- Page 1 Installation Guide Mirrored Cabinet K-3091 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1” 1012595-2-A...
-
Page 2: Tools And Materials
Tools and Materials Thank You For Choosing Kohler Company We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems, please don’t hesitate to contact us. Our phone numbers and website are listed on the back cover. - Page 3 • (6) polyset anchors • (6) #10 x 2” screws • (10) #10 x 1/2” screws Model K-3091 does not include end caps; you need a separate end cap kit for this model. Establish and install all plumbing rough-ins in the correct location before beginning installation of the mirrored cabinet.
- Page 4 Make sure the shutoff valves are located in the lower designated section of the cabinet (rough-in location). NOTE: Do not install the finished wall until all braces have been installed and all plumbing rough-ins have been completed. Complete the finished wall. 1012595-2-A Kohler Co.
-
Page 5: Assemble The Cabinet
These are used to secure the connectors and side kits. Use two connecting blocks for each cabinet addition. Assemble the cabinet to the connecting blocks from the inside of the cabinet with #10 x 1/2″ thread cut screws. Kohler Co. 1012595-2-A... - Page 6 Use the #10 x 2″ pan head thread cut screws (supplied) to secure the “Z” mounting bar to the wall. Locate the three top clips for the cabinet and slide the clips into the groove located in the channel on the top side of the cabinet. 1012595-2-A Kohler Co.
- Page 7 Fasten the clips securely using #10 x 2″ screws. Attach the black door latch with the screw and acorn nut to the pre-drilled hole on the bottom of the cabinet. Kohler Co. 1012595-2-A...
- Page 8 Partially drive four #10 x 1-1/4″ screws (provided) through the inside location holes, through the spacer block holes, and into the end caps. Tighten the screws to secure the end caps. Install the dome cap covers over the screw heads. 1012595-2-A Kohler Co.
-
Page 9: Install The Door
If the door opens swiftly, squeaks or rubs against the gasket, adjust the door outward with screw #3. Check the door swing. The hinges are provided with a 110° black plastic stop to restrict the door from swinging wide. Kohler Co. 1012595-2-A... -
Page 10: Complete The Installation
Turn the supplies on and check for leaks. Flush water through the lines to remove debris. Attach the water line to the spout assembly. Conduct a final check for leaks. Tuck the hoses back into the cabinet. Be careful not to kink the hoses. 1012595-2-A Kohler Co.
