Summary of Contents for YORKVILLE LP-LED2X
- Page 1 * L P - L E D 2 X n o t s h o w n ( L P - L E D 2 X h a s 2 p o d s i n s t e a d o f 4 ) . LP-LED2X REV2 + LP-LED4X REV3...
-
Page 2: Important Safety Instructions - English / Français
Important Safety Instructions - English / Français I MP OR TA N T S A FE T Y I N ST R U C TI O N S This lightning flash with arrowhead symbol, within an The exclamation point within an equilatereal triangle is intended to alert the user to the presence equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous of important operating and maintenance (servicing) instructions in the literature accompanying voltage”... -
Page 3: Table Of Contents
Montage ................6 Table of Contents ..............ii Utilisation de LP-LED/X Multiples ........6 LP-LED2X & LP-LED4X............. 1 Sélecteur 1,2 / 3,4 du LP-LED2X ........6 Function and Stand Alone Operation ......1 Consommation Électrique ..........6 Bluetooth™ Smart Device ..........2 Contrôleurs d’Éclairage LP-C4 et LP-C12 de Yorkville ... -
Page 4: Lp-Led2X & Lp-Led4X
3. With a Yorkville Lighting Controller. The Yorkville Sound LP-C12 controller allows for more functionality than the LP-LED/X Bars on their own. The older Yorkville Sound LP-608 can also be used but has limited functionality (see more detailed description below). -
Page 5: Bluetooth™ Smart Device
S t a g e L i g h t i n g Bluetooth™ Smart Device You must install the Yorkville LP Control App on your smart device prior to use. The App is available on the Apple App Store and the Google Play Store. -
Page 6: Using Multiple Lp-Led/Xs
LP-LED2X 1,2/3,4 Switch The LP-LED2X has 2 light pods but the Yorkville lighting controllers such as the LP-C4 or LP-C12 use a 4 chan- nel signal. The 1,2/3,4 switch selects which 2 of the 4 channels the bar responds to. -
Page 7: Lp-Led2X & Lp-Led4X
LP-LED2X & LP-LED4X. Les LP-LED2X et LP-LED4X de Yorkville Sound sont des systèmes d’éclairage compacts et puissants. Le LP- LED2X se compose de 2 pods d’éclairage (LP-LED4X en a 4) sur une base pouvant être montée sur support. La barre abrite les contrôles de l’utilisateur, des connecteurs pour un contrôleur indépendant, le bloc d’alimentation, et diverses options de montage. -
Page 8: Dispositif Intelligent Bluetooth
S t a g e L i g h t i n g Dispositif Intelligent Bluetooth™ Avant de l’utiliser vous devez installer l’application Yorkville LP Control sur votre smart device. L’application est disponible sur l’App Store d’Apple et le Google Play Store. -
Page 9: Montage
Sélecteur 1,2 / 3,4 du LP-LED2X Le LP-LED2X a 2 pods d’éclairage, mais les contrôleurs d’éclairage Yorkville tels que le LP-C4 ou LP-C12 uti- lisent un signal à 4 canaux. Le sélecteur 1,2 / 3,4 sélectionne à quels 2 des 4 canaux la barre répond. -
Page 10: Specifications - English / Français
DMX: Standard Shielded 3-pin XLR Cable Other Dimensions (LWH) LP-LED2X: 24 x 4.8 x 8 inches (61 x 12.25 x 20.4 cm) LP-LED4X: 31 x 4.8 x 8 inches (78.8 x 12.25 x 20.4 cm) Weight LP-LED2X: 9.5 lbs (4.3 kg) LP-LED4X:14.6 lbs (6.6 kg) -
Page 11: Diagram - Audio In / Entrée Audio
(Optional / Optionnel) Brightness Function Lamp Color FOR CONNECTING TO A FOR CONNECTING TO A YORKVILLE CONTROLLER YORKVILLE CONTROLLER Audio IN DMX OUT DMX IN • DO NOT CONNECT TO DMX • • DO NOT CONNECT TO DMX • Mode... -
Page 12: Diagram - Stand Alone / Utilisation Autonome
LP-LED4X #1 Sortie Brightness Function Lamp Color FOR CONNECTING TO A FOR CONNECTING TO A YORKVILLE CONTROLLER YORKVILLE CONTROLLER Audio IN DMX OUT DMX IN • DO NOT CONNECT TO DMX • • DO NOT CONNECT TO DMX • Mode... -
Page 13: Dmx Modes - English
DMX Modes - English LP -LED/X/M DMX™ Modes for the LP-LED Bars Set unit to off position to in order to access DMX. Specific operating instructions for the DMX™ modes are available in the specific DMX™ controller operation manual. For specific LP-LED Bar DMX™ modes see addendum at the end of the manual. Mode Address Mode... - Page 14 LP -LED/X/M Mode Address Mode Address Mode 4 - 32 DMX™ Channels Mode 5 - 16 DMX Channels Dip Switch #10 and #11 set to ON) Dip Switch 12 Up from the Right Only) CH 1 – Red for Pod 1 CH 1 –...
-
Page 15: Dmx Modes - Français
DMX Modes - Français LP -LED/X/M Modes DMX™ Pour Les Barres LP-LED Mettez l’appareil en position off pour accéder au DMX. Des instructions d’utilisation spécifiques pour les modes DMX™ sont dis- ponibles dans le manuel d’utilisation spécifique du contrôleur DMX™ DMX™. Pour les modes LP-LED/X/M Bar DMX™ spécifiques, voir l’additif à... - Page 16 LP -LED/X/M Mode Address Mode Address Mode 4 (32 canaux DMX™ Mode 5 (Occupe 16 canaux DMX™ Les Commutateurs Dip #10 et #11 Réglés à ON) Le Commutateurs Dip # 12 Réglé à ON, de la Droite Seulement C 1 – Rouge pour Pod 1 C 1 –...
-
Page 17: Tripod Mount - English / Français
Tripod Mount - English / Français LP-LED Mounting Instructions for Tripod Speaker Stand 1. Déployez complètement les pieds du 1. Fully extend the tripod legs for trépied pour une stabilité maximale. maximum stability. 2. Positionnez les unités LP-LED aux 2. Position the LP-LED unit/s at de- positions désirée sur les poteaux sired positions on poles and use et utilisez des vis à... -
Page 18: Convenience Receptacle - English
P o w e r R e c e p t a c l e The LP-LED2X and LP-LED4X provide a convenience outlet which can minimize wiring and improve overall safety when used properly. Please carefully read all of the important safety tips shown below for long and safe use of your lighting equipment. -
Page 19: Convenience Receptacle - Français
P o w e r R e c e p t a c l e Les LP-LED2X et LP-LED4X proposent une prise de courant de commodité qui peut réduire le câblage et accroître la sécurité générale lorsqu’elle est utilisée correctement. Veuillez lire attentivement tous les conseils de sécurité... - Page 20 LP -LED/X S t a g e L i g h t i n g...
-
Page 21: Warranty - English / Français
Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge. -
Page 22: Rear Page
WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Limited Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W 3Y8 CANADA 14305, USA Voice: 905-837-8481 Voice: 716-297-2920 Fax: 905-837-8746 Fax: 716-297-3689 Manual-Owners-LP-LED_X-00-2v0 • Mar 7, 2025...
