- Page 1 Mon P10, Mon P12, Mon P15 Passive Speaker...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 11.04.2025, ID: 353571, 353573, 353575 (V3)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Installation..............................11 4.1 Tips on handling speakers......................13 Connections............................... 14 Technical specifications........................15 Plug and connection assignment....................21 Protecting the environment......................22 Mon P10, Mon P12, Mon P15 Passive Speaker... - Page 4 Mon P10, Mon P12, Mon P15 Passive Speaker...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 8 Safety instructions NOTICE! Damage to the device if operated in unsuitable ambient conditions! The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the ambient conditions specified in the “Technical specifications” chapter of this user manual. Avoid operating it in environments with direct sun‐ light, heavy dirt and strong vibrations.
-
Page 9: Features
Features Features Mon P10 (item no. 353571) Special characteristics of this passive 2-way speaker: 10-inch/1-inch coaxial speakers Beam angle 80° × 80° Connection options: – 2 × lockable Speaker Twist (INPUT/LINK) Highly efficient compression drivers Powerful woofer Two carrying handles Output for further monitors Plywood enclosure with scratch-resistant black PU coating 36 mm pole flange on the bottom... - Page 10 Features Two carrying handles Output for further monitors Plywood enclosure with scratch-resistant black PU coating 36 mm pole flange on the bottom Protective cover (optional, item no. 322028) Mon P15 (item no. 353575) Special characteristics of this passive 2-way speaker: 15-inch/1.35-inch coaxial speakers Beam angle 60°...
-
Page 11: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 12 Installation NOTICE! Potential property damage due to unsuitable stands! If the product is mounted on an unsuitable stand, there is a risk that the stand will fall over and cause damage. Only use stands whose maximum load-bearing capacity is at least as high as the weight of the product.
-
Page 13: Tips On Handling Speakers
Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. -
Page 14: Connections
Connections Connections ö [INPUT] | Input, designed as a lockable Speaker Twist [LINK] | Connection for connecting another passive speaker, designed as a lockable Speaker Twist Mon P10, Mon P12, Mon P15 Passive Speaker... -
Page 15: Technical Specifications
Technical specifications Technical specifications Mon P10 Mon P12 Mon P15 (item no. 353571) (item no. 353573) (item no. 353575) System Passive 2-way monitor Configuration 10-inch woofer (with 2- 12-inch woofer (with 15-inch woofer (with 3- inch voice coil) 2.5-inch voice coil) inch voice coil) 1-inch compression 1-inch compression... - Page 16 Technical specifications Mon P10 Mon P12 Mon P15 (item no. 353571) (item no. 353573) (item no. 353575) Beam angle (H × V) 80° × 80° 60° × 80° Dimensions (W × H × D) 480 mm × 300 mm × 510 mm ×...
- Page 17 Technical specifications Further information Mon P10 Mon P12 Mon P15 (item no. 353571) (item no. 353573) (item no. 353575) Housing Wood Colour Black Truss-capable Monitor inclination Crossover points 2-way Stand flange 36 mm Wall mount Protective cover Optional (item Optional (item Optional (item no.
- Page 18 Technical specifications Dimensions and frequency response of Mon P10 420 mm 480 mm Mon P10, Mon P12, Mon P15 Passive Speaker...
- Page 19 Technical specifications Dimensions and frequency response of Mon P12 500 mm 510 mm Mon P10, Mon P12, Mon P15 Passive Speaker...
- Page 20 Technical specifications Dimensions and frequency response of Mon P15 545 mm 610 mm Mon P10, Mon P12, Mon P15 Passive Speaker...
-
Page 21: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... -
Page 22: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 23 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
- Page 24 Notes Mon P10, Mon P12, Mon P15 Passive Speaker...
- Page 25 Notes Mon P10, Mon P12, Mon P15 Passive Speaker...
- Page 26 Notes Mon P10, Mon P12, Mon P15 Passive Speaker...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
