Miniatures 42006 Step By Step Assembly Instructions

#42006 Loft Apartment Kit
Step-by-step assembly instructions
Copyright miniatures.com 2024
PARTS:
Foundation
Second Floor
Large Window Wall
Arch Wall
Solid Wall
Door Wall
Small Window Wall
Gap Filler
Door with trim
6-Light Window
6-Light Window Trim
6-Light Window Acrylic Pane
30-Light Window
30-Light Window Trim
30-Light Window Acrylic Pane
SUPPLIES NEEDED:
Masking tape
White glue (such as #1249 Weldbond)
Damp clean cloth
Exterior and interior finishes
Assembly Instructions
Tip: Plan the finishes for the interior and exterior at the
dry-fit stage, before final/permanent assembly. It is
easier to finish the panels as flat surfaces. Disassemble
and finish as desired, then reassemble using glue.
Shell
Place the Foundation
1.
flat on the work surface.
2. Glue the Arch Wall and
the Solid Wall into their
respective grooves and
to each other. They are
flush along the corner.
The Solid Wall is slightly
taller. The arch can be
placed at the left or right.
3. Glue the Gap Filler into the groove on the floor in the
arch opening.
2388 Pleasantdale Road, Atlanta, GA 30340 • 1.800.926.6464 • www.miniatures.com • Made in Thailand
GENERAL INSTRUCTIONS
• Identify and inspect all parts using the Parts List and Parts Diagram.
• Read the directions completely before beginning the project.
• If possible, have a dedicated work area so that you are not
unpacking, repacking, and moving the project from place to place.
• Choose a work surface that is level, clean, dry, and protected from
glue spills.
• Do a dry fit, using masking tape to hold parts in place, to make sure
everything fits together correctly before assembling permanently.
4. Glue the Second Floor
to the top of the wall
assembly. Orient it so
that the surface with
the groove and rabbet
faces up. The groove
on its underside
receives the top of
the Solid Wall.
5. Glue the Large
Window Wall to the
assembly. It rests
in the rabbet on
the Foundation. All
joints are flush. The
large window can
be placed on the
first or second level.
Not Suitable for Children
under 15 years old.
0724
