- Page 1 PRODUCT BROCHURE 3VJ Series Molded Case Circuit Break MARCH 2021...
-
Page 2: Molded Case Circuit Breakers
3VJ SERIES Molded Case Circuit Breakers NEW! SIMPLY EFFICIENT 3VJ Molded Case Circuit Breakers with Thermal Magnetic Trip units offer the perfect solution whether in industrial applications, buildings, infrastructure or utilities. The 3VJ MCCBs are the efficient choice for cost effective power distribution. It ensures reliable protection of personnel and plants with simple functional features that maximize benefits for users in all segments. - Page 3 RELIABLE & SAFE COMPACT Every piece of this MCCB is designed These MCCBs save space in with the utmost quality for optimal enclosures & switchboards and performance. The 4 pole MCCB reduces the overall size of the (100% rated) is perfect to operate in module.
-
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS 3VJ10 3VJ11 TYPE Number of poles 1, 2, 3, 4 2, 3, 4 Frame Size 125 X Rated operational current I 20 ... 125 25 ... 125 at 45 C ambient temperature Rated operational voltage 50/60 Hz AC Insulation voltage 1000 Impulse voltage... - Page 5 TECHNICAL SPECIFICATIONS 3VJ12 3VJ13 TYPE Number of poles 2, 3, 4 3, 4 Frame Size Rated operational current I 160 ... 250 320 ... 400 at 45 C ambient temperature Rated operational voltage 50/60 Hz AC Insulation voltage 1000 1000 Impulse voltage Suitable for Isolation Utilization category,...
-
Page 6: Product Dimensions
PRODUCT DIMENSIONS 3VJ10 1 Pole 3 Pole 2 Pole 4 Pole Depth 3VJ11 2 Pole 2 Pole 3 Pole 4 Pole Depth 3VJ12 4 Pole Depth 2 Pole 3 Pole 3 Pole 4 Pole Depth 3VJ13 3 Pole 4 Pole Depth All dimensions are in mm... -
Page 7: Product Selection Guide
PRODUCT SELECTION GUIDE The order number is systematically structured and provides information about the most important features of the 3VJ Molded Case Circuit Breaker. – – 0AA0 Breaker type: Frame size: 3VJ10 20 – 125 3VJ11 25 – 125 3VJ12 160 –... -
Page 8: Product Selection
PRODUCT SELECTION 1 Pole Thermal Magnetic Trip Unit Fixed Thermal Fixed Magnetic (FTFM) 240VAC + 50Hz 3VJ10 Frame Nominal Overload Short-circuit Current Protection Protection Size Order Number = 10kA at 240V = 18kA at 240V = 25kA at 240V 3VJ1002-0DA12-0AA0 3VJ1002-1DA12-0AA0 3VJ1002-3DA12-0AA0 3VJ1092-0DA12-0AA0... - Page 9 PRODUCT SELECTION 2 Pole Thermal Magnetic Trip Unit Fixed Thermal Fixed Magnetic (FTFM) 415VAC + 50Hz 3VJ10 3VJ11 3VJ12 Nominal Overload Short- Frame Size Current Protection circuit Order Number Protection = 10kA at = 18kA at = 25kA at = 36kA at = 55kA at 415V 415V...
- Page 10 PRODUCT SELECTION 3 Pole Thermal Magnetic Trip Unit Fixed Thermal Fixed Magnetic (FTFM) 415VAC + 50Hz 3VJ13 3VJ10 3VJ11 3VJ12 Frame Nominal Overload Short- Size Current Protection circuit Order Number Protection = 10kA at 415V = 18kA at 415V = 25kA at 415V = 36kA at 415V = 55kA at 415V 3VJ1002-0DA32-0AA0...
- Page 11 PRODUCT SELECTION 3 Pole Thermal Magnetic Trip Unit Adjustable Thermal Fixed Magnetic (ATFM) 415VAC + 50Hz 3VJ13 3VJ10 3VJ11 3VJ12 Frame Nominal Overload Short- Protection Size Current circuit Order Number Protection = 10kA at 415V = 18kA at 415V = 25kA at 415V = 36kA at 415V = 55kA at 415V 3VJ1002-0DB32-0AA0...
- Page 12 PRODUCT SELECTION 4 Pole Thermal Magnetic Trip Unit Fixed Thermal Fixed Magnetic (FTFM) 415VAC + 50Hz 3VJ12 3VJ10 3VJ11 3VJ13 Frame Nominal Overload Short- Current Protection circuit Size Order Number Protection = 10kA at 415V = 18kA at 415V = 25kA at 415V = 36kA at 415V = 55kA at 415V 3VJ1002-0EA42-0AA0...
- Page 13 PRODUCT SELECTION 4 Pole Thermal Magnetic Trip Unit Adjustable Thermal Fixed Magnetic (ATFM) 415VAC + 50Hz 3VJ10 3VJ11 3VJ12 3VJ13 Frame Nominal Overload Short- Protection Size Current circuit Order Number Protection = 10kA at 415V = 18kA at 415V = 25kA at 415V = 36kA at 415V = 55kA at 415V 3VJ1002-0EB42-0AA0...
-
Page 14: Product Accessories
PRODUCT ACCESSORIES EXTERNAL FRAME SIZE ACCESSORIES 3VJ10 3VJ11 3VJ12 3VJ13 Extended Door Mounted Rotary Operator (including 8UC handle) 3VJ9018-0HD11 3VJ9118-0HD11 3VJ9218-0HD11 3VJ9417-0HD11 Straight Terminals 3VJ9011-0EC00 (1P) Spreader Terminals 3VJ9112-0ED00 3VJ9212-0ED00 3VJ9012-0ED00 3VJ9013-0ED00 3VJ9113-0ED00 3VJ9213-0ED00 3VJ9313-0ED00 3VJ9014-0ED00 3VJ9114-0ED00 3VJ9214-0ED00 3VJ9314-0ED00 Phase Barriers 3VJ9018-0CA00 3VJ9218-0CA00 3VJ9218-0CA00... - Page 15 PRODUCT ACCESSORIES INTERNAL FRAME SIZE ACCESSORIES 3VJ10 3VJ11 3VJ12 3VJ13 AUX Auxiliary Switch 3VJ9018-0AN11 3VJ9218-0AN11 3VJ9218-0AN11 3VJ9417-0AN11 3VJ9218-0AN21 3VJ9218-0AN21 3VJ9417-0AN21 AL Alarm Switch 3VJ9018-0AA11 3VJ9118-0AA11 3VJ9218-0AA11 3VJ9417-0AA11 3VJ9118-0AA21 3VJ9218-0AA21 3VJ9417-0AA21 AUX + AL Auxiliary Switch 3VJ9018-0AD11 3VJ9118-0AD11 3VJ9218-0AD11 3VJ9417-0AD11 3VJ9118-0AD21 3VJ9218-0AD21 3VJ9417-0AD21 STL Shunt Trip (Right)
- Page 16 3VJ Series Product Brochure 2021 Published by Siemens Malaysia Sdn Bhd Smart Infrastructure Electrical Products (EP) Cp Tower, 11, Jalan 16/11 46350 Petaling Jaya, Selangor Malaysia Attach business card here Subject to changes and errors. The information given in this document only...
