 © Tool Connection Ltd...
-
Page 2: Table Of Contents
11-15 QUICK START USER INTERFACE STATUS STATUS BAR STATUS BAR LAYOUT STATUS BAR MESSAGE AREA STATUS BAR ICONS STATUS BAR ICONS LEVEL STATUS BAR MENU OPTIONS STANDARD OPTIONS USING MENU MENU ITEMS MEASURING EXHAUST GASES 2 Laser EGA SERIES MANUAL... - Page 3 VIEWING STORED LOGS LOG VIEW MENU OPTIONS FINDING STORED REPORTS REPORT MENU OPTIONS PRINTING Laser INFRARED PRINTER PRINTOUTS Laser LINK SPECIFICATIONS EU DECLARATION SERVICE - CALIBRATE - RECERTIFY KANE ASSET MANAGER (KAM) 27-29 COLD WEATHER PRECAUTIONS Laser EGA SERIES MANUAL 3...
-
Page 4: Laser Ega Overview
“hands-free” operation and is supplied with an exhaust probe and battery charger with 3 NiMH batteries. Your Laser EGA has a large 6 line display showing data and test results based on your actions. The display bottom line also highlights analyser status at all times. -
Page 5: Analyser Features And Keypad
ANALYSER FEATURES AND KEYPAD Laser EGA SERIES MANUAL 5... -
Page 6: Keypad Buttons
Navigate down - Short press to scroll down Data hold - Short press to hold current data on screen (see status bar section) Pump toggle - long press to toggle the pump on and off Function keys Rotary dial 6 Laser EGA SERIES MANUAL... -
Page 7: Analyser Layout
• Menu • Status • Measure Water trap & particle filter Exhaust gas inlet Battery charger Exhaust gas inlet Watertrap drain with red plug Red connector - plugs into exhaust gas inlet Exhaust probe hose Laser EGA SERIES MANUAL 7... - Page 8 Magnets x2 Exhaust Probe Gas exhaust (see page 10) Watertrap drain with red plug Red connector - plugs into exhaust gas inlet 8 Laser EGA SERIES MANUAL...
-
Page 9: Batteries
After changing batteries reset your analyser time & date. CHARGING NiMH BATTERIES Your Laser EGA uses a standard Micro USB connector - For best results turn off then connect your charger. Charging indicator will illuminate then turn off when charging is complete. -
Page 10: General Safety
● Altitude to 2000m ● Ambient temperature 0°C-40°C ● Maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50%RH at 40°C ● Mains supply fluctuations not to exceed 10% of the nominal voltage 10 Laser EGA SERIES MANUAL... -
Page 11: First Time Use
GENERAL OPERATING PRINCIPLE Using your Laser EGA is simple with the rotary dial and user interface. Most tests can be made with little user activity. Your analyser status bar offers options based on tasks you are performing and displays useful information and messages. -
Page 12: Status
No. of days until next calibration due Serial number Status bar STATUS BAR Status bar shows analyser status and offers options based on your settings. Navigate through status bar options via & buttons when status bar is on display. Status bar 12 Laser EGA SERIES MANUAL... -
Page 13: Status Bar Layout
CALIBRATION DUE between calibration due WARNING MESSAGE and current time Display alternates air AIR PURGE purge delay symbol & “SNOOZE” TIMER Current time Display alternates LOW BATTERY between BAT symbol & WARNING MESSAGE Current time Laser EGA SERIES MANUAL 13... -
Page 14: Status Bar Icons
STATUS BAR ICON LEVEL ICON LIST Pump status indication PUMP (Running/Stopped) Indicates the analyser LOGGED DATA contains logged data Indicates data is being transmitted SENDING DATA to either the App or the Printer BATTERY Battery Status indication 14 Laser EGA SERIES MANUAL... -
Page 15: Status Bar Menu Options
As you navigate up or down items will move up or down the screen returningto the beginning. Note: To exit MENU turn your analyser rotary dial to any position - note any unsaved changes will be lost. Laser EGA SERIES MANUAL 15... -
Page 16: Menu Items
This unique feature provides future connectivity to a selection of peripheral devices currently under development, which will link wirelessly to your analyser, and utilise its display functionality. Once connected, they will remain connected unless specifically dis-connected. Keep in touch with Laser via www.lasertools.co.uk 16 Laser EGA SERIES MANUAL... -
Page 17: Measuring Exhaust Gases
● Do not put analyser on hot surfaces ● Do not exceed analyser water trap max levels ● Do not let analyser particle filter become dirty and blocked Check readings are stable and within expected range. Laser EGA SERIES MANUAL 17... -
Page 18: Co Sensor Protection Pump Operation
To edit a line, press until EDIT appears on the status bar. Press and hold to select EDIT. Cursor flashes and line number appears in status bar. Use select option to appear on line then press to enter option. 18 Laser EGA SERIES MANUAL... -
Page 19: Measure Screen
NOx reading (if fitted) Status bar STORED MEMORY REPORTS Your Laser EGA utilises a shared memory system which means stored logs are not limited by type. An icon displays when your analyser has stored data. To view current memory rotate dial to MENU then select LOGS to display. -
Page 20: Menu Options
Return to main menu VIEWING STORED REPORTS To view your reports, select VIEW option from LOGS Menu: List of available LOGS To navigate and select use & REPORT VIEW MENU OPTIONS View stored Tests Returns to previous menu 20 Laser EGA SERIES MANUAL... -
Page 21: Finding Stored Reports
Return to main menu INFRARED PRINTER The Laser 8559 is compatible with Infra-Red printer IRP3, which is available as an optional extra To use your printer, switch on and place the printer infrared receiver in line with the emitter on top of your analyser - allow a 15cm gap between analyser and printer. -
Page 22: Printouts
TRANSFER – for use with future peripheral devices You can wirelessly connect optional Laser LINK devices to your analyser. Rotate dial to Laser LINK on your analyser to manage how your analyser communicates with wireless devices. To ADD, REMOVE and check STATUS of optional Laser LINK devices (when available ) select LINK using &... -
Page 23: Specifications
Corrected Carbon Monoxide 0 - 21% 0.1% ±0.3% Volume Pre-programmed Emissions Battery Life >8 hours (continuous with pump on) Laser-EGA is independently tested and certified to EN50379, Certification Parts 1-3 Operating Conditions Temperatures 0 - 45°C Humidity 15 to 90% RH, (non-condensing) -
Page 24: Certificate Of Conformity
EMC Regulations 2016 EN50270:2015 RoHS – 2011/65/EU RoHS 2012 IEC62321-1:2013; IEC62321-2:2013; IEC62321-3-1:2013; IEC62321-4:2013; IEC62321-5:2013; IEC62321-6:2015; IEC62321-7-1:2015; IEC62321-7- 2:2017 LVD – 2014/35/EU Electrical Equipment EN61010-1:2010 (Safety) Regulations 2016 SIGNED: Mr Eddie Altham, Managing Director DATE: 1ST DEC 2022 24 Laser EGA SERIES MANUAL... - Page 25 SERVICE - CALIBRATION - UPGRADES Our International Service Partner for the Laser range of EGA’s, is : Kane International Ltd Kane House, 11 Bessemer Road Welwyn Garden City Hertfordshire AL7 1GF, t: 0800 059 0800 e: service@kane.co.uk From outside UK Call +44 1707 375550 Laser recommends that all gas analysers &...
-
Page 26: Kane Asset Manager (Kam)
& helps prevent industry colleagues unknowingly buying stolen goods • Remove your KANE Analyser once sold so its new owner can also benefit There are different KAM options & we'd be delighted to discuss your individual requirements Contact: support@kane.co.uk 26 Laser EGA SERIES MANUAL... - Page 27 Your support - our way Laser EGA SERIES MANUAL 27...
- Page 28 Book & pay to Service & Recertify via your KAM dashboard Select FREEPOST for tracked carriage - UK mainland only Your analyser will be despatched on the same day we receive it... OR YOUR MONEY BACK 28 Laser EGA SERIES MANUAL...
-
Page 29: Cold Weather Precautions
‘ON’ sampling fresh air for a few hours. Connect your mains adapter or battery charger to avoid draining batteries. If you still experience problems please contact Kane Customer Service. Laser EGA SERIES MANUAL 29... - Page 30 THIS PRODUCT CONFORMS WITH THE FOLLOWING PLEASE RECYCLE PACKAGING MADE IN THE UK 30 Laser EGA SERIES MANUAL...
- Page 31 Laser EGA SERIES MANUAL 31...
- Page 32 Or scan the QR code to go directly to register your product online on the KAM service dashboard Tool Connection Ltd Kineton Road Southam Warwickshire CV47 0DR, UK email:service@toolconnection.co.uk KAM telephone: 0800 059 0800 32 Laser EGA SERIES MANUAL...
