- Page 1 NVS-IP100020SP IP/SIP Column Speaker 120W User Manual www.nordencommunication.com...
- Page 2 www.nordencommunication.com...
-
Page 3: Table Of Contents
Contents Product Overview………………………………………………………………………………………………….3 • Description……………………………………………………………………………………………………..3 • Features………………………………………………………………………………………………………….3 Hardware interface introduction……………………………………………………………………………4 User-defined web page settings…………………………………………………………………………….4 • Login web interface………………………………………………………………………………………..4 • System Tools…………………………………………………………………………………………………..5 • Protocols………………..………………………………………………………………………………………6 • Network Parameters………………………………………………………………………………………6 • Sip parameters……………………………………………………………………………………………….7 • Server parameters………………………………………………………………………………………….8 • Audio parameters…………………………………………………………………………………………10 • Priority of local task………………………………………………………………………………………12 •... -
Page 4: Product Overview
Product Overview Description The NVS-IP100020SP is an IP based column loudspeaker with an IPX5 rating that may be utilize outside for applications such as public address, music streaming, pre- recorded message transmission, and scheduled announcements. It's best used in parks, playgrounds, and outdoor plazas. It is an all-in-one design, integrated with network audio decoding, digital amplifier and loudspeaker unit. -
Page 5: Hardware Interface Introduction
Hardware Interface Introduction 1. Power supply interface AC220V 2. Network interface Plugging network cable and connecting to switch. Note: This icon means weephole, please do not cover or block it. User-defined web page settings Login web interface (1) Use a web browser and navigate to the IP address of the SIP Column Speaker (factory default is http://192.168.1.101), then press Enter. -
Page 6: System Tools
（3）After pressing Enter, you will arrive in the configuration web page of the SIP Column Speaker. (Note :After saving the parameters in web page , if it doesn't take effect , please clear your browser caches , then re-configuring it ) System Tools In this window , user can check device ‘s ID, IP address , subnet mask etc.. -
Page 7: Protocols
Protocols SIP Column Speaker support NAS Protocol and Standard SIP protocol ( the default is SIP protocol) . Please select the protocol correspond to the type of software which device will log in . After saving , please clear the browser cache and restart the browser to let it take effect.(Note : Choosing different protocol will have different options at left side) Network Parameters... -
Page 8: Sip Parameters
The parameters are as following： Device IP Address (Default: 192.168.1.101, Must Be Device IP Unique and Not Repeated by Other Devices) Subnet mask The subnet mask of the LAN network Default gateway The gateway of the network Preferred DNS IP address of the preferred domain name resolver on the server network Alternate DNS... -
Page 9: Server Parameters
The parameters are as following： SIP Address of the Device: Do Not Modify the SIP Server SIP Server Port Unless Necessary (Default Port: 5060) SIP Account of the Device (Must Be Unique and Not Account Repeated by Other Devices) The password of the device when logging in the SIP Password server. - Page 10 User can enable or disable FTP function. When enabled FTP function, user can use FTP to update the offline tasks automatically. Note: When user use Norden software to push offline tasks, then need to close FTP function. Method of Users Can Log in Using a Username and Password, or Log in Login Directly Without Entering Any Information.
-
Page 11: Audio Parameters
(Note: All Terminals Must Use NAS Protocol to Log in to the Software). Audio parameters The parameters are as following： Local sound Finished products do not have a line-in interface and this volume function is reserved. Range from 0-15 Offline speaker broadcast Note: when speaker are online , volume will be controlled by volume... - Page 12 Problem, Such as a Faulty Speaker Unit or Cable, the Device Will Self-Detect and Feedback the Issue to the Server. After Enabling, the SIP Column Speaker Can Automatically Adjust the Broadcasting Volume Based on the Noise Level. Dynamic For Example: If Nearby Noise Exceeds the Referenced Noise volume Value and the Noise Detection Correction Value, the adjustment...
-
Page 13: Priority Of Local Task
Note: We recommend selecting 'Low Band' for higher complete audio data, and 'Proper Delay' for synchronous broadcasting. Receiver The Volume of the Receiving Microphone Broadcast Can Be Microphone Properly Attenuated (1dB, 2dB, 3dB, or 4dB) to Prevent Radio Volume Sound Distortion from Excessive Volume. The Default Tuning Setting is No Adjustment. -
Page 14: Password Modification
Password modification You can change the web page login-in account and password here, it will be effective after clicking on “Save”. Upgrade the firmware (Note: please do not upgrade the firmware without any special needs) Click “System Tools” and “Upgrade Firmware” to enter the firmware upgrade page. (If you encounter an abnormal web page when entering upgrade mode, please clear all browser cache and then re-login to the web page.) After Successfully Selecting the Correct Firmware Provided by the Factory, Click... -
Page 15: Reset To Defaults
Upgrade to Fail). Then click reboot and back to normal settings. Reset to Defaults Reset to defaults: when all parameters need to be reset to defaults Restart device Restart the device Note: all the modified parameters on the web page will be effective after restarting the device. -
Page 16: System Log
System log The logfile contains all system events of SIP column speaker. Basic functions Receive Broadcast Supports Receiving Broadcasts Initiated by the Server or Other Terminals. Offline Broadcast SIP Column Speaker Supports Offline Broadcast. When the Device Is Offline, the Terminal Can Play On-Time Ring Bell Tasks Set Up by the Server. - Page 17 Time and Schedule Type, or Set the Terminal ID and File in the Add Operation Interface, etc. 2）After click save, then click push task icon in the left bottom. Notes: offline broadcast only support MP3 format audio. Steps under NAS software 1）Setting “time ring bell”...
-
Page 18: Receive Monitor
3）Access to terminal FTP:// terminal IP(the defaults user name and password is admin), put the exporting timing ring bell document to “NAS2007” under FTP (note :If there is no folder named as NAS2007 ,please create a new one ), It will be effective after rebooting the device. -
Page 19: Troubleshooting
Troubleshooting Terminal cannot login to the server? 1. Check if the server software and main control computer are properly running. Ensure that all firewalls (including system firewalls and antivirus software) are disabled before opening the service software. 2. Check whether the network connection is normally working or not. 3.
