Summary of Contents for Zotac ZBOX HD-NS21-E
- Page 2 ZOTAC. Products and corporate names mentioned in this manual may not be reg- istered trademarks or copyrights of their respective companies, and are respective owners.
-
Page 3: Table Of Contents
Removing a hard disk (for Type 1 HDD Bracket) ---------------------------------- 12 Removing a hard disk (for Type 2 HDD Bracket) ---------------------------------- 13 --------------------------------------------------------------- 14 Installing the stand ----------------------------------------------------------------------------- 14 Installing your ZOTAC ZBOX to a monitor ----------------------------------------------- 14 ---------------------------------------------------------------- 15 --------------------------------------------------------------- 16 Installing an operating system -------------------------------------------------------------- 16... - Page 4 ZOTAC ZBOX ® v NVIDIA q Product Size v 188mm x 188mm x 44mm ® v Intel v Supports Windows XP 32 bit/64 bit, Windows Vista 32 bit/64 bit and Windows 7 32bit/64bit v Supports hot plug and play v Six USB 2.0 ports (two front panel ports, four rear panel ports) v Support one ESATA port.
-
Page 5: Setting Up Your System
ZOTAC ZBOX Safety information Your ZOTAC ZBOX is designed and tested to meet the latest standards of safety for infor- mation technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before you operate your system. -
Page 6: Package Contents
ZOTAC ZBOX Welcome Congratulations on your purchase of the ZOTAC ZBOX. The following illustration displays the package contents of your new ZOTAC ZBOX. If any of the below items is damaged or missed, contact your retailer. -
Page 7: Front View
ZOTAC ZBOX Getting to know your ZOTAC ZBOX Front view Refer to the diagram below to identify the components on this side of the system The stereo headphone jack (3.5mm) is used to connect the system’s audio out The microphone jack is designed to connect the microphone used for video confer- encing, voice narrations or simple audio recordings. -
Page 8: Rear View
ZOTAC ZBOX Rear view Refer to the diagram below to identify the components on this side of the system. The external SATA port is compatible with e.SATA devices such as external hard drives and Blu-ray drives The USB (Universal Serial Bus) port is compatible with USB devices such as key- boards, mouse devices, cameras and hard disk drives. -
Page 9: Installing A Memory Module
ZOTAC ZBOX Installing Hardware inside ZOTAC ZBOX Before installing hardware, please follow the instructions below to remove the cover of your ZOTAC ZBOX. 1. Unscrew. Installing a memory module at a 45 degree angle. -
Page 10: Removing The Memory Module
ZOTAC ZBOX memory slot. This ZOTAC ZBOX accomodates two install at least one module in any of the two slots. If you want to install two SO- Removing the memory module below to release the memory module. 2. The memory module can be easily taken out. -
Page 11: Installing And Removing A Hard Disk
Installing and removing a hard disk Users please note that the hard disk bracket of your ZOTAC ZBOX will be one of the two images below. Please install or remove the hard disk according to the hard disk bracket type. -
Page 12: Installing A Hard Disk (For Type 2 Hdd Bracket)
ZOTAC ZBOX 3. Insert a 2.5-inch SATA hard disk into the bracket at a 45 degree angle and gently slide into the connector. Installing a hard disk (for Type 2 HDD Bracket) -
Page 13: Removing A Hard Disk (For Type 1 Hdd Bracket)
ZOTAC ZBOX 2. Insert a 2.5-inch SATA hard disk into the bracket at a 45-degree angle. pressing down on the hard drive to secure the hard disk into the bracket. 4. Ensure the hard disk snaps into place with the plastic clips. -
Page 14: Removing A Hard Disk (For Type 2 Hdd Bracket)
ZOTAC ZBOX Removing a hard disk (for Type 2 HDD Bracket) -
Page 15: Installing The Stand
ZOTAC ZBOX Positioning your ZOTAC ZBOX Do not position the ZOTAC ZBOX where the ventilation holes are covered. To guarantee proper use, leave 4 inches (10 cm) spacing in front of the ventilation holes. ZOTAC mini-PC system provide ample connectivities in tiny space, please choose... - Page 16 Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system. When your ZOTAC ZBOX is not in use, unplug the power adapter or switch off the AC outlet to save on power consumption.
-
Page 17: Installing An Operating System
Install system drivers to gain full functionality of the ZOTAC ZBOX hardware and features. Installing system drivers Before you can use the full features of the ZOTAC ZBOX, the system drivers must be installed. The following types of operating systems are supported by the ZOTAC ®... -
Page 18: Using A Static Ip
Connect. After connection was established, you will see Connected. Connect the supplied wireless antenna to your ZOTAC ZBOX to enhance wireless signal reception. For security concerns, Do NOT connect to an unsecured network, otherwise, the transmitted information without encryption might be visible to others. -
Page 19: Using A Dynamic Ip (Pppoe Connection)
ZOTAC ZBOX Repeat Step 1-3 in the previous section. Select Obtain an IP address automatically and click OK. Click Next. Select Connect to the Internet and click Next. Select Set up my connec- tion manually. Select your connection type and click Next. - Page 20 ZOTAC ZBOX...
- Page 21 ZOTAC ZBOX...
