Cateye STEALTH 50 Quick Start Manual
  1. Manuals
  2. Brands
  3. Cateye Manuals
  4. Bicycle Accessories
  5. STEALTH 50
  6. Quick start manual
Cateye STEALTH 50 Quick Start Manual

Cateye STEALTH 50 Quick Start Manual

Cyclocomputer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CATEYE STEALTH 50
CC-GL50
Quick Start
PDF file
•
Opening a file may display a message related to
the format field on the screen. Click on the icon
in the message to close.
•
When you click on the movie screen, a message
regarding security appears. Click the "Trust in
the text" or "Play" button to close the message.
Click the screen again to play the movie.
START
Click the button and follow the
instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STEALTH 50 and is the answer not in the manual?

Questions and answers

Related Manuals for Cateye STEALTH 50

Summary of Contents for Cateye STEALTH 50

  • Page 1 CATEYE STEALTH 50 CC-GL50 Quick Start PDF file • Opening a file may display a message related to the format field on the screen. Click on the icon in the message to close. START • When you click on the movie screen, a message regarding security appears.
  • Page 2 Thank you for purchasing our cyclocomputer CATEYE STEALTH 50. This Quick Start Manual explains how to set up the computer and how to install the unit on your bicycle. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.

  • Page 3: Setting Up The Computer

    CATEYE STEALTH 50 Return to a Cover Quick Start Manual Contents Click on the item to view. Setting up the computer How to attach the bracket (movie format) Optional: How to mount the speed sensor (movie format) Optional: How to wear the heart rate sensor (movie format)

  • Page 4: Operation Of Buttons

    Operation of buttons Set up the computer by operating the buttons as follows. Check the button position before you start setting up. POWER MENU MODE Next...
  • Page 5 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Power ON Power ON Power ON Pressing and holding the button on the back of the computer for 2 seconds turns on the power, and the Formatting operation screen lights up.
  • Page 6 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Formatting operation Power ON Press the MENU button on the back of the computer and the AC button simultaneously. Formatting operation After all screen items light up, the display will be changed to the speed unit setting screen, and setup will start.
  • Page 7 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the speed unit Power ON When the MODE button is pressed, either “km/h” or “m/h (mile)” is selected for the speed unit display. Select the Formatting operation display of your choice.
  • Page 8 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing (Searching the sensor ID) Power ON When using the ANT+ sensor, it is necessary to perform pairing with the computer. When not using, pairing is not Formatting operation required.
  • Page 9 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer I do not have an ANT+ sensor Power ON Pairing is not required. Press the MENU button 5 times to jump to the next step “Setting the time zone”.

  • Page 10: Setting The Time Zone

    CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the time zone Power ON Power ON Select the code for the city nearest from your current lo- cation, while viewing the “Time zone list”. Formatting operation...

  • Page 11: Setting The Daylight Saving Time

    CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the daylight saving time Power ON Power ON Change ON/OFF according to the period of daylight sav- ing time, when you are on Daylight Saving Time.

  • Page 12: Setting The Clock Display Format

    CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the clock display format Power ON Power ON When the MODE button is pressed, either “12h” or “24h” is selected for the clock display format. Select the display...
  • Page 13 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Now, setup of the computer is completed. Power ON Power ON When the bracket is not attached to your bicycle, return Formatting operation Formatting operation to Contents, click on “How to attach the bracket (movie formant)”, and then attach it according to the instruc-...
  • Page 14 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the time zone City Time dif- -11:00 -10:00 -09:00 +08:00 -07:00 -06:00 -05:00 -04:00 -03:00 -02:00 -01:00 -00:00 +01:00 +02:00 +03:00 +04:00 +05:00 +06:00 +07:00 +08:00...
  • Page 15 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer I have an ANT+ sensor Power ON Power ON This unit has 2 different methods for pairing. Formatting operation Formatting operation Automatic search: The computer completes pairing by receiving the signal sent from the ANT+...
  • Page 16 Setting the daylight saving time When you perform pairing with “ISC:1” (Speed/cadence sensor), the dis- play of “CD:1” (Cadence sensor) is skipped. Setting the clock display format Select “ISC” to pair the CATEYE speed/cadence sensor (ISC-11). GPS search screen Return Next (Setup completed)
  • Page 17 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing: Automatic search (2/4) Power ON Power ON Pressing and holding the MODE button changes the value in the lower display, and then automatic search is started.
  • Page 18 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing: Automatic search (3/4) Power ON Power ON When the computer receives the ID signal from the sen- sor successfully, the ID number is displayed. Formatting operation...
  • Page 19 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing: Automatic search (4/4) Power ON Power ON When you use other sensors, perform pairing in the same procedure. Formatting operation Formatting operation Selecting the sensor To the...

  • Page 20: Entering The Tire Circumference

    CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Entering the tire circumference Power ON Power ON Enter the tire circumference (mm) of your bicycle with 4 digits in reference to the Tire circumference reference table.
  • Page 21 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the time zone Power ON Power ON Select the code for the city nearest from your current lo- cation, while viewing the “Time zone list”. Formatting operation...
  • Page 22 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the daylight saving time Power ON Power ON Change ON/OFF according to the period of daylight sav- ing time, when you are on Daylight Saving Time.
  • Page 23 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the clock display format Power ON Power ON When the MODE button is pressed, either “12h” or “24h” is selected for the clock display format. Select the display...
  • Page 24 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Now, setup of the computer is completed. Power ON Power ON When the bracket is not attached to your bicycle, return Formatting operation Formatting operation to Contents, click on “How to attach the bracket (movie formant)”, and then attach it according to the instruc-...

  • Page 25: Tire Circumference Reference Table

    CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Tire circumference reference table Generally, ETRTO or the tire size is indicated on the side of the tire. ETRTO Tire size L (mm) ETRTO Tire size L (mm)
  • Page 26 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the time zone City Time dif- -11:00 -10:00 -09:00 +08:00 -07:00 -06:00 -05:00 -04:00 -03:00 -02:00 -01:00 -00:00 +01:00 +02:00 +03:00 +04:00 +05:00 +06:00 +07:00 +08:00...
  • Page 27 When you perform pairing with “ISC:1” (Speed/cadence sensor), the dis- Setting the daylight saving time play of “CD:1” (Cadence sensor) is skipped. Select “ISC” to pair the CATEYE speed/cadence sensor (ISC-11). Setting the clock display format GPS search screen Return Next...
  • Page 28 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing: manual ID number entry (2/4) Power ON Power ON Press and hold the MODE button, and then press the MODE button within 3 seconds after the value in the low-...
  • Page 29 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing: manual ID number entry (3/4) Power ON Power ON Pressing the MODE button increases the value flashing, and pressing and holding the MODE button moves to the...
  • Page 30 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Pairing: manual ID number entry (4/4) Power ON Power ON When you use other sensors, perform pairing in the same procedure. Formatting operation Formatting operation Selecting the sensor...
  • Page 31 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Entering the tire circumference Power ON Enter the tire circumference (mm) of your bicycle with 5 digits in reference to the Tire circumference reference table. Formatting operation...
  • Page 32 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the time zone Power ON Select the code for the city nearest from your current lo- cation, while viewing the “Time zone list”. Formatting operation When the MODE button is pressed, the city code display changes.
  • Page 33 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the daylight saving time Power ON Change ON/OFF according to the period of daylight sav- ing time, when you are on Daylight Saving Time. Formatting operation After selecting, press and hold the MODE button to go to the next step “Setting the clock display format”.
  • Page 34 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the clock display format Power ON When the MODE button is pressed, either “12h” or “24h” is selected for the clock display format. Select the display Formatting operation format of your choice.
  • Page 35 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Now, setup of the computer is completed. Power ON When the bracket is not attached to your bicycle, return Formatting operation to Contents, click on “How to attach the bracket (movie formant)”, and then attach it according to the instruc-...
  • Page 36 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Tire circumference reference table Generally, ETRTO or the tire size is indicated on the side of the tire. Tire size Tire size Tire size Tire size Tire size...
  • Page 37 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setting up the computer Setting the time zone City Time dif- -11:00 -10:00 -09:00 +08:00 -07:00 -06:00 -05:00 -04:00 -03:00 -02:00 -01:00 -00:00 +01:00 +02:00 +03:00 +04:00 +05:00 +06:00 +07:00 +08:00...
  • Page 38 CATEYE STEALTH 50 Return to Contents Quick Start Manual How to attach the bracket...
  • Page 39 CATEYE STEALTH 50 Return to Contents Quick Start Manual How to mount the speed sensor...
  • Page 40 CATEYE STEALTH 50 Return to Contents Quick Start Manual How to wear the heart rate sensor...
  • Page 41 The settings of this unit can be changed using your PC. What is CATEYE Atlas™ CATEYE Atlas™ is a website where you can view the trips measured using this unit or INOU. • The trip (measurement data) loaded using CATEYE Sync™ can be viewed on a map and a graph.
  • Page 42 CATEYE STEALTH 50 Return to Contents Quick Start Manual CATEYE Sync™ / CATEYE Atlas™ Click on the item to view. Before use : Setting up your PC Uploading the trip (movie format) Editing and disclosing your trips (movie format) Changing the computer configuration (movie format)

  • Page 43: Setup Of Your Pc

    When you have an account: Membership registration is not required. Go to the next step “Installing CATEYE Sync™”. You can use the same account when using CATEYE INOU and having registered membership. When you do not have an account: Return...
  • Page 44 CATEYE STEALTH 50 Return to Contents Quick Start Manual Setup of your PC Membership registration to CATEYE Atlas™ (2/3) Membership Membership Installing Setting registration to registration to CATEYE Sync™ CATEYE Sync™ CATEYE Atlas™(2/3) CATEYE Atlas™ Confirm the Terms of Service, and then click on...
  • Page 45 Be sure to enter the required items. Entering the registration form Confirm the registration, and then click on . Now, your membership registration is completed. After your membership registration is completed, go to the next step “Installing CATEYE Sync™”. Confirming the registration Return Next...

  • Page 46: Installing Cateye Sync

    Membership Installing Installing Setting registration to registration to CATEYE Sync™ CATEYE Sync™ CATEYE Sync™ CATEYE Atlas™ CATEYE Atlas™ (1/2) Click on the banner of CATEYE Sync™ from the top page of CATEYE Atlas™. The download page will open. Return Next...
  • Page 47 CATEYE Sync™ will start being downloaded. Double-click on the execution file downloaded. Install CATEYE Sync™ according to the instruction dis- played on the screen. After CATEYE Sync™ is installed, go to the next step “Setting CATEYE Sync™”. D ownload for Windows version...

  • Page 48: Setting Cateye Sync

    CATEYE Sync™ CATEYE Sync™ CATEYE Sync™ CATEYE Atlas™ CATEYE Atlas™ (1/2) Start CATEYE Sync™. Double-click the shortcut [CATEYE Sync™] to start CATEYE Sync™. CATEYE Sync™ icon Click on [Q Series / STEALTH] The menu screen appears. Starting CATEYE Sync™ Return...
  • Page 49 Login setting of CATEYE Sync™ is completed. Enter your e-mail address Now, setup of the computer is completed. and password Return to the contents of CATEYE Sync™/Atlas™ and see “Uploading, editing and sharing the trip” and “Changing the computer configuration”. Setting completed...
  • Page 50 CATEYE STEALTH 50 Return to Contents Quick Start Manual Uploading the trip...
  • Page 51 CATEYE STEALTH 50 Return to Contents Quick Start Manual Editing and sharing the trip...

  • Page 52: Changing The Computer Configuration

    CATEYE STEALTH 50 Return to Contents Quick Start Manual Changing the computer configuration...
