Easy Key
8000系列
8000 series
推拉式智能门锁
Push-pull smart
door lock
DDL801-5HBS
DDL801-5HBS
User
用户手册
manual
在以下网站上注册产品并获得支持
www.philips.com/support
Register your product and get support at
www.philips.com/support
图片为全功能产品外观，根据不同
功能组合，产品的外观略微不同，
The image shows the fully functional
具体以实物为准。
product. Appearance may vary slightly
with different feature combinations;
please refer to the actual product for
details.
Advertisement
Table of Contents
Related Manuals for Philips EasyKey DDL801-5HBS
Summary of Contents for Philips EasyKey DDL801-5HBS
- Page 1 推拉式智能门锁 Push-pull smart door lock DDL801-5HBS DDL801-5HBS User 用户手册 manual 在以下网站上注册产品并获得支持 www.philips.com/support Register your product and get support at www.philips.com/support 图片为全功能产品外观，根据不同 功能组合，产品的外观略微不同， The image shows the fully functional 具体以实物为准。 product. Appearance may vary slightly with different feature combinations; please refer to the actual product for...
-
Page 3: Table Of Contents
Contents 1. Important Information 6. Other features Safety Mute mode Caution Factory reset Disposal of used locks and batteries Doorbell 2. Assembly 7. Indicators Packing list Status indicator Exploded views Low battery indicator Armed Notice before assembling mode indicator System Adjustable deadbolt instructions locking indicator Assembly steps... -
Page 4: Important Information
◆ Please ensure that installation or any component replacement is carried out by ◆ Please do not attempt to forcibly disassemble Philips, a Philips authorized service center, or the product to trigger an alert or cause damage. professional technicians. ◆ Please avoid using sharp objects to scrape ◆... -
Page 5: Assembly
2 Assembly Packing list This packing list is for reference only. Please refer to the actual included items. ① Exterior assembly with ② Interior assembly with ③ Drilling template ④ Mortise silicon pad silicon pad Easy Key Quick Start Warranty EasyKey EasyKey Guide Card 合格证... -
Page 6: Exploded Views
Exploded views 1.Battery cover X1 5. M5 anchor screw X2 9. M6 screw tubeX2 2. Alkaline battery X8 6. Mounting plate X1 10. Exterior assembly X1 3. M6 anchor screw X2 7. Mortise X1 11. Mortise tumbler X1 4. Interior assembly X1 8. -
Page 7: Notice Before Assembling
Notice before assembling This product applies to doors with swing directions as follows left-hand inswing, left-hand outswing, right-hand inswing, and right-hand outswing. Left-hand swing Right-hand swing Left-hand inswing Right-hand inswing Left-hand outswing Right-hand outswing Attention Please select the installation kit based on the door thickness. Adjustable latch instructions Use an Allen wrench Remove the deadbolt,... -
Page 8: Assembly Steps
Assembly steps The following assembly steps apply to the right-hand swing doors. For left-hand swing doors, please read through the [Notice before assembling] and adjust the latch direction first. To drill holes in the door according Install the screw tubes onto the to the drilling template, mount the exterior assembly, then insert the mortise into the jamb, and secure the... - Page 9 Insert the assembly and mortise cables Align and insert the mortise tumbler from the exterior assembly into their into the tumbler hole on the interior corresponding interfaces. assembly. Place any excess wiring into the hole, then tighten the screws to secure the interior assembly.
-
Page 10: Get To Know Your Lock
3 Get to know your lock Exterior assembly Status indicator ① Doorbell ② Keypad ③ Key tag recognition area ④ Mute button ⑤ Push-pull handle ⑥ Fingerprint recognition area ⑦ Charging port ⑧ Keyhole ⑨ Interior assembly Battery cover ① RES button ②... -
Page 11: Settings
4 Settings Instructions before setting ◆ The system modes include the general mode and dual verification mode. General mode Door can be opened using any enrolled access method Door can be opened using any two combinations of Dual verification mode fingerprint, PIN code, key tag, or face ID. -
Page 12: Master Mode
Master mode Settings Add a user PIN code Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. Master PIN code Press [1] to enter settings, then press [1] again to add a user. The door lock will After illuminating the keypad, without automatically detect and add PIN codes, inputting any other numbers, press the [*] key... -
Page 13: Network Settings
Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. Press [1] to enter settings, then press [4] to enter the option for adding or modifying the master fingerprint. Press [1] to enter settings, then press [6] to delete a user. -
Page 14: Get To Use Your Lock
5 Get to use your lock Outdoor/ indoor unlock Outdoor unlock Fingerprint Key tag PIN code Push/ Push/ Push/ Fingerprint pull the pull the pull the recognition handle handle to handle to Touch area Key tag to unlock unlock unlock keypad recognition area... -
Page 15: Indoor Lock
Indoor lock After closing the door, the latch bolt will automatically extend to lock it, and a voice prompt will confirm that the door is closed. Indoor lock If the door lock fails to auto-lock, press the [CLOSE] button after closing the door to lock it manually. -
Page 16: Other Features
6 Other features Mute button Function: Activate mute mode by pressing the mute button to silence voice prompts during door unlock—great for quiet times to avoid disturbing others in the household. How to use: 1. Switching voice mode to mute mode: while the system is awake, press and hold the "0"... -
Page 17: Doorbell
Doorbell Function: The indoor chime of the door lock rings to remind the homeowner of a visitor. How to use: When the doorbell button is pressed from outside, the indoor chime of the door lock will ring. Attention 1. Upon pressing the doorbell, the indicator will light up in blue and flash. -
Page 18: Low Battery Indicator Armed
Low battery indicator Red: when the door lock is awakened, it automatically checks the battery voltage. If the battery voltage is too low, the low battery indicator will illuminate. When unlocking, a voice prompt will remind you to replace the Low battery indicator battery. -
Page 19: Troubleshooting
8 Troubleshooting Alert types Armed mode Triggering: Triggering: when the door lock is in the armed mode, opening it from the inside will trigger the alert. Alert method: Alert method: continuous, repeated alert sound. Off: The alert will be off automatically after a successful verification with any access method. -
Page 20: How To Apply External Power Source
Tamper alert Triggering1: after the door gap is pried open, the sensor latch will extend. Alert method: continuous, repeated alert sound. Off: the alert will be off automatically or after a successful verification with any access method. Triggering2: exterior assembly is pried open, and not properly aligned with the door. -
Page 21: Battery Replacement
2. Align the clip points of the new handle cover with the clip position and snap it into place. Attention You can customize the handle cover in different colors. For more details, please consult a Philips Smart Lock's official consumer care center or an authorized dealer. - Page 22 Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license. This product has been manufactured by and is sold under the responsibility of Shenzhen Conex Intelligent Technology Co., Ltd., and Shenzhen Conex Intelligent Technology Co., Ltd. is the warrantor concerning this...
