Synco Xtalk XMax User Manual

Full duplex wireless intercom headset system
Hide thumbs

Advertisement

Table of Contents

Xtalk XMax
Full Duplex Wireless Intercom Headset System
User Manual
Thank you for choosing SYNCO product. Please read this manual carefully before use
and follow all instructions mentioned herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Xtalk XMax and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Synco Xtalk XMax

Summary of Contents for Synco Xtalk XMax

  • Page 1 Xtalk XMax Full Duplex Wireless Intercom Headset System User Manual Thank you for choosing SYNCO product. Please read this manual carefully before use and follow all instructions mentioned herein.
  • Page 2 C o n ten ts Product Introduction P 01 Button Function P 01 Operations P 02 1. Power On/Off P 02 2. Master/Level 1/Level 2 Settings P 03 3. Pairing/Unpairing P 04 4. Group Management P 07 5. Volume Settings P 10 6.

  • Page 3: Product Introduction

    Product Introduction ① 3.5mm Mic In Port ② Power On/Off Toggle ③ Microphone Status Indicator ④ Button A ⑤ Volume ＋ & Headset Settings Verification button ⑥ Button B ⑦ Volume － ⑧ Master/LV.1/LV.2 Indicator ⑨ Type-C Port Button Function Button A Pairing/Unpairing Set as the Master/Level 1/Level 2...
  • Page 4 Volume － Volume Down Switch among Boost Mode 1/2/3(Only For Master) Operations 1. Power On/ Off Power On: Push the power toggle switch upwards to turn it on. Power Off: Push the power toggle switch downwards to turn it off. ↑...
  • Page 5 2. Master/Level 1/Level 2 Settings All headsets can be set as: Master/Level 1/Level 2 Set as Master： Long press the button A, release after the 2nd "Beep" sound and hear "Master Mode". Indicator: red. Master Release Beep, Beep Mode Set as Level 1： Long press the button A, release after the 3rd "Beep"...
  • Page 6 3. Pairing/Unpairing You can pair the headsets via SYNCO EasyGo software. Download link: https://www.syncoaudio.com/pages/synco-xtalk-easygo User guide: https://youtu.be/PmjeSV-5xzI Or pair them by manual. Manual Pairing * The Xtalk Max headset can be paired with all versions of Xtalk headset. * It supports group connections with up to13 people.
  • Page 7 3.2 If Pair 6~13 headsets 1) Set a Master, 4 Level 1 and 1~8 Level 2. Level 1 Pairing Master Mode Level 2 Pairing 2) Long press the button A on Master and 4 Level 1 in 1 min, release after the 1st “Beep” sound, and hear "Connecting and Pairing".
  • Page 8 Level 2 Level 2 Level 1 Level 1 Level 2 Level 2 Master Level 2 Level 2 Level 1 Level 1 Level 2 Level 2 * A Master can connect up to 4 Level 1, and a Level 1 can connect up to 2 Level 2. * The Level 2 must be paired with the Level 1 before it can connect to the Master.
  • Page 9 4. Group Management You can divide an Xtalk system into independent groups or merge multiple groups into one single group. 4.1 Divide Into Groups 1)Set the required number of Master based on the planned group count (see 2. Master Settings). 2)Set the Level 1/Level 2 for each group (see 2.
  • Page 10 Divide XMax9 into 2 groups: 2-Person Group & 7-Person Group 1)Set 2 Masters, 5 Level 1, and 2 Level 2. 2)Pairing (* Please pair and restart each group before pairing the next.). 2-Person Group： Long press the button A on a Master and a Level 1, release after the 1st "Beep" sound and hear "Connecting and Pairing", then restart the headsets.
  • Page 11 4.2 Combine Into One Group 1) Only keep one Master, and set the other headsets as Level 1 and Level 2 if needed. (See 2. Master/Level 1/Level 2 Settings). 2)Pair all headsets and restart (see 3. Pairing/Unpairing). Combine 2 groups(A 2-Person Group and A 5 Person Group) into 1 group 1)Keep 1 Master, set 4 Level 1 and 6 Level 2(See 2.
  • Page 12 5. Volume Settings Short press the volume up/down button to increase/decrease the volume. 6. Noise Cancellation Short press the B button to turn on/off the noise cancellation feature. 7. Mute/Unmute Rotate the boom arm up/down (see the picture below) to mute/unmute. Mute Unmute Unmute...
  • Page 13 9. Boost Mode When poor signal, switch the Boost Mode to amplify the signal, improving communication clarity and stability, and reducing interruptions and disconnections. Long press the volume-, release after the 1st "Beep" sound to switch the mode and hear “Mode 1/Mode 2/Mode 3”.
  • Page 14 Release 11.2 Bluetooth Pairing After switching to Bluetooth mode, connect the Bluetooth "SYNCO" on your device. * The headset will enter the Pairing Mode after switching to Bluetooth mode. Or you can long press button A, release after the 1st "Beep" to hear "Pairing" to enter the Pairing Mode.
  • Page 15 11.5 Activate the Voice Assistant Double press the button B to activate the voice assistant. 11.6 Call Control Pick Up/End/Reject the Call Short press the button A to pick up/end the call. Double press the button A to reject the call.
  • Page 16 12. Powering Via Replaceable Battery Power Push down the toggle of the battery case then pull the case door outward to place/remove the battery. 13. Indicator Light Status Microphone Status Indicator Green Light Steady Connection Successful Green Light Flashing Slow Not Connected Green/Yellow Lights Alternating Noise Cancellation Off...
  • Page 17 Note: For the firmware update using EasyGo, please: 1.Switch the headset to intercom mode. 2.Open the SYNCO EasyGo and connect the headset. Click "XMAX Series" to open the XMAX firmware upgrade & voice package installation page. 3.Select the firmware package/voice package + Bluetooth voice package and click "Install"...

  • Page 18: Specifications

    Specifications Wireless Technology Digital 2.4GHz Transmission Mode Full-Duplex Operating Range 500m (LOS) Frequency Band 2.4GHz Approximate RF Sensitivity <-90dBm Radio Output Frequency 20dBm Power USB-C 5V Battery Capacity 1050mAh Li-ion Battery Working Time Charging Time About 2.5H Frequency Response 150Hz~7KHz Signal-To-Noise Ratio ≥...

  • Page 19: Packing List

    Packing List XM ax1 Headset x1 Charging Cable Carrying Bag Rechargeable Battery x1 One-Ear Foam Mic Windshield Warranty Cushion x1 Card x1 XM ax2 Headset x2 Charging Cable Carrying Bag Charging Station x1 One-Ear Foam Mic Windshield Warranty Card Rechargeable Cushion x2 Battery x2 www.syncoaudio.com...
  • Page 20 XM ax5 Headset x5 Storage Case x1 6-Slot Charging Charging Carrying Station x1 Adapter x1 Bag x5 Rechargeable One-Ear Foam Mic Windshield Data Transfer Warranty Battery x5 Cushion x5 Cable x1 Card x1 XM ax9 Headset x9 Storage Case x1 6-Slot Charging Charging Carrying...

  • Page 21: Warranty

    · Warranty does not apply to human errors. WARRANTY Warranty Period Thank you for purchasing SYNCO products. 1. Customers are entitled to free replacement or repair service in case of quality defect(s) found in the product under normal use within 30 days upon receipt of the product.
  • Page 22 2. Please retain your sales receipt and warranty certificate as proof of purchase. If any of these documents is missing, only sales return or chargeable service will be provided. 3. If the SYNCO product is out of the warranty coverage, the service and the parts cost will be charged.
  • Page 23 Guangzhou Zhiying Technology Co., Ltd Room 2401, 24 / F, South Tower, Lisheng Plaza, No. 68 Huadi Avenue, Liwan District, Guangzhou, China, 510000 support@syncoaudio.com www.syncoaudio.com https://www.facebook.com/syncomicrophones...
