7 Drawer Cabinet
Assembly Instructions
Dimensions
Width - 53.9 inch
Depth - 15.7 inch
Height - 31.3 inch
Important
Please read these instructions fully before starting assembly
–
Please keep for future reference
-
Any question please feel free to contact us:
support@amer-life.com TEL:(901) 347-2181
We will provide further assistance within 24 hours.
CSN131-1E4A0
CSN131-1E4B0
Issue 1 -10/20/2024
Advertisement
Related Manuals for AMERLIFE CSN131-1E4A0
Summary of Contents for AMERLIFE CSN131-1E4A0
- Page 1 7 Drawer Cabinet Assembly Instructions Please keep for future reference CSN131-1E4A0 CSN131-1E4B0 Dimensions Width - 53.9 inch Any question please feel free to contact us: Depth - 15.7 inch support@amer-life.com TEL:(901) 347-2181 Height - 31.3 inch We will provide further assistance within 24 hours.
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Safety and Care Advice Important – Please read these instructions fully before starting assembly ・ Check you have all the ・ During assembly do not stand • To reduce components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 4 Componets - Panels Please check you have all the panels listed below 1 (1372*400*24mm x1) 2 (694*369*17mm x1) (694*369*17mm (684*42*12mm 5 (684*42*12mm x1) 6 (1262*38*12mm x1) 7 (361*170*15mm x2) 8 (1310*70*15mm x1) 9 (1310*70*15mm x1) 12 (300*40*25mm x6) 10 (500*361*15mm x1) 11 (1368*398*12mm x1) 13 (1318*178*3mm x1) 14 (1318*254*3mm x2)
- Page 5 Componets - Panels Please check you have all the panels listed below 21 (359*95*12mm x3) 22 (300*95*12mm x3) (300*95*12mm (367*295*3mm 25 (633*251*15mm x4) 26 (572*145*12mm x4) 27 (300*145*12mm x4) 28 (300*145*12mm x4) 29 (580*295*3mm x4) 30 (287*50*12mm x4)
- Page 6 Componets - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied are required. 6*30mm Wooden Dowel x 56 6*35mm Cam Bolt x 66 Cam Lock x 66 4*30mm Screw x 12 4*12mm Screw x 4...
- Page 7 DO NOT OVER TIGHTEN. NE KAS SERRER EXCESSIVEMENT.
- Page 8 Assembly Instructions...
- Page 9 Assembly Instructions Step 1 CAM-LOCK C x 6 A x 4 B x 6 Tighten until shoulder is flush with panel.Do not overtighten or undertighten(see example below) Shoulder NO GAP Panel Panel...
- Page 10 Assembly Instructions Step 2 A x 12 4 x 30mm F x 12...
- Page 11 Assembly Instructions Step 3 3*12mm E x 18 B x 6 M x 3...
- Page 12 Assembly Instructions Step 4 3*12mm E x 12 M x 2 Turn the panel over...
- Page 13 Assembly Instructions Step 5 3*12mm E x 12 M x 2 Edge Banding Here. No edge Banding Here. Turn the panel over No edge Banding Here. Edge Banding Here.
- Page 14 Assembly Instructions Step 6 4 x 35mm A x 4 G x 4 4 x 35mm Step 7 A x 2 G x 2 No edge Banding Here.
- Page 15 Assembly Instructions Step 8 C x 3 A x 2 Three holes in this direction Step 9 C x 3 A x 2...
- Page 16 Assembly Instructions Step 10 A x 6 Step 11 CAM-LOCK Tighten until shoulder is flush B x 12 with panel.Do not overtighten or undertighten(see example below) Shoulder NO GAP Panel Panel...
- Page 17 Assembly Instructions Step 12 4 x 40mm H x 6 The groove is here Step 13 B x 8...
- Page 18 Assembly Instructions Step 14 No hole on this side C x 8 No hole on this side No hole on this side Step 15 C x 12...
- Page 19 Assembly Instructions Step 16 4*12mm D x 4 N x 1 Step 17 A x 10 The height can be adjusted and balanced with all four feet by rotating the studs.
- Page 20 Assembly Instructions Step 18 Do not fully tighten wall fixing brackets until it's ready to be fixed to the wall. B x 8 C x 8 4 x 40mm H x 3 O x 2 The groove is here...
- Page 21 Assembly Instructions Step 19 3*12mm L x 20 P x 4 Step 20 O x 2 Please read the Guide to Wall Mounting & Fixings on the last page before excuting this step.
- Page 22 Assembly Instructions Step 21 B x 6 4 x 35mm G x 12 J x 3 K x 3...
- Page 23 Assembly Instructions Step 22 A x 6 C x 6 Step 23 3*12mm E x 18 M x 3...
- Page 24 Assembly Instructions Step 24 4*35mm G x 24...
- Page 25 Assembly Instructions Step 25 B x 20 I x 8 K x 16 Step 26 A x 8 C x 20...
- Page 26 Assembly Instructions Step 27 3*12mm E x 24 M x 4...
- Page 27 Assembly Instructions Step 28 Congratulation! You’ve made to the last step! But don’t be too thrilled yet, put on the drawer can be frustrating if you do it wrong. So, take your time and follow the steps below. 1.Please ensure that you have matched the wheels on BOTH sides of the drawer with the wheels on rails installed BEFORE push in the drawer.
