QUICK START GUIDE
LTP PARALLELING POWER SYSTEM
La Marche LTP Paralleling Power System: Quick Start Guide
WARNING: Please read the Important Safety Instructions before proceeding. Make sure to check for
1
35AH BATTERIES @ 48VDC PER BOX
(4X12VDC 35AH BATTERIES)
SYSTEM A
Mount LTP System & LTPB-2 battery box properly. Please refer
to the instruction manual for detailed mounting instructions and
drawings.
3
Connect batteries, paralleling battery cables, loads per illustration above.
P25-LLTP-SG-1
ECN 21270
10/16
MADE IN U.S.A.
Specifications subject to change without notice
any shipping damages before getting started.
SYSTEM B
2
Please make sure all battery breakers are off the position
before making any connections within the battery enclosure.
OFF
La Marche Mfg. (A U.S. Company)
106 Bradrock Drive, Des Plaines, IL 60018
Tel: 847.299.1188 Fax: 847.299.3061
sales@lamarchemfg.com
www.lamarchemfg.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for La Marche P24B-18-12V
Summary of Contents for La Marche P24B-18-12V
- Page 1 QUICK START GUIDE LTP PARALLELING POWER SYSTEM La Marche LTP Paralleling Power System: Quick Start Guide WARNING: Please read the Important Safety Instructions before proceeding. Make sure to check for any shipping damages before getting started. 35AH BATTERIES @ 48VDC PER BOX...
- Page 2 Set output voltage base on your battery type. Units are factory set at 52 volt. NOTE: Refer to battery manufactures data sheet for charging voltage. LMC Model Number Amp-Hours Nominal Voltage Volts per Cell Current Limit P24B-18-12V 18AH 2.25Vpc 2.5Amps P24B-26-12V 26AH 2.25Vpc 4.5Amps...
