  • Page 1 Hardware Maintenance Manual Yoga Pro 7 (14″, 10) and Yoga Pro 7i Aura Edition (14″, 10)
  • Page 2 First Edition (February 2025) © Copyright Lenovo 2025.

  • Page 3: Table Of Contents

    General guidelines ....Trademarks ....xlix Handling thermal interface materials ..© Copyright Lenovo 2025...
  • Page 4 Hardware Maintenance Manual...

  • Page 5: About This Manual

    • It is recommended that these products be repaired by trained service technicians. For customers electing to repair their own Lenovo products, please follow all instructions carefully. • Before servicing a Lenovo product, be sure to read all the information under Chapter 1 “Safety information” on page 1.
  • Page 6 Hardware Maintenance Manual...

  • Page 7: Chapter 1. Safety Information

    • Do not work alone under hazardous conditions or near equipment that has hazardous voltages. • Disconnect all power before: – Performing a mechanical inspection – Working near power supplies – Removing or installing main units © Copyright Lenovo 2025...

  • Page 8: Safety Inspection Guide

    This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-Lenovo features or options not covered by this inspection guide.

  • Page 9: Handling Devices That Are Sensitive To Electrostatic Discharge

    4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.

  • Page 10: Grounding Requirements

    Grounding requirements Electrical grounding of the computer is required for operator safety and correct system function. Proper grounding of the electrical outlet can be verified by a certified electrician. Safety notices (multilingual translations) The safety notices in this section are provided in the following languages: •...
  • Page 11 DANGER DANGER DANGER DANGER Chapter 1 Safety information...
  • Page 12 Hardware Maintenance Manual...
  • Page 13 PERIGO PERIGO PERIGO PERIGO PERIGO Chapter 1 Safety information...
  • Page 14 PERIGO PERIGO PERIGO DANGER DANGER DANGER Hardware Maintenance Manual...
  • Page 15 DANGER DANGER DANGER DANGER DANGER VORSICHT Chapter 1 Safety information...
  • Page 16 VORSICHT VORSICHT VORSICHT VORSICHT VORSICHT Hardware Maintenance Manual...
  • Page 17 VORSICHT VORSICHT Chapter 1 Safety information...
  • Page 18 Hardware Maintenance Manual...
  • Page 19 Chapter 1 Safety information...
  • Page 20 Hardware Maintenance Manual...
  • Page 21 Chapter 1 Safety information...
  • Page 22 Hardware Maintenance Manual...
  • Page 23 Chapter 1 Safety information...
  • Page 24 Hardware Maintenance Manual...

  • Page 25: Chapter 2. General Checkout

    The following are not covered under warranty: • LCD panel cracked from the application of excessive force or from being dropped • Scratched (cosmetic) parts • Distortion, deformation, or discoloration of the cosmetic parts © Copyright Lenovo 2025...

  • Page 26: Cru List

    • Plastic parts, latches, pins, or connectors that have been cracked or broken by excessive force • Damage caused by liquid spilled into the system • Damage caused by the improper insertion of a personal-computer card (PC card) or the installation of an incompatible card •...

  • Page 27: Chapter 3. Identifying Frus (Crus)

    Chapter 3. Identifying FRUs (CRUs) Locate FRUs and CRUs The exploded illustrations help Lenovo service technicians identify FRUs or CRUs that they may need to replace when servicing a customer’s computer. © Copyright Lenovo 2025...
  • Page 28 Figure 1. Exploded view Hardware Maintenance Manual...
  • Page 29 Table 2. FRU (CRU) categories FRU (CRU) category LCD module Note: The LCD module is a FRU and it cannot be disassembled. Upper case Touchpad System board Heat sink (AMD models) Heat sink (Intel models) Fans OLED board Microphone cable Microphone board Battery pack cable Battery bracket...
  • Page 30 Hardware Maintenance Manual...

  • Page 31: Chapter 4. Removing A Fru Or Cru

    Chapter 4. Removing a FRU or CRU Service tools The following table lists tools for servicing Lenovo computers. Tools with a cross mark are needed for serving the product models as described by this publication. Prepare them before you service the product.

  • Page 32: Handling Thermal Interface Materials

    3. Follow the correct sequence in the steps for removing a FRU, as shown in the illustrations by the numbers in square callouts. 4. When removing a FRU, move it in the direction as shown by the arrow in the illustration. 5.

  • Page 33: Areas On The System Board Where Thermal Interface Materials Are Applied

    Figure 2. Areas on the heat sink where thermal interface materials should be applied (Intel models) Figure 3. Areas on the heat sink where thermal interface materials should be applied (AMD models) Areas on the system board where thermal interface materials are applied The following figure shows the areas on the system board where thermal interface materials are applied.

  • Page 34: Remove The Battery Pack

    1.85±0.15 Step 3. Pry up the latches and then remove the lower case. Figure 6. Remove the lower case Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Lower case Remove the battery pack Make sure the following FRU (or CRU) has been removed.
  • Page 35 Figure 8. Remove the battery pack cable Step 4. Remove the battery bracket. Figure 9. Remove the battery bracket Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Battery pack Battery pack cable Battery bracket...

  • Page 36: Remove The Solid-State Drive (Ssd)

    Remove the solid-state drive (SSD) Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 27 Step 1. Disconnect the battery pack cable from the system board. Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable. Step 2.
  • Page 37 • Install 2280 SSD: 1. Remove the screw in the 2280 SSD standoff and then remove the 2242 SSD pad. Table 8. Screw used to secure the SSD Length (mm) Torque (kgf.cm) Quantity Thread 1.85±0.15 2. Use this screw to install the 2280 SSD in the reverse order of the removal steps mentioned above. •...

  • Page 38: Remove The Wi-Fi Card

    Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Solid-state drive (SSD) Remove the Wi-Fi card Make sure the following FRU (or CRU) has been removed. “Remove the lower case” on page 27 Step 1.

  • Page 39: Remove The Speakers

    Peel off the speaker connect mylar and disconnect the speaker cables from the system board. Release the speaker cable from the cable guide and then remove the speakers. Figure 13. Remove the speakers Refer to to look up the Lenovo part number of the following https://support.lenovo.com/partslookup replacement part: Speakers Remove the OLED board Make sure the following FRU (or CRU) has been removed.

  • Page 40: Remove The Microphone Board

    Quantity Thread 1.85±0.15 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: OLED board Remove the microphone board Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 27 “Remove the battery pack ”...

  • Page 41: Remove The Heat Sink

    Figure 16. Remove the microphone cable Go to to look up the Lenovo part numbers of the following https://support.lenovo.com/partslookup replacement parts: Microphone board Microphone cable Remove the heat sink Make sure the following FRU (or CRU) has been removed. “Remove the lower case” on page 27 Step 1.

  • Page 42: Remove The Fans

    Table 12. Screws used to secure the heat sink Length (mm) Torque (kgf.cm) Quantity Thread 1.85±0.15 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Heat sink Related topics “Handling thermal interface materials ” on page 26 Remove the fans Make sure the following FRUs (or CRUs) have been removed.

  • Page 43: Remove The I/O Board

    Length (mm) Torque (kgf.cm) Quantity Thread 1.85±0.15 Go to to look up the Lenovo part number of the following replacement https://support.lenovo.com/partslookup part: Fans Remove the I/O board Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 27 “Remove the heat sink”...

  • Page 44: Remove The System Board

    Quantity Thread 1.85±0.15 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: I/O board Remove the system board Make sure the following FRUs (or CRUs) have been removed. “Remove the lower case” on page 27 “Remove the battery pack ”...
  • Page 45 Figure 23. Remove three screws and flip the hinge Table 16. Screws used to secure the hinge Length (mm) Torque (kgf.cm) Quantity Thread M2.5 3±0.3 Step 2. Disconnect all cables connected to the system board. Chapter 4 Removing a FRU or CRU...
  • Page 46 Figure 24. Disconnect cables connected to the system board Step 3. Remove four screws and then remove the system board. Figure 25. Remove the system board Hardware Maintenance Manual...

  • Page 47: Write Key Product Information To A Replacement System Board

    Attention: Take extra caution when entering the MTM and SN and when selecting the product name and keyboard language. Carefully verify these details before committing the writing action. Once recorded on the system board, they cannot be altered. Consult Lenovo service if you are uncertain about the MTM, SN, and product name for your PC.

  • Page 48: Remove The Touchpad

    Step 4. Click Start Update to update the product information. Step 5. Click Yes in the confirmation window to continue the update. Step 6. Click Finish to close the tool. Step 7. Click Yes in the confirmation window to restart the computer and apply the configuration on the system board.

  • Page 49: Remove The Lcd Module

    Step 3. Remove the touchpad. Figure 29. Remove the touchpad Refer to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Touchpad Remove the LCD module Make sure the following FRU (CRU) has been removed. “Remove the lower case” on page 27 Step 1.

  • Page 50: Remove The Upper Case

    Torque (kgf.cm) Quantity Thread M2.5 3±0.3 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: LCD module Remove the upper case Make sure the following FRUs (or CRUs) have been removed. Hardware Maintenance Manual...
  • Page 51 “Remove the system board” on page 38 “Remove the touchpad” on page 42 “Remove the LCD module” on page 43 Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement part: Upper case Chapter 4 Removing a FRU or CRU...
  • Page 52 Hardware Maintenance Manual...

  • Page 53: Appendix A. Label Locations

    India BIS label 22 mm x 30 mm TW Caution label 70 mm x 10 mm VietNam Energy label 10 mm x 9 mm Belarus label 40 mm x 8 mm CECP Label 30 mm x 30 mm © Copyright Lenovo 2025...
  • Page 54 Table 20. All base cover labels (continued) Applied country/region Label Label name Label dimensions USA warning label (Canada) 120 mm x 20 mm US RTC battery label 120 mm x 20 mm 43.11 mm x 16.2 mm Carbon Neutral label Hardware Maintenance Manual...

  • Page 55: Trademarks

    Trademarks LENOVO and the LENOVO logo are trademarks of Lenovo. All other trademarks are the property of their respective owners. © 2025 Lenovo.
