APPLICATION GUIDE
FRONIUS Primo/Symo GEN24 & GEN24 Plus
series
PV Point and PV Point Advanced setup
(Australia & NZ Only)
Fronius reserves all rights, in particular rights of reproduction, distribution and translation.
No part of this work may be reproduced in any way without the written consent of Fronius. It must not be saved, edited, reproduced or distributed
using any electrical or electronic system. You are hereby reminded that the information published in this document, despite exercising the greatest
of care in its preparation, is subject to change and that neither the author nor Fronius can accept any legal liability
Gender-specific wording refers equally to female and male form.
Advertisement
Table of Contents
Related Manuals for Fronius Primo GEN24 Series
Summary of Contents for Fronius Primo GEN24 Series
- Page 1 Fronius reserves all rights, in particular rights of reproduction, distribution and translation. No part of this work may be reproduced in any way without the written consent of Fronius. It must not be saved, edited, reproduced or distributed using any electrical or electronic system. You are hereby reminded that the information published in this document, despite exercising the greatest of care in its preparation, is subject to change and that neither the author nor Fronius can accept any legal liability Gender-specific wording refers equally to female and male form.
-
Page 2: Table Of Contents
Contents Change Log ........................... Error! Bookmark not defined. General PV Point: ................................. 3 PV Point Advanced: ............................... 4 Technical characteristics for PV Point / PV Point Advanced: ................4 System Components ................................5 Installation: ..................................... 6 GEN24 preparation: .............................. 6 PV Point: ................................. -
Page 3: Change Log
GENERAL PV Point: The Fronius GEN24 PV Point / Opportunity Power (OP) function is a separate AC power output on the inverter that can provide single phase power during a grid outage. PV Point can source this power from the present solar power or stored power in the PV battery (a battery unit is not necessary for the operation of PV Point). -
Page 4: Pv Point Advanced
The functional diagram of the PV Point is shown in Figure 1: Figure 1: Schematic of the basic PV Point power supply of the Fronius GEN24 & GEN24 Plus series PV Point Advanced: The “PV Point Advanced” solution uses the existing PV Point function with a 3 party changeover relay allowing backup loads to be powered by the grid until a blackout occurs. -
Page 5: Operational Information
• done. System Components The following component groups are required as part of the system: For PV Point you only require a Fronius inverter: Fronius Primo/Symo GEN24 or GEN24 Plus − IMPORTANT: Remember to update your inverter with the latest firmware available prior to operating this feature. -
Page 6: Installation
GEN24 series with the outputs is shown in Figure 2: Figure 2: Inverter underside of the Fronius GEN24 & GEN24 Plus series with the four predefined outputs (11). The first step is to drill a hole through one of the four outlets on the base shell. We recommend using a step drill (M16 / 16 mm diameter) for this.:... -
Page 7: Pv Point
No special tools are required to install the PV Point and no ferrules need to be fitted to the cables. Fronius recommends the use of a copper cable with a cable cross-section of min. 1.5 mm² to max. 10 mm² for direct connection. Figure 5 shows the requirements for the cable Figure 5: Push-in spring clamp and cable requirements for installing the PV Point Application Guide –... -
Page 8: Wiring Examples (Pv Point And Pv Point Advanced)
Wiring Examples (PV Point and PV Point Advanced): Figure 6 shows a technical application of PV point powering a GPO. PV Point Concept Diagram: Figure 6: Technical diagram of PV Point Note: Devices shown in this diagram are for orientation only. Local site conditions and constraints are to be considered by qualified personnel designing and/or installing the equipment. -
Page 9: Installation Notes (Pv Point And Pv Point Advanced)
Installation Notes (PV Point and PV Point Advanced): PV Point/PV Point Advanced is to be wired as an ‘Alternative Supply’ in accordance with • AS4777.1:2024. PV Point/PV Point Advanced is not a ‘Substitute Supply’. Application of PV Point may require enclosures containing an Earth bar & a Neutral bar. These •... -
Page 10: Pv Point Advanced Concept Diagram
1.1.1 PV Point Advanced Concept Diagram: Application Guide – PV Point and PV Point Advanced v3.0 10/27... -
Page 11: Table Of Wiring Examples For Pv Point Or Pv Point Advanced
1.1.2 Table of wiring examples for PV Point or PV Point Advanced: Example Installation Type 1Φ/3Φ Example Manual Bypass switch PV Point 1Φ Not Applicable PV Point with 1Φ Manual Changeover PV Point Advanced 1Φ (Automatic Changeover) PV Point Advanced 1Φ... -
Page 12: Example 1: Pv Point With A Gpo (Primo)
1.1.3 Example 1: PV Point with a GPO (Primo) Application Guide – PV Point and PV Point Advanced v3.0 12/27... -
Page 13: Example 2: Pv Point With Manual Changeover (Primo)
1.1.4 Example 2: PV Point with Manual Changeover (Primo) Application Guide – PV Point and PV Point Advanced v3.0 13/27... -
Page 14: Example 3: Pv Point Advanced (Automatic Changeover) With Bypass Switch (Primo)
1.1.5 Example 3: PV Point Advanced (Automatic Changeover) with Bypass Switch (Primo) Application Guide – PV Point and PV Point Advanced v3.0 14/27... -
Page 15: Example 4: Pv Point Advanced (Automatic Changeover) With Gpo Without Bypass (Primo)
1.1.6 Example 4: PV Point Advanced (Automatic Changeover) with GPO without Bypass (Primo) Application Guide – PV Point and PV Point Advanced v3.0 15/27... -
Page 16: Example 5: Pv Point Advanced (Automatic Changeover) Without Gpo/Bypass (Primo)
1.1.7 Example 5: PV Point Advanced (Automatic Changeover) without GPO/Bypass (Primo) Application Guide – PV Point and PV Point Advanced v3.0 16/27... -
Page 17: Example 6: Pv Point Advanced (Automatic Changeover) With Bypass Switch (Symo)
1.1.8 Example 6: PV Point Advanced (Automatic Changeover) with Bypass Switch (Symo) Application Guide – PV Point and PV Point Advanced v3.0 17/27... -
Page 18: Example 7: Pv Point Advanced (Automatic Changeover) With Gpo Without Bypass (Symo)
1.1.9 Example 7: PV Point Advanced (Automatic Changeover) with GPO without Bypass (Symo) Application Guide – PV Point and PV Point Advanced v3.0 18/27... -
Page 19: Example 8: Pv Point Advanced (Automatic Changeover) Without Gpo/Bypass (Symo)
1.1.10 Example 8: PV Point Advanced (Automatic Changeover) without GPO/Bypass (Symo) Application Guide – PV Point and PV Point Advanced v3.0 19/27... -
Page 20: Commissioning
(mobile, laptop, etc...) to this network to access the local web interface. Figure 9 shows the LED communication interface with its functions: Figure 8: Opening the local network (Wifi access point) of the Fronius GEN24 or GEN24 Plus inverter series and description of the functions of the LED patterns The communication light will flash blue and the connection to the inverter (via app or WLAN/LAN) can be established. -
Page 21: Activation Of Pv Point During Initial Commissioning
Activation of PV Point during initial commissioning: The PV Point can be activated during initial commissioning in the commissioning wizard under the "Product Wizard" in the "Functions and I/Os" menu item. Here it is important to activate the basic backup power function and the "PV Point" mode. This selection applies to both PV Point and PV Point Advanced. - Page 22 Figure 10: Activation of the PV Point in the web interface retrospectivley. After successful installation and commissioning, Fronius recommends a functional test of the PV Point/ PV Point Advanced, The switching time is less than 23 seconds. Application Guide – PV Point and PV Point Advanced v3.0...
-
Page 23: Appendix
Appendix 2.5.1 Additional Notes related to installation: Any specific current ratings that are seen in example photos should be ignored as they must • be selected in accordance with your specific installation requirements. Please note that PV Point loads being switched by the changeover relay back to the grid would •... -
Page 24: Installation Examples (Referenced To Above Wiring Drawings)
2.5.2 Installation Examples (referenced to above wiring drawings): Example 1: PV Point with a GPO (Primo) Example 1.1: PV Point with a GPO (outside the DB) (Primo) In this example the GPO is located outside & adjacent to the Inverter AC Isolator and RCBO for the GPO. - Page 25 Example 5: PV Point Advanced (Automatic Changeover) without GPO/Bypass (Primo) Example 7: PV Point Advanced (Automatic Changeover) with GPO without Bypass (Symo) Application Guide – PV Point and PV Point Advanced v3.0 25/27...
- Page 26 · Any party placing reliance on information contained in this document does so at their own risk. in no event shall fronius be liable for any liability (direct or indirect) for any injury, loss, claim, damage or any incidental or consequential damages, including but not limited to lost profits or savings, arising out of or in any way connected with the use of any information, or any error, omission or defect in the information, contained in this document.
- Page 27 END OF DOCUMENT Fronius Australia Technical Support Email: PV-Support-Australia@fronius.com Phone: 03 8340 2910 For more detailed information see the operation manual available on the product specific page on here. Application Guide – PV Point and PV Point Advanced v3.0 27/27...
