- Page 1 NVS-10390040CS 40W COAXIAL CEILING SPEAKER WITH MULTIPLE POWER TAP OPTION User Manual www.nordencommunication.com www.nordencommunication.com...
- Page 2 www.nordencommunication.com...
-
Page 3: Table Of Contents
Contents Product Overview………………………………………………………………………………………………….3 • Description ……………………………………………………………………………………………………3 • Features…………………………………………………………………………………………………………3 Product Dimension…………………………………………………………………………………..……………3 Installation Instructions…………………………………………………………………………………………4 Technical Parameters…………………………………………………………………………………………….5 Specifications…………………………………..…………………………………………………………………...6 www.nordencommunication.com... -
Page 4: Product Overview
Product Overview Description The NVS-10390040CS is a Ceiling Speaker and it can be switched between the ohms terminal 8 Ω and the voltage terminal 70/100V. The built-in 6.5" speaker driver has a wide frequency response range of 50Hz to 20kHz. It is made of high-quality ABS material, which assure a long-term durability and never out of shape and it will not color fade. -
Page 5: Installation Instructions
Installation Instructions Pull the net by the net hook (Figure ①). Cut an Ø200mm installation hole on ceiling by the cutout template we sent (Figure ②). Pass public address wire through the wire-protecting pipe to connect speaker’s terminal, then fix up the strain relief fitting and the terminal cover plate (Figure ③). -
Page 6: Technical Parameters
Push the speaker into the installation hole and turn the installing screw to fix up the speaker on ceiling (Figure ⑥). Push the net into the plastic panel. Adjust the direction of set and examine whether it is steady. Technical Parameters www.nordencommunication.com... -
Page 7: Specifications
Specification Model NVS-10390040CS Rated power Driver Size 6.5” X 1, 1 ” X 1 Frequency Response 50Hz-20kHz Power Taping Options 6/10/20/40W Input Voltage/Impedance 70 & 100V/4-16Ω Coverage Angle 150° Input Connectors Spring loaded terminal Sensitivity (1m,1w) 91dB±2dB Maximum SPL (1m) 107dB±2dB...
