Soloshot SOLOSHOT3+ Instructions

YOUR SOLOSHOT3+
1. IN THE CASE
Lens Cover
128GB microSD
Card & Reader
3+ Lens
1. Power Button
2. TAG
2. OLED Screen
3. Function Button
3. BASE & LENS
2
4
5
6
7
Front
4. NOT INCLUDED - WALL POWER ADAPTED
You will need a USB wall plug adapter suitable for your country with a 1.5 - 2A rating such
as for Tablets. Charging a fully drained SOLOSHOT3+ will take approximately ~ 4-5 hours.
For best results you may use a Qualcomm certified Quickcharge 2.0 or 3.0 adapter for
~30% faster charging (2.0 or 3.0).
Armband & Clip
BASE
1 2
1
3
8
13
Back
TAG
Mini USB
Charging Cord
Tripod
3
NOTE - TAG comes already docked to your Base!
Make sure to remove the protective plastic wrap
from the TAG before using!
1. 3+ Sensors - Keep Clear!
2. Mono Microphone
3. 3.5mm Auxiliary Jack
4. Directional LED - Blinks Green When Tracking
5. K-Lock Port (on side, lock not included)
9
6. Tag & Accessory Port
7. Mini USB Charging Port & Type USB Port (for
Developers)
10
8. HDMI Out
11
9. Micro SD Card Slot (Orange 128GB card already
installed)
10. Lens Release Button
12
11. BASE & LENS Power Button (Press for 3 seconds to
turn on)
12. Touchscreen
13. Rubber Tripod Coupling (3/8" Tripod Mount Inside)
Shoulder
Strap
Wall Adapter
(not included)
1
YOUR SOLOSHOT3+ •
