About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Yoga Pro 7 14IMH9 83E2 Yoga Pro 7 14IMH9 U1...
Camera The built-in camera captures visible light and converts it to digital signals. It is used for video recording and video conferencing. This camera also receives near-infrared waves emitted by an infrared LED and reflected by a human face, so it can also be used for facial recognition.
Top view Figure 2. top view Description Speakers Keyboard Touchpad Speakers The speakers are the PC's built-in sound output devices. Keyboard The keyboard is the PC's built-in input device for typing characters. It also includes keys that can make you more productive when interacting with the PC, apps, and the Windows operating system.
Related topics “Hotkeys” on page 17 “The FnLock switch” on page 17 Appendix A “Function descriptions for Lenovo hotkeys” on page 35 Touchpad The touchpad is the PC's built-in pointing device, which provides the basic functionality of an external mouse. Slide your finger on the touchpad to move the pointer on the screen and tap or double-tap to select or execute a screen item.
Left view Figure 3. left-side view Description ™ HDMI connector ® Multi-purpose USB Type-C connector Charging light HDMI connector The HDMI connector is used to connect an external display device, such as a television, a projector, or a monitor. Multi-purpose USB Type-C connector This USB Type-C connector is the PC's power input connector.
Charging light The charging light indicates whether the PC is plugged into an electrical outlet. When the PC is plugged into an electrical outlet, the color of the light indicates whether the battery is fully charged (or will shortly be fully charged).
Right view Figure 4. right-side view Description Camera switch Power light Power button Combo audio jack USB Standard-A connector Camera switch This toggle switch is used to enable or disable the built-in camera. Note: This switch is designed for privacy protection. If you don't need to use the camera, slide the switch to the off position to prevent any apps from using the camera.
USB device connected to this type of connector even when the PC is shut down, in sleep, or hibernation mode. The always-on function can be turned on and off in: • The PC's firmware setup utility, or • Lenovo Vantage or Lenovo PC Manager User Guide...
Bottom view Figure 5. bottom view Description Air vents (intake) Speakers Novo button hole Avoid constant body contact with specific hot sections CAUTION: When the computer is operating, it should be placed on a hard and flat surface with its bottom area not in contact with user’s bare skin.
Page 16
• Display the Windows advanced startup options page Note: The Novo button is rarely used during normal PC operations. To prevent users from accidently pressing it, the Novo button is placed in a recessed hole. You can use a straightened paper clip to press this button.
Specifications Dimensions Width 325.50 mm Depth 226.49 mm 17.95 mm Thickness (thickest part) Thickness (thinnest part) 15.60 mm ac power adapter Input 100 V ac–240 V ac, 50 Hz–60 Hz Maximum output voltage 20 V Maximum output current • 5 A, or •...
Page 18
Display 14.5 inches Screen size (diagonal) Resolution • 3072 × 1920, or • 2560 × 1600 Supported refresh rates • 90 Hz, or • 120 Hz Connectors and slots USB Standard-A connector • Quantity: 1 • Maximum power output: 5 V, 1.5 A •...
Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device.
Night light temperature screen. Note: Selected Lenovo computers are low blue light certified using night light mode and color temperature settings available in the pre-installed operating system. These computers are tested with night light turned on and color temperature set to 48 or greater.
To open it, type its name in the Windows Search box and select the matched result. If neither of the apps is pre-installed, you may install one on your own. Lenovo Vantage is available for download free of charge from the Microsoft Store.
Interact with your computer Hotkeys Look at the top row of the keyboard of your Lenovo computer and you’ll find keys with printed icons. These keys are called hotkeys and they provide shortcuts to functions that you’ll use frequently. The function that each hotkey provides is denoted by the icon printed on the key.
Appendix A “Function descriptions for Lenovo hotkeys” on page 35 The Copilot key The era of AI has arrived, and many Lenovo PCs now include a Copilot key on the keyboard. It is located either in the bottom or the top row of the keyboard and is marked with For Windows PCs with Copilot in Windows available and enabled, pressing the Copilot key opens Copilot in Windows.
Related topics “I pressed the Copilot key on my keyboard, but neither Copilot in Windows nor Windows Search opened. What could be the potential cause?” on page 30 Touch operations supported by Windows For computers with a touch-enabled screen, you can touch the screen directly with your fingers and interact with your computer in a more natural way.
Page 26
Touch operation Used for Opening the widgets panel Swipe in from the left edge Opening the notification center Swipe in from the right edge The Windows operating system also supports 3- and 4-finger gestures on the screen and the touchpad. You can set them up in Settings ➙...
Intelligent features Your computer may be pre-installed with one of Lenovo Vantage or Lenovo PC Manager but not both. Most features described here can be enabled or disabled in one of these apps. Other features may be enabled in a standalone app.
You can charge the battery any time you want. The battery packs of Lenovo computers support multiple charging modes that are suitable for different power usage habits. You can switch the battery’s active charging mode in Lenovo Vantage or Lenovo PC Manager.
You can switch the operation mode in the pre-installed app Lenovo Vantage or Lenovo PC Manager. As a shortcut, you can also use the key combination Fn + Q. Three modes are usually available for most Lenovo computers. The following table lists the operation modes and the recommended conditions for each mode.
Change the setting to Disabled or Enabled. Step 4. Select Exit ➙ Exit Saving Changes. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. Step 1. Open the UEFI/BIOS setup utility.
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service.
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service.
Note: The master and user hard disk passwords must be set at the same time. Step 4. Select Exit ➙ Exit Saving Changes. If the hard disk password is set, you must provide the correct password to start the operating system. Change or remove hard disk password Step 1.
Why does my computer start automatically when I open the lid Your computer may have Flip to Start enabled. Many Lenovo notebook computers include a sensor that can detect the angle at which the lid is opened. When you open the lid, the sensor can detect this behavior. If Flip to Start is enabled, the computer will respond by starting up automatically.
3. Click Diagnostics ➙ Operating System Diagnostics and then follow the on-screen instructions. Use Lenovo Vantage or Lenovo PC Manager to: • Download and install the latest drivers and firmware. • Configure hardware settings Use Windows Search. • Diagnose computer hardware problems.
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;...
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo.
For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product, see “Warranty information” in the Safety and Warranty Guide that comes with your computer. Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https://pcsupport.lenovo.com/warrantyupgrade...
Appendix A. Function descriptions for Lenovo hotkeys Hotkey functions are denoted by the icons printed on the keys. The following table describes the functions for all Lenovo hotkeys. The keyboard of your Lenovo computer should only support a subset of the listed hotkeys.
Page 42
Table 10. Hotkey icons and denoted functions (continued) Hotkey icon Function description Plays the next audio or video in the playlist. Switches the computer’s active operation mode. Blurs the background for videoconferencing. Switches the computer’s active audio mode. Turns on/off night light mode. (Windows operating systems) Note: Hotkey functions may change if the associated app or the Windows operating system is updated.
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 44
Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
