Sealey VS0249 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
WARNING! Ensure all Health and Safety, local authority, and general workshop practice regulations are strictly adhered to when using tools.
‰
DO NOT use tools if damaged or worn.
8
Maintain the tools in good and clean condition for best and safest performance.
9
Ensure all threads are clean and well lubricated.
9
Ensure the vehicle is adequately supported with axle stands, ramps, etc. as appropriate.
9
Wear suitable clothing to avoid snagging. DO NOT wear jewellery. Tie back long hair.
9
Wear approved eye protection. A full range of personal safety equipment is available from your Sealey stockist.
9
Account for all tools and parts being used and DO NOT leave them in or on the vehicle.
9
IMPORTANT: Always refer to the vehicle manufacturer's service instructions, or proprietary manual, to establish the correct procedure
and data. These instructions for use are provided as a guide only.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
‰
situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but
must be applied by the operator.
2. INTRODUCTION
Used for pushing back brake pistons and removal/installation of hose clips. Pneumatic wind-back tool is suitable for left or right-hand wind-
back operations. Suitable for push-back and wind-back brake pistons. Long-reach flexible cable, designed to reach awkward-positioned
hose clips. Kit includes a 2-pin magnetic adaptor for use with interchangeable brake adaptor plates, thrust pin, one and two brake piston
spreaders, thrust bolt, 10mm ratchet spanner, locking nut spanner and hose clip attachment. Supplied in a storage case.
FIG.1
3
2
4
5
6
3. SPECIFICATION
Model No:
Maximum Spread:
Cable Length:
Jaw Opening:
Nett Weight:
© Jack Sealey Limited
PNEUMATIC BRAKE PISTON SPREADER /
WIND BACK & HOSE CLIP TOOL
VS0249
MODEL NO:
7
9
10
11
1
1
VS0249
60mm
660mm
55mm
3.08kg
Original Language Version
1 Pneumatic body
2 Adapter
3 Single piston drive blade set
4 Double piston drive blade - large hole
5 Double piston drive blade - small hole
8
6 Hex Wrench
7 Fixing plate
8 Hose clip clamp
9 Drive rod
10 Transmission rod
11 Ratchet Wrench - 10mm
VS0249 Issue 1 11/12/2024
