Summary of Contents for Inkbird IAM-T2
- Page 1 IAM-T2 Smart Indoor Air Quality Monitor User Manual...
- Page 2 Please keep this manual properly for reference. You can also scan the QR code to visit our official website for product usage videos. For any usage issues, please feel free to contact us at support@inkbird.com.
- Page 3 Wenn Sie eine Bedienungsanleitung in deutscher Sprache benötigen, scannen Sie bitte den QR-Code und besuchen Sie unsere Website, um sie zu erhalten und ein Video über die Verwendung des Produkts zu sehen. Se avete bisogno di un manuale di istruzioni in italiano, scansionate il codice QR e visitate il nostro sito web per ottenerlo e vedere un video su come utilizzare il prodotto.
- Page 4 afin d'obtenir et de visionner la vidéo d'utilisation du produit ! Als je een Nederlandstalige handleiding nodig hebt, scan dan de QR-code om naar onze officiële website te gaan en bekijk de video over het gebruik van het product! Si necesita el manual de instrucciones en español, escanee el código QR para ir a nuestro sitio web oficial y ver el vídeo sobre cómo utilizar el producto.
-
Page 5: Table Of Contents
Installation Instructions CATALOG U E Operation Instructions APP Installation & Connection Overview Cleaning and Maintenance Technical Specifications Important Notes/Warnings LCD Screen Definitions/Product Introduction FCC Requirement Operating Buttons Definitions Customer Service... -
Page 6: Overview
It is therefore vital to maintain an appropriate range of indoor CO2 concentrations for the sake of health. That's why we introduced the IAM-T2, an intelligent indoor air quality monitor that helps you stay safe and healthy. -
Page 7: Technical Specifications
Technical Specification Product name Smart Indoor Air Quality Monitor Brand INKBIRD Model IAM-T2 Battery capacity 3000mAH Lithium Battery DC5V/1A with USB Type C charging cable Power supply (the cable length is 1M) Screen Type LCD screen with white backlight Networking Low-power-consumption Bluetooth 5.0... - Page 8 Sampling Interval 1min/2min/5min/10min (default 1min) Smart Application INKBIRD APP Production 111*66*21mm Dimension Production Weight 185g Package 178*105*36.5mm Dimension Charging time About 6 hours Battery life more than 6 months...
- Page 9 Remark:When the sampling interval is set to 1 minute, the battery can last for approximately 60 days; when the sampling interval is set to 10 minutes, the battery can last for more than 6 months. The longer the sampling interval, the longer the battery life. Testing data Measurement range Resolution Accuracy CO2 concentration 0-9999ppm 1 ppm ± 40 ppm（±5%） Temperature value -9.9℃ - 100℃ 0.1 °C (0.1 °F) ±0.2 °C (±0.36 °F) Relative humidity 0-99% ± 1.8 %...
-
Page 10: Lcd Screen Definitions/Product Introduction
LCD Screen Definitions/Product Introduction 3.1.LCD Screen Definitions ①Auto-Calibration icon ②CO Concentration value ③Buzzer ON/OFF icon ④Bluetooth icon ⑤Battery indication ⑥Temperature ( ℃/℉ ) ⑦Relative Humidity (%RH) ⑧CO2 level indicator light... - Page 11 ①Auto-Calibration icon： When this icon appears, the smart auto-calibration is turned on. When this icon disappears, the smart auto-calibration is turned off. Please do not activate automatic calibration if the device has been stored in an environment with CO₂levels≥1000 ppm(e.g., a grow tent) for extended periods.
- Page 12 NOTE: See Section 4, <<Operating Buttons Definitions>>, in this manual for details on switching the buzzer on or off. ④Bluetooth icon When this icon appears, Bluetooth is turned on but not connected. When this icon“ ” is flashing every 0.5 second, the device Bluetooth is pairing.
- Page 13 *If the CO2 indicator light blinks red 3 times each time the CO2 concentration value is refreshed, it means that the CO2 concentration level is in unhealthy condition (＞1400 ppm). Note: These are default thresholds that can be reconfigured using the INKBIRD app.
- Page 14 3.2 Product Appearance Introduction A.Foldable stand B:Temperature and humidity measuring point...
- Page 15 C:CO2 concentration measuring point D:Type-C charging port...
-
Page 16: Operating Buttons Definitions
Operating Buttons Definitions A: ℃/℉ Switch button Short press: Change the temperature unit between℃ and ℉; Long press: Press and hold it for 2 seconds to turn off/on the buzzer. B:Bluetooth button Short press: When Bluetooth is connecting, the Bluetooth icon“ ”... - Page 17 C:Power Button ON：Turn on the device OFF：Turn off the device...
-
Page 18: Installation Instructions
Installation Instructions Two ways to place the IAM-T2 monitor A：Standing on the table B：Hanging up... -
Page 19: Operation Instructions
Operation Instructions 6.1 Push the switch to the "ON" position to turn on the device, and the device LCD will display as shown below: ①：When turning on the device, the LCD screen will display " " for 3 seconds. ②：After 3 seconds, the LCD screen will show " "... - Page 20 ① ② ③...
- Page 21 6.2.1 Low battery alarm: When the battery is low, the battery level icon“ ” will flash; after one minute, the device will be automatically turned off. 6.2.2 Unhealthy data alarm: When the CO2 concentration reaches an unhealthy state (red), the device emits a soft “beep”...
-
Page 22: App Installation & Connection
APP Installation & Connection 7.1 INKBIRD APP Installation Search for the INKBIRD App from Google Play or App Store to get it for free, or you can scan the QR code below to download it directly. - Page 23 3. APP Location Permission Requirement: We need to obtain your location information to discover and add nearby devices. INKBIRD promises to keep your location information strictly confidential. And your location information will only be used for the location function of the App and will not be collected, used, or disclosed to any third party.
- Page 24 7.2 Registration Step1: Registering an account is necessary before using the INKBIRD app for the first time. Step2: Open the app, select your Country/Region, and a verification code will be sent to you. Step3: Enter the verification code to confirm your identity, and the...
- Page 25 *Turn on the Bluetooth on your smartphone and be careful to put the device as close as possible to the smartphone. *Open the INKBIRD app and click “+” on the top right corner to add a device. Then follow the app instructions to complete the Bluetooth connection.
-
Page 26: Cleaning And Maintenance
Cleaning and Maintenance 8.1. Do not expose this product to water, or place it in high-temperature environments over 50℃. Keep it away from fire sources. 8.2. This product is a precise measuring instrument, do not disassemble it by yourself. 8.3. Do not place this product in an environment full of dust or corrosive gas for measurement. -
Page 27: Important Notes/Warnings
Important Notes/Warnings ISSUES POSSIBLE SOLUTIONS 1. The device samples once per minute at the fastest. Please The value wait for it. If you need to change the sampling time to of CO2 / 2min/5min/10min, please set it on the App. The longer the tempera- sample interval, the longer the battery life. -
Page 28: Fcc Requirement
FCC Requirement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 29 These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
- Page 30 – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
-
Page 31: Customer Service
During this period, products that prove to be defective will, at the discretion of INKBIRD, be either repaired or replaced without charge. For any problems in use, please feel free to contact us at support@inkbird.com. We will do our best to help you. - Page 32 Shenzhen Inkbird Technology Co., Ltd. support@inkbird.com Consignor: Shenzhen Inkbird Technology Co., Ltd. Office Address: Room 1803, Guowei Building, No.68 Guowei Road, Xianhu Community, Liantang, Luohu District, Shenzhen, China Manufacturer: Shenzhen Inkbird Technology Co., Ltd. Factory Address: 5th and 6th Floor, Building 138, No. 71, Yiqing Road, Xianhu Community,...
