- Page 1 INSTRUCTION BOOK COMPRESSED AIR FILTERS DD 7+-630+, DDp 7+-630+, PD 7+-630+, PDp 7+-630+, QD 7+-630+, UD 7+-630+...
- Page 3 Atlas Copco Compressed air filters DD 7+-630+, DDp 7+-630+, PD 7+-630+, PDp 7+-630+, QD 7+-630+, UD 7+-630+ Instruction book Original instructions COPYRIGHT NOTICE Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.
-
Page 4: Table Of Contents
Instruction book Table of contents Safety..........................4 ........................... 4 AFETY ICONS ................... 4 AFETY PRECAUTIONS DURING INSTALLATION ....................5 AFETY PRECAUTIONS DURING OPERATION ................5 AFETY PRECAUTIONS DURING MAINTENANCE OR REPAIR .........................6 ISMANTLING AND DISPOSAL Description........................8 ........................8 ESCRIPTION OF FILTERS PASS™........................ - Page 5 Instruction book ..........................30 RINCIPAL DATA ..........................30 PECIFIC DATA ..................... 32 ATED FLOW AT REFERENCE CONDITIONS ........................33 ORRECTION FACTORS ........................33 IMENSIONS AND WEIGHT ........................36 UPPLIED COMPONENTS Pressure equipment directives................... 38 2920 7199 41...
-
Page 6: Safety
Instruction book Safety Safety icons Explanation Danger to life Warning Important note Safety precautions during installation 1. Install the equipment where the ambient air is cool and as clean as possible. Consult section Reference conditions and limitations. 2. During installation or any other intervention on the equipment or one of the connected machines, the machines must be stopped, de-energized and the isolating switch opened and locked before any maintenance or repair. -
Page 7: Safety Precautions During Operation
Instruction book Safety precautions during operation All responsibility for any damage or injury resulting from neglecting these precautions, or non-observance of the normal caution and care required for installation, operation, maintenance and repair, even if not expressly stated, will be disclaimed by the manufacturer. -
Page 8: Dismantling And Disposal
Instruction book 7. Never use a light source with open flame for inspecting the interior of the device. 8. All regulating and safety devices shall be maintained with due care to ensure that they function properly. They may not be put out of action. 9. - Page 9 Instruction book Disposal of other used material Used filters or any other used material (e.g. filter bags, filter media, desiccant, lubricants, cleaning rags, machine parts, etc.) must be disposed of in an environmentally friendly and safe manner, and in line with the local recommendations and environmental legislation. 2920 7199 41...
-
Page 10: Description
Instruction book Description Description of filters Type Description Air flow • Coalescing filters for general purpose protection, removing solid particles, from inside to liquid water and oil aerosol outside • Air purity class in a typical installation: [2:-:3] • High efficiency coalescing filters, removing solid particles, liquid water and from inside to oil aerosol outside... -
Page 11: Filters With Inpass
Instruction book Filters with inPASS™ The premium range filters are equipped with an integrated inPASS™ valve in the housing. This inPASS™ valve will be used to service the filter and replace the filter element without interrupting operation and compressed air flow. 2920 7199 41... - Page 12 Instruction book In normal filtration operation the air flow is directed into the filter element and passes through several filter media layers before being guided to the outlet port of the filter. When the inPASS™ valve is activated, the compressed air flow is redirected through this valve to the filter outlet. This creates the opportunity to depressurize the filter housing, using the drain valve at the bottom of the filter, and service the filter element.
-
Page 13: Filters Without Inpass
Instruction book Filters without inPASS™ The standard range filter is not equipped with an integrated inPASS™. The DD+, PD+, UD+, DDp + and PDp+ filters have a differential pressure indicator for sizes 7+ to 45+ and a differential pressure gauge for sizes 45+ to 630+. At start-up and during normal operation, the differential pressure indicator will be yellow;... -
Page 14: Options
Instruction book The differential pressure gauge indicates the pressure drop on an indicative scale from 0 to 750 mbar. Refer to section Service intervals for more information on service intervals. Options Filter connection kit If two or more filters are used in combination, build the filter heads together by means of a serial connection in the correct air flow direction. - Page 15 Instruction book Voltage-free contact A voltage-free switch, mounted in the differential pressure gauge, closes at a pressure drop of 0.35 bar (5 psi) and can be used for remote control or alarm purposes. The maximum switching voltage and current are 30 VAC/VDC and 0.2 A respectively. External power supply Optionally, the smart service indicator can be fitted with an external power supply and alarm contact.
- Page 16 Instruction book Referen Description +VCC from external power supply GND (ground) from power supply Output signal NO (normally open). If needed, the contact can be changed to NC (normally closed) in the settings menu. – Electronic drain The electronic drain is optional on the DD+, PD+ and UD+ filters. The electronic drain is a zero loss, electronically operated drain valve, specially designed to drain oil condensate.
- Page 17 Instruction book If the microcontroller registers a malfunction, the automatic drain valve will automatically change to alarm mode. This alarm signal can be relayed via a potential-free contact. The electronic drain is available for 3 operating voltages: 220 V, 115 V and 24 V (50/60 Hz). An extra electric wiring can be foreseen to connect the potential free contacts and an external test button.
-
Page 18: Installation
Instruction book Installation General remarks When installing the filter, keep in mind the following: • Be sure that the piping is internally clean, especially downstream of the filter. • Sizing of filter should be done carefully, taking into account the application requirements. Maximum flow capacity, as listed in Chapter 5.4 or 6.4 "Rated flow at reference conditions", should never be exceeded to make sure that filtration performance and filter lifetime are guaranteed. -
Page 19: Specific Remarks
Instruction book Process piping recommendations To reach class 1 for solid particles according to ISO8573-1, it’s recommended to use stainless steel piping or AIRnet aluminum piping. Other types of piping, like brass or copper piping’s are not recommended as the surface roughness is too high, which makes class 1 difficult to reach. inPASS™... - Page 20 Instruction book • Remove the back-cover and insert 3 AA batteries. Make sure to use high quality batteries to ensure functionality. Batteries should at least comply to the following specification: AA size, alkaline, capacity: 2xxx mAh, voltage: 1.5V. • The device will boot up automatically •...
- Page 21 Instruction book Also, if the battery level is becoming too low, the warning mode will be activated, and the battery outline symbol will blink. Alarm mode The LED on the front of the device will be flashing once every 5 seconds in case an alarm mode is triggered.
-
Page 22: Iso 12500
Instruction book Rotation of the Smart service indicator It is possible to rotate the display of the Smart service indicator for both installation directions of the filter. 1. Remove the top cover by removing the screw with the appropriate tool. 2. - Page 23 Instruction book for benchmarking purposes. The testing will provide the user with an efficiency value on the required particle size and the initial pressure drop at nominal flow conditions. 2920 7199 41...
-
Page 24: Maintenance
Instruction book Maintenance Maintenance When maintaining the filter, keep in mind the following: • On filters with manual drain valve, open the latter at regular intervals to evacuate collected dust or liquid. • In case an automatic drain valve or a solenoid timer drain is installed, manual draining can be carried out by turning the connection nipple of the automatic drain valve counterclockwise. - Page 25 Instruction book 2. Before operating the inPASS™, please check if the circlips (1) is correctly positioned (supported by the inPASS™ groove and the horizontal face on top of the filter head) just below the hexagonal nut. In case of any doubts, please contact your supplier. 3.
- Page 26 Instruction book 2. Place the appropriate tool (wrench, spanner) over the hexagonal nut and make sure there is room for rotational movement as indicated on the lock-out feature. Rotate the inPASS™ valve over 90° in a fluent motion (to not hinder the air flow) in the direction indicated on the lock-out feature.
- Page 27 Instruction book Filter size Expected torque Maximum torque Recommended tool lb-ft lb-ft 7 - 25 7.38 22.13 Open-ended spanner 45 - 75 11.06 33.19 Ring spanner 110 - 180 18.44 55.32 Ratchet spanner 240 - 300 25.81 77.44 Ratchet spanner 390 - 510 44.25 132.76...
- Page 28 Instruction book In case the filter cannot be depressurized by venting via the drain port, do not continue with the filter element change and contact your supplier for further assistance. 5. Discard the used filter element. 6. Position the new filter element on top of the bowl and align the filter element fin with the groove in the top of the hexagonal nut, as can be seen in the figure below.
-
Page 29: Filter Element Change Without Inpass
Instruction book Filter element change without inPASS™ The hand-tool icon on the figure indicates the items provided in a dedicated filter kit. 1. Before filter element change, check for any leakages at the bottom of the filter bowl (connection of manual and automatic drain) during normal filter operation. If any leakage is observed, replace the drain according to the instruction from section Drain replacement. -
Page 30: Drain Replacement
Instruction book 7. Screw the bowl (with the filter element resting on top) completely on the head. A small amount of acid-free vaseline may be applied to the threads and O-ring of the bowl to facilitate the assembly. No lubricant of any sort should be used on the filter element seal. Drain replacement The hand-tool icon on the figure indicates the items provided in a dedicated filter kit. -
Page 31: Service Intervals
Instruction book 1. Start by isolating the filter housing from the compressed air flow. • For a filter without inPASS™ valve, this is done externally. • For a filter with inPASS™ valve, this is done by rotating the inPASS™ valve into inPASS™... -
Page 32: Technical Data
Instruction book Technical data Reference conditions Air inlet pressure 7 bar(e) 102 psig Air inlet temperature 20˚C 68 ˚F Ambient temperature 20˚C 68 ˚F Compressed air inlet dewpoint 3˚C 37 ˚F Principal data Maximum compressed air inlet pressure 14 bar(e) 203 psig (for inPASS™... - Page 33 Instruction book Solid particle 1µm > 99.999 > 99.999 > 99.999 removal 97.03 99.67 99.94 0.1µm efficiency 0.01µm > 99.999 > 99.999 > 99.999 according to ISO12500-3:2 Air purity class ISO [2:-:3] [1:-:2] [1:-:2] 8573-1:2010 in a typical installation As aerosol At MPPS: Most Penetrating Particle Size Preceded by a liquid water separation device Preceded by a liquid water separation device and a DD+...
-
Page 34: Rated Flow At Reference Conditions
Instruction book Rated flow at reference conditions Filters with inPASS™ Type Flow 110+ 145+ 180+ 240+ 300+ 380+ 425+ 510+ 1081 Filters without inPASS™ Type Flow 110+ 145+ 180+ 240+ 300+ 360+ 430+ 525+ 1112 630+ 1335 2920 7199 41... -
Page 35: Correction Factors
Some environmental aspects could cause a higher amount of oil or volatile organic compounds in the air due to processes with organic solvents/oils nearby. Contact Atlas Copco when higher concentrations can be expected. Dimensions and weight 2920 7199 41... - Page 36 Instruction book Filters with inPASS™ Type mass (kg) 1.18 G 1/2 NPT 1/2 1.24 G 1/2 NPT 1/2 1.45 390.5 315.5 G 1/2 NPT 1/2 2.35 G 3/4 NPT 3/4 NPT1 110+ 559.5 459.5 84.5 G1 1/2 NPT1 145+ 5.93 629.5 529.5 84.5...
- Page 37 Instruction book Filters without inPASS™ Type mass (kg) G 1/2 NPT 1/2 1.25 G 1/2 NPT 1/2 1.43 390.5 315.5 G 1/2 NPT 1/2 2.43 G 3/4 NPT 3/4 2.87 NPT1 110+ 5.08 559.5 459.5 84.5 G1 1/2 NPT1 145+ 629.5 529.5 84.5...
-
Page 38: Supplied Components
Instruction book Supplied components The table below gives an overview of the components provided on the different types of filters. Abbreviations: • PDSG ..Pressure Differential Smart service Indicator • PDI ..Pressure Differential Indicator • PDG ..Pressure Differential Gauge •... - Page 39 Instruction book Type DD+, PD+, UD+ DDp+, PDp+ 630+ PDG+AD PDG+MD 2920 7199 41...
-
Page 40: Pressure Equipment Directives
Instruction book Pressure equipment directives Components subject to 2014/68/EU Pressure Equipment Directive The following table contains the necessary information for the inspection of all pressure equipment according to the Pressure Equipment Directive 2014/68/EU. Size Connection Connection Total volume Maximum PED category type size (litres) - Page 41 Instruction book Size Connection Connection Total volume Maximum PED category type size (litres) working pressure (bar) 630+ 3" 18.31 CAT II 3" 18.31 CAT II 2920 7199 41...
- Page 44 COMMITTED TO SUSTAINABLE PRODUCTIVITY We stand by our responsibilities towards our customers, towards the environment and the people around us. We make performance stand the test of time. This is what we call — Sustainable Productivity. www.atlascopco.com...
