- Page 1 INSTRUCTION MANUAL MODELS: DV 100 DVS 100 DV 130 DVS 130 DV 150 DVS 150 DV 180 DVS 180 DV 205 DVS 205 DV 250 DVS 250 DV 300 DVS 300 DV 325 DVS 325 DV 460 DVS 460 DV 505...
- Page 3 Please keep this manual at hand for consultation at all times and ensure it is included with the machine should it be re-sold. GRUPOS ELECTROGENOS GESAN, S.A. is constantly striving to improve its products, and regularly introduces changes to the equipment it supplies. For this reason the characteristics and information contained in this manual may be modified without prior notice and without incurring any obligation.
- Page 4 Generators sets GESAN INDEX: • SAFETY PRECAUTIONS • GENERAL DESCRIPTION • WIRING SYSTEM • CONTROL CARDS • LABELS • BEFORE OPERATION • OPERATION • HANDLING AND STORAGE • MAINTENANCE • WIRING DIAGRAMS • TROUBLESHOOTING • ADVICE ON INSTALLING GENERATOR SETS IN CONFINED SPACES...
-
Page 5: Safety Instructions
Generators sets GESAN SAFETY INSTRUCTIONS Please read carefully the following warnings for your own safety and the safety of others : 1. Make sure that the control panel is well lit if you run your generator set in poor lighting conditions. - Page 6 KEEP OUT OF THE REACH OF CHIDREN. Please refer also to the engine and alternator user’s manual. For further information or enquiries please contact : GRUPOS ELECTROGENOS GESAN S.A. Polígono Malpica- Alfindén, c/ Encina, nº 8 50171 La Puebla de Alfindén (Zaragoza)
-
Page 7: General Description
Generators sets GESAN GENERAL DESCRIPTION The generator set consists of an engine and alternator mounted on a fabricated steel profile baseframe which is painted with a phosphate primer and top coat. The alternator is directly coupled to the engine to SAE standards. The rotor is fixed to the flywheel using steel discs for flexibility. - Page 8 Generators sets GESAN STATIONARY WITH NON SOUNDPROOFED CANOPY In this version the generator set is supplied on a skid base with a metal canopy for outdoor use. The control panel is housed inside the canopy and is operated manually using an igniton key.
- Page 9 Generators sets GESAN STATIONARY SOUNDPROOFED This set features a SOUNDPROOFED METAL CANOPY lined with sound attenuating materials, which, in combination with the exhaust silencer, attains a noise level compliant with directives 79/113/CEE and 84/536/CEE. MOBILE SOUNDPROOFED Generator set mounted on baseframe with independent trailer. Features metal canopy housing the control panel.
-
Page 10: Wiring System
WIRING SYSTEM CONTROL PANELS Control panels are supplied in IP 54 protected metal cabinets and mounted on the baseframe with anti-vibration dampeners. DVS: DV 100, DV 130 y DV 150: DVS 100, DVS 130 y DVS 150: • • Frequency meter Frequency meter •... - Page 11 DV 100, DV 130, DV 150, DV 180, DV 205, DV 250, DV 300, DV 325, DV 460, DV 505, DVS 100, DVS 130, DVS 150, DVS 180, DVS 205, DVS 250, DVS 300, DVS 325, DVS 460 y DVS 505: •...
-
Page 12: Indicator Lights
Generators sets GESAN CONTROL CARD GPM-2 GPM-2 is a programmable engine protecting card, designed to control and monitor generator sets, engines, air compressors, etc. and can be used either with 12 VDC or 24 VDC batteries. OPERATION GPM-2 can be used in two operating modes depending on the position of the key: MANUAL and AUTOMATIC. -
Page 13: Alarm Signals
Generators sets GESAN ALARM SIGNALS FAIL TO START Flashing light: After three failed attempts, the hooter sounds. GPM-2 shuts down the system. Continuous light: Voltage failure or low frequency alarm signal. The hooter will sound and GPM-2 will shut down the system. -
Page 14: Specifications
Generators sets GESAN SPECIFICATIONS INPUT: 12 and 24 VDC nominal: (max. 17.5 VDC and 35 VDC respectively) selected using JUMPER SWITCH J4. ALTERNATOR ENERGIZING: 2VDC. 24VDC. Non-energized selected using JUMPER SWITCH J2. START-UP CUT-OUT: Via “OIL PRESSURE”, “BATTERY CHARGE ALTERNATOR”, signals or “Frequency”... - Page 15 Generators sets GESAN CONTROL CARD GECO GECO is an AUTOMATIC CONTROLLER designed to start, control and monitor generator sets in mains failure situations, and can be used with both 12 and 24 VDC batteries. OPERATION TEST+SERV.-2 TEST AUTO GECO can be switched to any one of six different operational modes: OFF/RESET SERV.-1/START...
- Page 16 Generators sets GESAN OVERRIDE MAINS (AUTOMATIC MODE): Light off. Current is supplied by generator. OVERRIDE GENERATOR (AUTOMATIC MODE): Light on. Generator will not start on mains failure. TEST TEST Works as TEST WITH LOAD, but the load is not transferred to the generator. If the mains should fail while in this mode, the load will automatically be transferred to the generator.
-
Page 17: Low Fuel Level
Generators sets GESAN HIGH WATER TEMPERATURE / WATER l The lamp lights up, the hooter sounds and GECO shuts down the system. Turn the switch to the OFF position. OVERLOAD The lamp lights up, the hooter sounds and GECO shuts down the system. Turn the switch to the OFF position. - Page 18 Generators sets GESAN Flow chart for operation of an emergency automatic generator set Volvo...
- Page 19 Generators sets GESAN LABELS On your generator you will find the following labels: LABEL 1 (UNDEFINED HAZARD) LABEL 2 LABEL 3 (EARTH) LABEL 4 (ELECTRICAL HAZARD) LABEL 5 For your safety and the safety of the others, please replace immediately all these labels in case of loss or damage.
-
Page 20: Before Operation
Generators sets GESAN BEFORE OPERATION (Please note that this section is valid for models DS170L, DS240L, DS240R and DS400L) Before using the generator set, please take the following into consideration: RECOMMENDED OIL The use of motor oil SAE 20W40 is recommended at all temperatures. - Page 21 Generators sets GESAN a) Remove dipstick (see photo 1) b) Check that oil level is at it’s maximum (See photo 2) c) Replace dipstick. d) If oil level is low, add recommended oil by removing the cap on the engine body.
-
Page 22: Operation
Generators sets GESAN OPERATION Once the engine is running, your GESAN generator set is ready to provide you with the energy you require. However, for your own safety and for the correct running of your generator set, please follow the instructions set out below. -
Page 23: Installation
Generators sets GESAN COMMISSIONING INSTALLATION a) Place the machine on a firm, flat surface. b) If the machine is to work outdoors, protect it against rain. Make sure the machine is running in an environment where there is minimal damp and dust. Check that the exhaust is not pointing at people. - Page 24 Generators sets GESAN MANUAL STARTING WITH GPM2 1) Check that the installation that the generator is to be connected to is properly earthed. 2) Check the radiator water level and the oil level. Fill if necessary. 3) Check fuel level. If the level is too low the controller will not permit start-up.
- Page 25 Generators sets GESAN AUTOMATIC STARTING WITH GECO These generator sets feature a set mounted terminal box and a control panel which may be mounted on the set or separately if required. These generator sets may run both manually or automatically.
-
Page 26: Handling And Storage
Generators sets GESAN HANDLING AND STORAGE HANDLING With the exception of stationary generator sets without canopy, your generator set is equipped with a LIFTING ARCH for moving the set. We recommend you use this arch every time you move the set, as shown below. -
Page 27: Long Term Storage
Generators sets GESAN LONG TERM STORAGE When the generator set is withdrawn from service for a prolonged period please take the following instructions into consideration: a) Store the generator in a damp free and dust free environment. b) If the generator set is not to be used for more than six months, drain the engine oil and remove the oil filter. -
Page 28: Maintenance Schedule
Generators sets GESAN MAINTENANCE The life span and performance of your GESAN generator set depend on regular maintenance. It is therefore vital, to ensure long lasting service from your generator set, that you observe the schedule provided and also consult the engine and alternator manuals. - Page 29 Generators sets GESAN Periodic checks. Every… Check 50 hours Check fuel pipes and clamps Replace air filter Clean fuel filter 100 hours Check battery water level Check fan belt play 200 hours Check radiator hoses and clamps 300 hours Change oil filter cartridge...
-
Page 30: Wiring Diagrams
Generators sets GESAN WIRING DIAGRAMS WIRING DIAGRAM MODELS DV 100, DV 130 AND DV 150. DIAGRAM Nº 1646 Volvo... - Page 31 Generators sets GESAN WIRING DIAGRAM MODELS DV 180, DV 205, DV 250, DV 300, DV 460 AND DV 505 DIAGRAM Nº 1849 Volvo...
- Page 32 Generators sets GESAN WIRING DIAGRAMS MODELS DVS 100, DVS 130, DVS 150, DVS 180, DVS 205, DVS 250, DVS 300, DVS 460 AND DVS 505. DIAGRAM Nº 1611 Volvo...
- Page 33 Generators sets GESAN WIRING DIAGRAMS AUTOMATIC MODELS DV 100, DV 130, DV 150, DV 180, DV 205, DV 250, DV 300, DV 460, DV 505, DVS 100, DVS 130, DVS 150, DVS 180, DVS 205, DVS 250, DVS 300, DVS 460 AND DVS 505.
-
Page 34: Troubleshooting
Generators sets GESAN TROUBLESHOOTING (Problems with the engine) Problem Possible cause Solution Engine does not start up 1. Valves 1. Remove and grind the valve base 2. Loose Cylinder Screws 2.Tighten 3.Blocked ducts 3.Remove and clean 4. Blocked fuel filter 4. - Page 35 Generators sets GESAN (Problems with the alternator) Problem Cause Solution No current in the alternator 1. The circuit breaker or limiter arer 1. Screw in the circuit breaker unscrewed 2. Failure to excite 2.Consult technician 3.Low speed on engine 3. Check engine speed 4.
- Page 36 7. (Optional) Fuel tank for one day’s work: All Gesan units come equipped with a fuel tank. When using a supplementary fuel tank of a larger capacity, an intermediate from which the engine fuel pump will aspirate.
- Page 37 Generators sets GESAN convenient that the warm air outlet is situated in a wall open to strong winds from the outside, as cooling will be made difficult. A sufficient amount of space ahould be left around the generator set, so that any necessary maintenance work may be carried out and so that the unit is kept sufficiently cooled.
