Convertible bunk bed
Hide thumbs

Advertisement

Table of Contents

TM
Weight Limit:200 Lb / 91 Kg
for upper bed
225 Lb / 102 Kg
for lower bed
T.L - 2017/12/14
2014 Dorel Home Products All Rights Reserved
Convertible Bunk Bed
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
3264196WE
Twin Twin
Lot Number
B343264196WE01 - 10125-M
Silver
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Twin Twin 3264196WE and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Home Products Twin Twin 3264196WE

Summary of Contents for Dorel Home Products Twin Twin 3264196WE

  • Page 1 Visit www.dhpfurniture.com/eng/support-home or call Toll-Free 1-800-267-1739 Date of Purchase Lot Number THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. B343264196WE01 - 10125-M T.L - 2017/12/14 2014 Dorel Home Products All Rights Reserved...

  • Page 2: Warranty Information

    Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of Work in a spacious area and near where the unit will be used, preferably on a original purchase.
  • Page 4 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Post Post Post Post Post Before you throw the package, please use the T929760 T929770 T929780 T929790 T929800 Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
  • Page 5 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Slats Slat Spacer Slat Spacer Bolt Hole Plug Before you throw the package, please use the Plastic Plug T919470 T919490 T919480...

  • Page 6: Hardware Pack

    Hardware Pack Hardware Pack #: T3264196-01 1/4" X 5/8" X 30 5/16" X 3/4" X 16 1/4" X 1 5/8" 4 mm 1/4" X 2 3/8" Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
  • Page 7 Step 1 For you Safety,please ensure that the warning on E1 is oriented towards upside and inside of the bed . Attach E1 to A & C with Attach E2 to A & B with Warning label on part E1 should be oriented on the same side as rail holes!
  • Page 8 Step 2 Attach E2 X 2 to D X 2 & D1 X 2 with...
  • Page 9 Step 3 Wide side of the slot should be facing up ! Upper Bed: Attach J to A & B and H to A & C with Upper Bed Lower Bed: Attach J X 2 to D and D1 with Lower Bed X 16...
  • Page 10 Step 4 Upper Bed:Insert O into H & J as illustrated, then lock O into place with Y. Lower Bed:Insert O into J X 2 as illustrated, then lock O into place with Y. Upper Bed Lower Bed...
  • Page 11 Step 5 5.1 Press W onto O as illustrated. 5.2 Press Q onto W alternating left and right as illustrated. Upper Bed Lower Bed...
  • Page 12 Step 6 This bed offers you 2 status of bed: Single Beds and Bunk Bed, To assemble as Single Beds: From Step 6 to Step 7. To assemble as Bunk Bed: From Step 8 to Step 11. 6.1 Press Y1 X 4 and S X 4 into A B & C . 6.2 Screw X 6 into A B &...
  • Page 13 Step 7 Press Y1 X 4 and S X 4 into D X 2 and D1 X 2. SINGLE BEDS ASSEMBLY IS DONE! Lower Bed...
  • Page 14 Step 8 To assemble as Bunk Bed: From Step 8 to Step 11. 8.1 Attach F to A & H with & 8.2 Attach E to B & A with Upper Bed...
  • Page 15 Step 9 Insert K X 4 into D X 2 & D1 X 2 with Lower Bed...
  • Page 16 Step 10 With the help of an extra hand, move Upper Bed on the top of Lower Bed, and carefully slide A X 2, B & C into K X 4, then properly tighten with Upper Bed Lower Bed...
  • Page 17 Step 11 Attach Z to H with Fully tighten all the bolts. BUNK BED ASSEMBLY IS DONE!

  • Page 18: Helpful Hints

    Helpful Hints Weight Limit: 200 Lb / 91 Kg 225 Lb / 102 Kg Move your new furniture carefully, with two people lifting and carrying the unit to its new location. Your DHP furniture can be disassembled and reassembled to move. Clean the product with a soft damp cloth.
  • Page 19 WARNINGS for Bunk Bed Follow the information on the warnings appearing on the upper bunk end structure and on the carton. Do not remove warning label from bed. Always use the recommended size mattresses or mattress supports, or both, to help prevent the likelihood of entrapment or falls. Use only a twin mattress which is 74"-75"...
