Summary of Contents for Zotac ZBOX HD-ND02
- Page 2 ZOTAC. Products and corporate names mentioned in this manual may not be reg- istered trademarks or copyrights of their respective companies, and are used for identification purposes only.
-
Page 3: Table Of Contents
Removing a hard disk (for HDD Bracket 2) ----------------------------------------- 13 Positioning your ZOTAC ZBOX --------------------------------------------------------------- 14 Installing the stand ----------------------------------------------------------------------------- 14 Installing your ZOTAC ZBOX to a monitor ----------------------------------------------- 14 Setting up your ZOTAC ZBOX ---------------------------------------------------------------- 15 Installing drivers and software --------------------------------------------------------------- 16... -
Page 4: Product Specifications
ZOTAC ZBOX Product Specifications q Chipset v NVIDIA MCP7A-ION Series ® q Product Size v 188mm x 188mm x 44mm q Microprocessor support v Intel ATOM 230/330 CPU (533 MHz FSB) ® q Operating systems: v Supports Windows XP 32 bit/64 bit, Windows Vista 32 bit/64 bit and Windows... -
Page 5: Safety Information
ZOTAC ZBOX Safety information Your ZOTAC ZBOX is designed and tested to meet the latest standards of safety for infor- mation technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before you operate your system. -
Page 6: Welcome
ZOTAC ZBOX Welcome Congratulations on your purchase of the ZOTAC ZBOX. The following illustration displays the package contents of your new ZOTAC ZBOX. If any of the below items is damaged or missed, contact your retailer. Package contents • 1 x ZOTAC ZBOX •... -
Page 7: Getting To Know Your Zotac Zbox
ZOTAC ZBOX Getting to konw your ZOTAC ZBOX Front view Refer to the diagram below to identify the components on this side of the system 1. Headphone/Audio Out jack The stereo headphone jack (3.5mm) is used to connect the system’s audio out signal to amplified speakers or headphones. -
Page 8: Rear View
ZOTAC ZBOX Rear view Refer to the diagram below to identify the components on this side of the system. 1. eSATA port The external SATA port is compatible with e.SATA devices such as external hard drives and Blu-ray drives 2. USB ports The USB (Universal Serial Bus) port is compatible with USB devices such as key- boards, mouse devices, cameras and hard disk drives. -
Page 9: Installing Hardware Inside Zotac Zbox
ZOTAC ZBOX Installing Hardware inside ZOTAC ZBOX Before installing hardware, please follow the instructions below to remove the cover of your ZOTAC ZBOX. 1. Unscrew. 2. Gently remove the cover as the image below. Installing a memory module 1. Insert the memory module into the socket at a 45 degree angle. -
Page 10: Removing The Memory Module
2. Gently press down on the memory module until it is locked by the arms of the socket. Removing the memory module 1. Remove the cover of your ZOTAC ZBOX. 2. Gently press the two arms securing the memory in the socket as shown in the image below to release the memory module. -
Page 11: Installing And Removing A Hard Disk
HDD Bracket 2 Installing a hard disk (for HDD Bracket 1) 1. Remove the cover of your ZOTAC ZBOX. 2. Unscrew and remove the screw from the hard disk bracket, and raise the lid as shown in the image below. -
Page 12: Installing A Hard Disk (For Hdd Bracket 2)
ZOTAC ZBOX 4. Gently press down on the hard disk until it is seated, shut and screw the lid. 5. Reinstall the cover of your ZOTAC ZBOX. Installing a hard disk (for HDD Bracket 2) 1. Remove the cover of your ZOTAC ZBOX. -
Page 13: Removing A Hard Disk (For Hdd Bracket 1)
ZOTAC ZBOX Removing a hard disk (for HDD Bracket 1) 1. Remove the cover of your ZOTAC ZBOX. 2. Unscrew and remove the screw from the hard disk bracket, and raise the lid as shown in the image below. 3. Gently remove the hard disk from the socket, close and screw the lid. -
Page 14: Removing A Hard Disk (For Hdd Bracket 2)
ZOTAC ZBOX Removing a hard disk (for HDD Bracket 2) 1. Remove the cover of your ZOTAC ZBOX. 2. Pull the hard disk bracket with your right index finger and middle finger. 3. Gently remove the hard disk from the socket. -
Page 15: Positioning Your Zotac Zbox
Installing your ZOTAC ZBOX to a monitor You can also install your ZOTAC ZBOX to the back of a monitor. To do so: Secure the VESA mount to your monitor with four screws (HNM/M4x8). Place your ZOTAC ZBOX on the VESA mount noting the correct alignment and then secure the PC to the VESA mount with a coin. -
Page 16: Setting Up Your Zotac Zbox
Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system. When your ZOTAC ZBOX is not in use, unplug the power adapter or switch off the ... -
Page 17: Installing Drivers And Software
Install system drivers to gain full functionality of the ZOTAC ZBOX hardware and features. Installing system drivers Before you can use the full features of the ZOTAC ZBOX, the system drivers must be installed. The following types of operating systems are supported by the ZOTAC ZBOX driver CD: •... -
Page 18: Using Your Zotac Zbox
Select the wireless network you want to connect to from the list and click Connect. After connection was established, you will see Connected. Connect the supplied wireless antenna to your ZOTAC ZBOX to enhance wireless signal reception. For security concerns, Do NOT connect to an ... -
Page 19: Using A Dynamic Ip (Pppoe Connection)
Configuring audio output via an HDMI device If you use your TV with an HDMI connector as an audio output device, connect it to your ZOTAC ZBOX and follow the steps below to configure audio settings: Access the Sound settings via the system Control Panel... - Page 20 ZOTAC ZBOX...
- Page 21 ZOTAC ZBOX...
