- Page 1 7000 series Palm vein smart door lock DDL720-MVP-17HWSE User manual Register your product(s) to get support from below link: www. philips.com/support...
-
Page 3: Table Of Contents
Contents 1. Important Information 6. Other features Safety Armed mode Caution Mute mode Disposal of used locks and batteries Factory reset Doorbell Video and intercom Display 2. Assembly Packing list Exploded views 7. Indicators Notice before assembling Adjustable latch instructions Lock status indicator Assembly steps Low battery indicator... -
Page 4: Important Information
◆ Please ensure that installation or any component replacement is carried out by ◆ Please do not attempt to forcibly disassemble Philips, a Philips authorized service center, or the product to trigger an alert or cause damage. professional technicians. ◆ Please avoid using sharp objects to scrape ◆... -
Page 5: Assembly
2 Assembly Packing list This packing list is for reference only. Please refer to the actual included items. ① Exterior assembly with ② Interior assembly with ③ Drilling template ④ Mounting plate silicon pad silicon pad Easy Key Warranty Quick Start EasyKey Card Guide ⑤... -
Page 6: Exploded Views
Exploded views 1.Display × 1 6. Mounting plate × 1 11. M6 screw tube × 3 2. Li-polymer battery × 1 7. Mortise × 1 12. Exterior assembly × 1 3.M4 anchor screw × 6 8. Mortise anchor screw × 4 13. -
Page 7: Notice Before Assembling
Notice before assembling This product applies to doors with swing directions as follows left-hand inswing, left-hand outswing, right-hand inswing, and right-hand outswing. Left-hand swing Right-hand swing Left-hand inswing Right-hand inswing Left-hand outswing Right-hand outswing Attention 1. Please select the appropriate installation kit based on the door thickness. 2. -
Page 8: Assembly Procedure
Assembly procedure The following assembly steps apply to the right-hand swing doors. For left-hand swing doors, please read through the [Notice before assembling] and adjust the latch direction first. Insert the lock cylinder into the To drill holes in the door according corresponding position in the mortise, to the drilling template, mount the then tighten the anchor screws to... - Page 9 Pass the connecting cable through the Closely align the mounting plate hole on the door. Align the keyway against the interior side of the door, hole and the plastic cover, inserting and secure it tightly with the M6 them to closely fit against the exterior anchor screw.
- Page 10 Install the interior assembly and lock Install the battery， put on the battery the 6 M4 screws. cover and silicone plugs to complete the assembly. Attention Insert the battery into the compartment according to the orientation indicated on the battery Check the thumb turn, mechanical keys, and all components to ensure they are securely connected.
-
Page 11: Get To Know Your Lock
3 Get to know your lock This packing list is for reference only. Please refer to the actual packing items. Exterior assembly Palm vein ① Video module ② Lock status indicator ③ Doorbell ④ Keypad ⑤ Key tag scanner ⑥ Mute button ⑦... -
Page 12: Settings
4 Settings Instructions before setting ◆ The system modes include the general mode and dual verification mode. General mode Door can be opened using any enrolled access method Door can be opened using any two combinations offingerprint, Dual verification mode PlN code, key tag, or palm vein. -
Page 13: Master Mode
Master mode Settings Add a user PIN code Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. Master PIN code Press [1] to enter settings, then press [1] After illuminating the keypad, without again to add a user. - Page 14 Add a one-time PIN code Add or modify the master fingerprint Press the [*] key twice, enter the master PIN Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. code, and then press the [#] key to confirm. Press [1] to enter settings, then press [2] to Press [1] to enter settings, then press [4] to enter the option for adding or modifying the...
-
Page 15: System Settings
Delete a user Volume settings Press the [*] key twice, enter the master PIN Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. code, and then press the [#] key to confirm. Press [1] to enter settings, then press [6] to Press [2] to enter system settings, then press delete a user. -
Page 16: Network Settings
Network settings Dual verification Join a network Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. Press the [*] key twice, enter the master PIN code, and then press the [#] key to confirm. Press [2] to enter system settings, then press [4] to enable or disable dual verification. -
Page 17: Network Connection
200 to 500 milliseconds, with increments of 100 milliseconds per adjustment. Network Connection Download the official App Please scan the QR code or go to the corresponding App Store to search and download “Philips Home Access”. -
Page 18: Get To Use Your Lock
5 Get to use your lock Outdoor/ indoor unlock Outdoor unlock PIN code Fingerprint Push/ Push/ Fingerprint pull the pull the recognition area handle to handle to Touch unlock unlock keypad ① Touch to wake up the keypad, enter ①Place the finger with the pre- the pre-set PIN code, then press the enrolled fingerprint correctly on the [#] key to confirm. -
Page 19: Outdoor/ Indoor Lock
Indoor unlock Lever [OPEN] button Rotary knob Double-press the [OPEN] button Pull the rotary knob outward To unlock indoors, simply grip within one second, then push or and rotate it to unlock the the handle and rotate it. pull the door to unlock. door. -
Page 20: Mechanical Key Unlock
Lever To lock indoors, simply grip the handle and rotate it. Mechanical key ① Take out the mechanical ② Remove the handle cover. ③ Insert the mechanical key from the packaging. key into the keyway hole and rotate to unlock after inserting firmly. -
Page 21: Other Features
6 Other features Armed mode Function: Once the door lock is opened from the inside, it will trigger an alert. How to use: After locking the door, press [8] key to enter the armed mode. Attention 1. Armed mode is only available for mortise locks equipped with a detection switch;... -
Page 22: Factory Reset
Factory reset Function: Empty all user data and restore to factory default settings. How to use: Press the [RES] button twice with a sharp object to reset the lock, which will erase all user information. Doorbell Function: The indoor speaker plays a dingdong sound, informing that someone is at the door. -
Page 23: Video And Intercom
Video and intercom Function: The app's video viewing feature allows real-time monitoring of the doorstep and two-way communication. How to use: Once the door lock is connected to the app, you can use the video viewing feature to monitor the doorway in real-time and engage in two-way communication. -
Page 24: Indicators
7 Indicators Status indicator Blue: when the system wakes up, the indicator turns blue, indicating that the door Status indicator lock is ready for operation. Green: when the door lock is unlocked, the indicator turns green, indicating that the door has opened. Red: when the door lock is locked, the indicator turns red, indicating that the door has closed.that the door has opened. -
Page 25: System Lock-Out Indicator
System lock-out indicator [2] button in flashing [1] button in flashing If there are five consecutive incorrect attempts within five minutes using fingerprint, PIN code, or key tag, the door lock will be locked for two minutes. Attention Prompts will only appear upon touching to wake up the keypad In 2 mins In 1 mins... -
Page 26: Troubleshooting
8 Troubleshooting Alert types Armed mode Triggering: when the door lock is in the armed mode, an alert will be triggered upon unlocking the lock from the inside. Alert method: continuous, repeated alert sound. Off: the alert ends upon successful verification of any access method.inside. - Page 27 Tamper alert Triggering1: after the door gap is pried open, the assitant bolt will extend. Alert method: continuous, repeated alert sound. Off: the alert will be off automatically or after a successful verification of any access method. Triggering2: exterior assembly is pried open, and not properly aligned with the door.
- Page 28 Motion detection alert Triggering1: if suspicious individuals linger within the view of the main camera outside the door for a duration exceeding the preset value, it will activate Radar a loitering alert. sensor Alert method: the main camera will automatically capture video or images and send alert notifications to the app.
-
Page 29: How To Apply External Power Source
How to apply external power source When the battery voltage is low and you're unable to unlock the door from outside, you can use a 5V power bank as an emergency power source for the door lock. After unlocking the door, please replace the battery promptly. - Page 30 Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license. This product has been manufactured by and is sold under the responsibility of Shenzhen Conex Intelligent Technology Co., Ltd., and Shenzhen Conex Intelligent Technology Co., Ltd. is the warrantor concerning this...
