- Page 1 Installation Manual Frame Solar Modules - V.2 Mxxx-A1F - Mxxx-B1F - Mxxx-yyyy1F mitrex.com...
- Page 2 3.4 Parallel Connection 3.5 Electrical Grounding 4. Mechanical Installation ..................05 4.1 General Information 4.2 Site Considerations 4.3 Module Mounting 4.4 Mounting Via Clamps 5. Appendix ........................07 5.1 Electrical Specifications 5.2 Mechanical Specifications 5.3 Temperature Specifications 5.4 Clamping Position mitrex.com...
-
Page 3: Product Information
• Handle the module in a way that avoids breakage, scratching, bending of the glass and backsheet. Mitrex shall not be held responsible for damages of any kind, including – without limitation – bodily harm, injury or damage to property, in connection •... -
Page 4: Electrical Installation
Please ensure that all wiring is in perfect electrical and mechanical condition. 3.2 Wiring Requirements • Mitrex recommends that all wiring be double insulated with a minimum rating of 90°C (194°F). • All wiring should use a flexible copper conductor. -
Page 5: Mechanical Installation
• Depending on national directives, additional safety factors might be applicable for over current protection. 4.2 Site Considerations • Mitrex Solar Modules should be mounted in a location that meets the following requirements. WARNING: A multiplying factor is required for increased output of the PV modules. - Page 6 • Clamps are not in contact or cast shadows on the front glass. • Clamps do not damage, deform, or bend the module frame. • Clamps that satisfy the structural requirements of the installation site. • Long-term stable clamps that securely affix the module to the mounting frame. mitrex.com...
- Page 7 Clamp configuration CL1 – 4 point installation, rails perpendicular to long Temperature Coefficient Isc 0.036% / °C edge of PV module. Temperature Coefficient Pmax -0.36% / °C Note: For the most up to date electrical and mechanical specifications, refer to the individual datasheets. mitrex.com...
- Page 8 Installation Manual Framed Solar Modules A = (250 – 450) mm Uplift Load ≤ 5400 Pa Downforce Load ≤ 5400 Pa Clamp configuration CL2 – 4 point installation, mounting rails parallel to long edge of PV module. mitrex.com...
- Page 9 Installation Manual Framed Solar Modules General Product Datasheet T oll Free +1 (855) 254 0214 Learn More mitrex.com info@mitrex.com Headquarters 41 Racine Rd, Toronto, ON M9W2Z4, Canada +1 (416) 497 7120 USA Office Chrysler Building, 405 Lexington Avenue Floor 26, New York, USA, 10174 +1 (646) 583 4486 mitrex.com...
