Summary of Contents for COMPANION ROVER 600
- Page 1 ROVER 600/1000/1300 PORTABLE POWER STATION *Rover 1300 shown OWNERS MANUAL Model No. 10001620/10001609/10001610...
-
Page 2: Table Of Contents
CONTENTS Specifications ..........................3 Rover 600 Specifications .....................3 Rover 1000 Specifications ....................4 Rover 1300 Specifications ....................5 Safety Instructions ........................6 What’s In The Box ........................7 Product Details ........................8 Overview ..........................8 LCD Screen ..........................9 Power ON/OFF .........................9 Charging Devices........................10 DC Output ..........................11 AC/DC Lock Mode .......................11... -
Page 3: Specifications
ROVER 600/1000/1300 PORTABLE POWER STATION SPECIFICATIONS ROVER 600 SPECIFICATIONS GENERAL INFORMATION Model Rover Weight Dimensions 315 x 190 x 220mm LED Light 5W LED light - 3 modes (flashlight, SOS, blink) BATTERY SPECIFICATIONS Battery Capacity 560Wh 25Ah @ 22.4V / Equivalent to 43.75Ah @ 12.8V Battery Type LifePo4 Cycle Life... -
Page 4: Rover 1000 Specifications
ROVER 1000 SPECIFICATIONS GENERAL INFORMATION Model No. Rover 1000 Weight 13kg Dimensions 395 x 190 x 220mm LED Light 5W LED light - 3 modes (flashlight, SOS, blink) BATTERY SPECIFICATIONS Battery Capacity 1008Wh 45Ah @ 22.4V / Equivalent to 78.75Ah @ 12.8V Battery Type LifePo4 Cycle Life... -
Page 5: Rover 1300 Specifications
ROVER 600/1000/1300 PORTABLE POWER STATION ROVER 1300 SPECIFICATIONS GENERAL INFORMATION Model No. Rover 1300 Weight 15.2kg Dimensions 395 x 190 x 220mm LED Light 5W LED light - 3 modes (flashlight, SOS, blink) BATTERY SPECIFICATIONS Battery Capacity 1344Wh 60Ah @ 22.4V / Equivalent to 105Ah @ 12.8V Battery Type LifePo4 Cycle Life... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS USAGE 1. Do not use the product near a heat source, such as a fire source or a heating furnace. 2. Use under supervision and in well ventilated spaces. 3. After prolonged high power use, your Rover can run at relatively high temperatures. It is recommended to allow the Rover to cool for up to 30 mins prior to charging. -
Page 7: What's In The Box
ROVER 600/1000/1300 PORTABLE POWER STATION 18. When the power supply is connected in the normal mode to a refrigerator, the power supply may be automatically shut down due to the power fluctuation properties of the refrigerator. If the refrigerator stores medicines, vaccines or other high-value items, it is highly recommended that the AC/DC output is set to “Never Turn Off”... -
Page 8: Product Details
PRODUCT DETAILS OVERVIEW 1. LCD Screen 9. LED Light Switch 2. LCD Display Switch 10. AC Output Switch 3. DC Output Switch 11. 12V DC Charger Outlet 4. USB-C Output Port 12. AC Output Port 5. USB-A Output Port 13. DC Output Port 6. -
Page 9: Lcd Screen
ROVER 600/1000/1300 PORTABLE POWER STATION LCD SCREEN 1. Remaining Battery 7. AC Output 2. Remaining Charge/Dischage Time 8. High Temperature Warning 3. Input Power 9. Fan Indicator 4. Output Power 10. USB Output 5. LED light 11. DC Output 6. Warning POWER ON/OFF POWER ON/OFF 1. -
Page 10: Charging Devices
1. When using the AC output socket, make sure that the total power of all loaded devices is less than the rated power (Rover 600 - 700W / Rover 1000 - 1200W / Rover 1300 - 1200W). 2. After high-power discharge, due to the relatively high internal temperature of the product, even if all... -
Page 11: Dc Output
Rover 1000 & 1300: 2400W surge peak POWER BOOST (AC INVERTER) Power Boost allows the inverter to boost the rated output of the inverter by 1.5 times (ie. Rover 600: 700W to 1050W, Rover 1000 and Rover 1300: 1200W to 1800W). -
Page 12: Inductive Load Device
AC charging cable Fast charging 800W Max, fully charged in 2.2hrs (based on Rover 1000 and Rover 1300. Rover 600 will reach full charge in 2.1hrs) ATTENTION 1. For AC charging, use a power socket with a capacity of more than 10A and ensure that the working current of the socket is constantly greater than 10A. -
Page 13: Solar Charging
DC charger input cable. 117W Max, fully charged in 12hrs at the fastest (Charging via car outlet will vary. Based on optimum output: Rover 600 approx 5.3hrs; Rover 1000 approx 9hrs; Rover 1300 approx 12hrs) charging cable... -
Page 14: Additional Features
It is recommended that one device (with maximum power <1200W for Rover 1000 and Rover 1300, maximum power <700W for Rover 600) at a time is charged. Do not use multiple devices at the same time to avoid triggering overload protection. Companion takes no responsibility for... -
Page 15: Maintenance & Care
The rated power of the Rover 1000 and Rover 1300 is 1200W and the peak power is 2400W. The rated power of the Rover 600 is 700W and the peak power is 1400W. Confirm the power of the device before use, and ensure that the total power of all loaded devices is less than the rated power. -
Page 16: Troubleshooting
TROUBLESHOOTING INDICATOR PROBLEM SOLUTION Normal operation will resume automatically after Ed01/Ed02 DC over-current protecion removing DC overpower devices Eliminate the DC short-circuit fault and restart the Ed03 DC short-circuit protection product to recover Battery low-temperature Normal operation will resume automatically after battery Ed05/Ed07 protection heats up... - Page 17 ROVER 600/1000/1300 PORTABLE POWER STATION TROUBLESHOOTING INDICATOR PROBLEM SOLUTION DC fuse blown Contact Customer Service on 1300 362 921 Over-voltage or low-voltage EA40/EA41/EA45 Normal operation will resume automatically after restart error EA42/EA43/EA44 Module communication failure Normal operation will resume automatically after restart EA34/EA35/EA39 Inverter input errors Normal operation will resume automatically after restart...
-
Page 18: Warranty
WARRANTY POLICY 1. Products distributed by Adventure Operations Australia Pty Ltd and any of our subsidiaries come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if products fail to be of acceptable quality and the failure does not amount to a major failure. - Page 19 ROVER 600/1000/1300 PORTABLE POWER STATION NOTES:...
- Page 20 WARRANTY - For details see www.companionoutdoor.com/warranty Companion is a registered trademark of ® Adventure Trading Australia Pty Ltd Designed by: Adventure Trading Australia Pty Ltd 71 Charles Ulm Place, Eagle Farm, QLD 4009 AUSTRALIA Made in China...
