La Marche Manufacturing Company
www.lamarchemfg.com
A12B
"Constavolt"
Battery Charger / Power Supply
*Standard A12B Battery Charger in #6 Enclosure Shown
*A12B Battery Charger with Option 52E in #6 Enclosure Shown
Installation and Operation Manual
This manual is subject to change without notice. You may obtain the newest version of the manual at
www.lamarchemfg.com
106 Bradrock Dr. Des Plaines, IL 60018-1967
CPN 40594
Instruction Drawing Number: P25-LA12B-2
Tel: 847-299-1188
Fax: 847-299-3061
Revision A12
Rev. Date: 04/22
ECN: 23167
i
