- Page 1 NVS-IP100016SP IP/SIP POE Wall mount Speaker User Manual www.nordencommunication.com...
- Page 2 www.nordencommunication.com...
-
Page 3: Table Of Contents
Contents Product Overview....................3 • Description......................3 • Features......................3 Hardware Interface Introduction………..............4 Basic Network Setting…………………….……………………………………………………………..……...4 • Terminal devices configuration tool……………………………………………………………..…4 • Web page mode…………………………………………………………………………………..…………5 User-Define Terminal Parameters………………………………………………………………………….6 • Login Webpage……………………………………………………………………………………..……….6 • Running Status……………………………………………………………………………….………………7 • Network Parameters…………………………………………………………….………………………..7 • Server Parameters………………………………………………………………………………………….8 • Audio Parameters…………………………………………………………………………………………11 •... -
Page 4: Product Overview
Product Overview Description The NVS-IP100016SP is an IP/SIP Wall mount Speaker, which can be powered via PoE. It supports common network protocols for easy integration with SIP compatible VOIP system. The speaker can be configured from user friendly browser interface. -
Page 5: Hardware Interface Introduction
Hardware Interface Introduction 1. Network interface To the switch or POE switch insert a cable. 2. Power interface DC24V/1A, supply for the IP wall mounted speaker. (The device supports POE, need no more power supply if the network interface is already connected with POE switch.) 3. -
Page 6: Web Page Mode
(2) Configure the terminal's IP network information. Method 1: Check the designated terminal and click "Terminal Configuration"- "Parameter Configuration" to configure IP network information for the terminal. Method 2: If the scanning tool does not scan the terminal, you can click "Advanced" to perform mandatory IP configuration. -
Page 7: User-Define Terminal Parameters
The specific operation steps refer to the network parameters settings in the user- define terminal parameters. User-Define Terminal Parameters Login Webpage 1. Please enter the IP wall mounted speaker column IP address to the browser address column (the factory default IP address is 192.168.1.101), then enter. 2. -
Page 8: Running Status
3. Press login to enter to the Network Wall Mount Speaker web page. (Note: If the relevant parameter modification in the web page does not take effect after saving, please clear the cache and set them again.) Running Status When login to the web page, click “Running Status”, it will show the information of: Terminal ID, server IP, server port, device task status, MAC address,terminal IP address, gateway and other information. -
Page 9: Server Parameters
Parameters as following: IP Address The IP address of the device, the factory default IP is 192.168.1.101, which cannot be duplicated with other terminals. Subnet Mask The subnet mask of the LAN network. Default The gateway of the network. Gateway Primary DNS The IP address of the preferred DNS server (domain name resolver) of the network. - Page 10 The relevant Settings are as follows: Setting the protocol for normal communication between Transport Protocol device and sever. IP address of the SIP server that the terminal logs into. Please SIP Server IP, port enter the correct IP address of the SIP server. The port number cannot be changed except in special cases.
- Page 11 NAS Protocol The relevant Settings are as follows: Setting the protocol for normal communication between Transport Protocol device and sever. Unique number to identify the terminal and cannot be Terminal ID duplicated with terminals or other hosts. Configure the local port according to the actual situation; Local Port the default is 5060.
-
Page 12: Audio Parameters
Audio Parameter Set the audio related parameters of the device, Click on [save] after setting, the parameters will take effect after reboot. The relevant Settings are as follows: Broadcast Output The total volume of audio input by the device during Volume broadcasting, range: 0-15. -
Page 13: Alarm Options
You can set the “line input threshold” through “Line Input Calibration” Line input threshold button below “system settings”. Enable or disable the Ambient Noise Controller (ANC) feature. The Unit will adjust the output volume according to the ambient noise level. Linear and Disperse are optional. -
Page 14: Multicast
The relevant Settings are as follows: Set the trigger action when closing alarm input1/input2 port. Input1/Input2 Audio File: Trigger playback of selected file (Task ID). Action Call: Trigger a call to prescribed call target. Input1/Input2 Select the input1/Input2 signal mode. Level and Edge are Signal Mode optional. - Page 15 Parameters as following: Set whether to enable multicast function or not. In the case where there are multiple servers in the LAN, different servers must fill in different addresses and port Multicast function numbers when they initiate multicast broadcasts without interference.
-
Page 16: Onvif Parameter
Onvif Parameter Set the onvif related parameters of the device, Click on [save] after setting, the parameters will take effect after reboot. Parameters as following: Onvif Protocol Set whether to enable Onvif pulling stream function. ONVIF Username If it is enabled, please set the onvif username and password. ONVIF Password Onvif Control Port Set the Onvif control port, the default is 9090. -
Page 17: Broadcast Task Priority
Parameters as following: Push Timing Task The SDK Control: Push by the audio file upload tool. It pushes the task ID on the audio file upload tool to the Unit through http, and it can be used in serverless situations. Regular Perform: Pushing timing task through server. -
Page 18: System Settings
System Settings Reboot: Click on this button will reboot the device. Default: Click this button and all parameters of the device will be restored to factory Settings (please use with caution) Delete: Click on this button will delete all offline audio files, make sure there is no audio output when deleting. -
Page 19: Time To Restart
Time To Restart After this function is enabled, you can set the time for restarting the device every day. The default value is disable. Protocol Settings FTP: Set whether to enable FTP remote file transfer function. The default value is disable. -
Page 20: Power Settings
Power Settings Set the power settings of the device, Click on [save] after setting, the parameters will take effect after reboot. Parameters as following: Power Supply Select the power supply mode, support POE, POE+ and DC. Mode Output Power Support 15W, and 20W. www.nordencommunication.com... -
Page 21: Time Settings
Note: In POE power supply mode, only support select 15W. In POE+ and DC power supply mode, support select 15W and 20W. Time Settings Time Zone: set the time zone of the device. NTP Server: Fill in the NTP server of the device. Click on [save] after setting, the parameters will take effect after reboot. -
Page 22: Upgrade
Upgrade Software Version: The current firmware version of the device. Click on "Upgrade" button, you will enter the firmware upgrade mode after 15 seconds. Click on "Select file", select the upgrade file provided by the manufacturer, and click "Start upload" to start the upgrade. Note: Do not power off during the upgrade process, otherwise the upgrade may fail and the device fails. -
Page 23: System Logs
System Logs Network Wall Mount Speaker can automatically record the running process and generate logs, and support users to download system logs. www.nordencommunication.com... -
Page 24: Troubleshooting
Troubleshooting Why is the terminal still "offline"? 1). Check the software server and the main controller is opened or not. It`s required to close all firewall before opening the software server (including system built-in firewall and other antivirus software firewall) . 2).
