TP-Link tapo C200 Quick Start Manual

Quick Start Guide
Pan/Tilt Home Security
Wi-Fi Camera
Setup Video
Scan QR code or visit
https://www.tp-link.com/support/
setup-video/#cloud-cameras
7106511268 REV5.0.0 *Images may differ from actual products.
Mounting Instructions
1. Mark Position
Φ=6 mm (15/64 in.)
Place the mounting template
where you want the camera.
For wall mounting, drill two
holes through two circles.
2. Mount Base
Affix the camera base using
the screws.
For wall mounting, insert two
anchors into the holes and use
the screws to affix the camera
base over the anchors.
3. Secure Camera
Attach the camera on the
base and rotate to secure
the camera.
STEP 1
DOWNLOAD APP
Get the Tapo app from the
App Store or Google Play.
STEP 2
POWER UP
Plug in your camera and wait
until the LED blinks red and
green.
STEP 3
SET UP
Tap the button in the app
and select your model. Follow
app instructions to complete
setup.
Appearance
Tilt the camera lens up to find the RESET button and
the microSD card slot.
RESET Button
While the camera is powered on, press and hold the
RESET button for at least 5 seconds until the LED
blinks red. The camera will reset and reboot.
microSD Card Slot
Insert a microSD card and initialize it on the Tapo app
for local recording.
Lens
Micro SD RESET
Micro SD
For technical support, the user guide,
warranty, and more information,
please visit www.tapo.com/support/
LED Indication
Solid red
Blinking red and green
Blinking red slowly
Scan to download
Solid amber
Solid green
Blinking red quickly
Blinking green quickly
Mounting Kit
Camera Base
• Keep the device away from water, fire, humidity or hot environments.
• Do not use damaged charger or USB cable to charge the device.
• Do not use any other chargers than those recommended.
• Do not use the device where wireless devices are not allowed.
• Adapter shall be installed near the equipment and shall be easily accessible.
• Use only power supplies which are provided by manufacturer and in the original
packing of this product. If you have any questions, please don't hesitate to
contact us.
• For indoor use only.
• Do not disassemble, repair or modify the product.
• Do not use the product if the casing has been broken. Danger of electric shock.
• Never touch the product with wet hands.
• Do not expose to heavy rain or any type of moisture.
• Do not place near automatically controlled devices such as fire alarms. Radio
waves emitted from this product may cause such devices to malfunction resulting
in an accident.
• Observe restrictions on using wireless products in fuel depots, chemical plants or
when blasting operations are in progress.
• Do not use liquid to clean the product. Only use a dry cloth.
• Never put metal objects inside the product. If a metal object enters the product
turn off the circuit breaker and contact an authorised electrician.
• This product is not intended to be used when providing medical care. Consult the
manufacturer of any personal medical devices, such as pacemakers or hearing
aids to determine if they are adequality shielded from external RF (radio
frequency) energy.
• Do not use this product in health care facilities. Hospitals or health care facilities
may be using equipment that could be sensitive to external RF energy.
• Do not use this product near water for example near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
• The product should be kept free from excessive smoke, dust or high temperature
and vibration.
RESET
• This product should not be exposed to direct sunlight
• Do not place heavy objects on top of the product.
• When you leave the product unused for a long time unplug the product from the
power outlet.
• This product may interfere with other electronic products such as TV, radios,
personal computers, phones or other wireless devices.
• Operating Temperature: 0 °C ~ 40°C (32°F ~ 104°F)
Please read and follow the above safety information when operating the device. We
cannot guarantee that no accidents or damage will occur due to improper use of
the device. Please use this product with care and operate at your own risk.
©2024 TP-Link
Starting up
Ready for setup
Connecting to Wi-Fi
Connected to Wi-Fi
Connected to the cloud
Camera resetting
Camera updating
Camera
Mounting Template
Screws Anchors (for wall mounting)
