Sealey AP6215BE Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
‰
system.
Always load evenly with the centre of gravity of the load as near centre of the system as possible.
9
DO NOT overload the system - see section 3.
8
Use the system in a suitable work area.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Keep the system clean and tidy in accordance with good workshop practice.
9
DO NOT use the system for any purpose other than that for which it is designed.
8
DO NOT stand on the system, use it as a ladder or allow others to ride on the system.
8
Use the wheel locks to prevent the system from inadvertently moving.
9
DO NOT leave unattended, especially when loaded, unless the wheels are locked, chocked or the system otherwise secured.
8
DO NOT use system on uneven ground and do not run over curbs or steps - use a ramp.
8
DO NOT use system if any part is significantly damaged, paying particular attention to the wheels.
8
Keep children and unauthorised persons away from the work area.
9
2. INTRODUCTION
AP6215BE
Use as part of a complete garage storage system or as an individual storage trolley. All heavy-duty steel construction and manufactured
with steel inner walls for extra strength and durability. 15 Full height rear locking mechanism, soft close drawers with heavy-duty 45mm
ball-bearing slides that provide superior performance. Each drawer features stylish black anodized drawer pulls plus pre-cut non-slip
liners. Textured industrial powder coated finish. Fitted with four Ø152mm PP wheels with black chrome effect alloys, two castors with quick
release anti-rotation toe locks and two fixed wheels. Side handle for added comfort when manoeuvring around the workplace and stylish
30mm wooden work top. Features a power cord storage hanger and bottle opener. Supplied with two folding keys. This item is heavy. Extra
assistance must be provided at the delivery point to help its safe delivery.
AP6204BE
1864mm side locker with four self-adjusting powder coated shelves. Use as part of a complete garage storage system. All heavy-duty steel
construction and manufactured with steel inner walls for extra strength and durability. Textured industrial powder coated finish. Fitted with two
Ø152mm PP wheels with black chrome effect alloys and quick release anti-rotation toe locks. Only for use with Sealey AP6215BE 1549mm
Mobile Trolley and AP6103BE Hutch and 2 drawer riser unit. Supplied with two folding keys. Extra assistance must be provided at the
delivery point to help its safe arrival, delivered on a wooden pallet.
AP6203BE
Use as part of a complete garage storage system. All heavy-duty steel construction and manufactured with steel inner walls for extra strength
and durability. Two heavy-duty riser drawers with 45mm ball-bearing drawer slides provide superior performance, suitable for heavier loads.
Full height rear locking mechanism locks smooth running soft close drawers in place. Each drawer features stylish black anodized heavy-
duty drawer pulls plus pre-cut non-slip liners. Textured industrial powder coated finish. Hutch style topchest features gas struts, single full-
length powder coated shelf and pegboard back for easy tool storage. Pegboard is compatible with all Sealey TTS hooks. Hutch is supplied
with a power strip (4 x 230V, 2 x 5V 2.4A USB sockets) which can be easily installed to suit user, and also features LED lights. Hutch and
riser drawer set supplied together. Only for use with Sealey AP6215BE 1549mm Mobile Trolley. Supplied with two folding keys. Extra
assistance must be provided at the delivery point to help its safe delivery, delivered on wooden pallet.
3. SPECIFICATION
Model No.:........................................................... AP6215BE
Overall Size ( W x D x H): ....................1549 x 584 x 979mm
Weight Capacity: .......................................................... 415kg
Top Drawer x1: .......................................510 x 70 x 1430mm
© Jack Sealey Limited
MODULAR STORAGE SYSTEM
AP6215BE, AP6204BE, AP6203BE
MODEL NO'S:
Model No.:........................................................... AP6204BE
Shelf size in Locker x4: .....................................530 x 690mm
Overall Size ( W x D x H): .....................698 x 584 x 1864mm
Original Language Version
AP6215BE, AP6204BE, AP6203BE Issue 2 27/09/24
