- Page 1 Xtalk Full Duplex Wireless Intercom Headset System User Manual Thank you for choosing SYNCO product. Please read this manual carefully before use and follow all instructions mentioned herein.
-
Page 2: Table Of Contents
Contents P 01 Product Introduction P 01 Button Function P 03 Operations P 03 1. Power On/Off P 04 2. Master/Remote/Level 1/Level 2 Settings P 05 3. Pairing/Unpairing P 08 4. Group Management P 10 5. Volume Settings P 10 6. -
Page 3: Product Introduction
Product Introduction ① 3.5mm Mic In Port ② Power On/Off Toggle ③ Indicator Light ④ Button A ⑤ Volume ＋ & Headset Settings Verification button ⑥ Button B ⑦ Volume － ⑧ Type-C Port Button Function Note:The operations may vary depending on the firmware version. Please follow the instructions below to check the current firmware version.。... - Page 4 Button B Noise Cancellation on/off Turn on the Dominant Mode(Only For Master) Pair with nearby Level 1(Only For Level 2) Volume ＋ Volume Up Indicate whether the headset is Master, Remote, Level 1, or Level 2 Volume － Volume Down Switch among Boost Mode 1/2/3(Only For Master With New Firmware) www.syncoaudio.com...
-
Page 5: Operations
Operations 1. Power On/ Off Power On: Push the power toggle switch upwards to turn it on. Power Off: Push the power toggle switch downwards to turn it off. ↑ Power On *Products are pre-paired from the factory (except ↓ Power Off X1) and ready to use. -
Page 6: Master/Remote/Level 1/Level 2 Settings
2. Master/Remote/Level 1/Level 2 Settings All headsets can be set as: Previous firmware: Master/Remote New firmware: Master/Level 1/Level 2 Set as Master： Long press the button A, release after the 2nd "Beep" sound and hear "Master Mode". Master Release Beep, Beep Mode Set as Remote (Previous firmware)：... -
Page 7: Pairing/Unpairing
3. Pairing/Unpairing *Ensure all headsets have the same firmware, or the pairing will not be successful. *The previous firmware supports group communication with up to 5 people, while the new firmware supports group connections with up to 13 people. 3.1 If Pair ≤ 5 headsets 1) Set a Master and 1~4 Remote/Level 1. - Page 8 3.2 If Pair 6~13 headsets 1) Set a Master, 4 Level 1 and 1~8 Level 2. Level 1 Pairing Master Mode Level 2 Pairing 2) Long press the button A on Master and 4 Level 1 in 1 min, release after the 1st “Beep” sound, and hear "Connecting and Pairing".
- Page 9 Level 2 Level 2 Level 1 Level 1 Level 2 Level 2 Master Level 2 Level 2 Level 1 Level 1 Level 2 Level 2 * A Master can connect up to 4 Level 1, and a Level 1 can connect up to 2 Level 2. * The Level 2 must be paired with the Level 1 before it can connect to the Master.
-
Page 10: Group Management
4. Group Management You can divide an Xtalk system into independent groups or merge multiple groups into one single group. 4.1 Divide Into Groups 1)Set the required number of Master based on the planned group count (see 2. Master Settings). - Page 11 4.2 Combine Into One Group 1) Only keep one Master, and set the other headsets as Level 1 and Level 2 if needed. (See 2. Master/Remote/Level 1/Level 2 Settings). 2)Pair all headsets and restart (see 3. Pairing/Unpairing). Combine 2 groups(A 2-Person Group and A 9 Person Group) into 1 group 1)Keep 1 Master, set 4 Level 1 and 6 Level 2(See 2.
-
Page 12: Volume Settings
5. Volume Settings Short press the volume up/down button to increase/decrease the volume. 6. Noise Cancellation Short press the B button to turn on/off the noise cancellation feature. 7. Mute/Unmute Rotate the boom arm up/down (see the picture below) to mute/unmute. Mute Unmute Unmute... -
Page 13: Boost Mode 1
Boost Mode 1 Boost Mode 2 10. Real-Time Monitoring Connect the device(Camera, Camcorder, etc.) with the Xtalk headset via 3.5mm TRS port for monitoring the audio from the device. *This port is only for monitoring and is not the outputting port. -
Page 14: Indicator Light Status
Red Light Steady Charging 13. Firmware Update 1. Connect the Xtalk headset to the PC using a USB C data cable and power on the Xtalk. 2. Long press Volume+ and Volume- for 10s until you hear the “BeepBeep” sound twice. -
Page 15: Specifications
Specifications Wireless Technology Digital 2.4GHz Transmission Mode Full-Duplex Operating Range 350m (LOS) Frequency Band 2.4GHz Latency About 120ms Approximate RF Sensitivity <-90dBm Radio Output Frequency 20dBm Power USB-C 5V Battery Capacity 1050mAh Li-ion Battery Working Time Charging Time About 2.5H Frequency Response 150Hz~7KHz Signal-To-Noise Ratio... -
Page 16: Packing List
Packing List Headset x1 Charging Cable Carrying Rechargeable Bagx1 Battery x1 One-Ear Foam Mic Windshield Warranty Cushion x1 Card x1 Headset x2 Charging Cable Carrying Bag Charging Station x1 One-Ear Foam Mic Windshield Warranty Card Rechargeable Cushion x2 Battery x2 www.syncoaudio.com... - Page 17 Headset x5 Storage Bag x1 Charging Station Charging Carrying Cable x3 Bag x5 Rechargeable One-Ear Foam Mic Windshield Warranty Battery x5 Cushion x5 Card x1 Headset x9 Storage Bag x1 Charging Station Charging Carrying Cable x5 Bag x9 Rechargeable One-Ear Foam Mic Windshield Warranty Battery x9...
- Page 18 30 days upon receipt of the product. 2. Original SYNCO products are entitled to 12-month limited warranty service. The warranty period begins on the date of purchase of brand new, unused products by the first end-user.
- Page 19 2. Please retain your sales receipt and warranty certificate as proof of purchase. If any of these documents is missing, only sales return or chargeable service will be provided. 3. If the SYNCO product is out of the warranty coverage, the service and the parts cost will be charged.
- Page 20 Guangzhou Zhiying Technology Co., Ltd Room 2401, 24 / F, South Tower, Lisheng Plaza, No. 68 Huadi Avenue, Liwan District, Guangzhou, China, 510000 support@syncoaudio.com www.syncoaudio.com https://www.facebook.com/syncomicrophones...
