- Page 1 User Guide Pan/Tilt Home Security Wi-Fi Camera Tapo C210 © 2021 TP-Link 1910012987 REV1.0.0...
-
Page 2: Table Of Contents
Contents About This Guide ·················································································1 Introduction ····························································································2 Appearance ····························································································3 Set Up Your Camera ···········································································4 Setup using Amazon Frustration-Free Setup ······················6 Main Camera Controls ···································································10 Pan & Tilt Control ··············································································12 Motion Detection ··············································································13 24-hour Recordings ········································································17 Privacy Mode ······················································································19 Authentication ····················································································20... -
Page 3: About This Guide
Ignoring this type of note might result in a malfunction or damage to the device. Note: More Info • Specifications can be found on the product page at https://www.tapo.com. • Our Technical Support and troubleshooting information can be found at https://www.tapo.com/support/. • The setup video can be found at https://www.tp-link.com/support/setup-video/#cloud-cameras. -
Page 4: Introduction
• Sharing - Share the memorable moments with your family and friends. • Safe Storage – Store up to 256 GB on a microSD card*, equal to 512 hours (21 days) of footage △ *microSD card needs to be purchased separately. △ The data comes from TP-Link laboratory. -
Page 5: Appearance
Ready for setup • Blinking red slowly: Connecting to Wi-Fi • Solid amber: Connected to Wi-Fi • Solid green: Connected to TP-Link Cloud server DC Power Port Microphone Speaker Tilt your camera lens up to find the RESET • Blinking red quickly: button and microSD card slot. -
Page 6: Set Up Your Camera
Step 3. Add Your Camera Get the Tapo app from the Apple App Store Open the app, and log in with your TP-Link ID. Tap the button in the app and select your or Google Play, or by scanning the QR code If you don't have an account, create one first. - Page 7 Step 5. Place Camera Step 4. Configure Camera Place your camera on a flat surface, or install it on a wall or ceiling with the provided Follow app instructions to configure your mounting template and screws. camera and add it to your home network. affix the camera base using screws before securing the camera.
-
Page 8: Setup Using Amazon Frustration-Free Setup
Setup using Amazon Frustration-Free Setup What is Amazon Frustration-Free Setup? Amazon Frustration-Free Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi password on each device. To use this feature, confirm the following: ●... - Page 9 How to use Amazon Frustration-Free Setup with Tapo devices 1. Open the Amazon Alexa app. Then tap on the hamburger icon in the 2. Enter Tapo in the search bar and choose Tapo. upper left corner and select Skills & Games.
- Page 10 3. Tap the ENABLE button. 4. Log in with your TP-Link ID that has bound to your Tapo device, and tap Authorize. After authorized successfully, the message Tapo has been successfully linked will come up.
- Page 11 5. Plug in your Tapo device and the setup will complete automatically in two minutes. For setting up more Tapo devices, just plug in and enjoy! Done! If this device displays on the Home page in the Tapo app, it indicates this device has been successfully associated with your Amazon account and joined your Wi-Fi network automatically.
-
Page 12: Main Camera Controls
Main Camera Controls After you successfully set up the camera, you will see your camera listed on the home page. You can view and manage your camera from anywhere at any time with the Tapo app. Home Page Live View This page lists all your cameras you've added and you can view them Talk Voice... - Page 13 Camera Settings On this page, you can edit your account, quickly check the memorable Live View page, tap to enter the Camera Settings page. You can moments you saved, or find the FAQs and other features related to the change the settings of your camera to meet various needs, such as Tapo app.
-
Page 14: Pan & Tilt Control
Pan & Tilt Control On the Live View page, tap to enter the control page. Tap on the Pan & Tilt panel to control your camera to move. Pan & Tilt Settings: to set how many degrees the camera will move per tap of the Pan & Tilt. Vertical Cruise: Persistently move up and down. -
Page 15: Motion Detection
Motion Detection With motion detection, the Tapo app alerts you of activity that matters and sends notifications straight to you when motion detected. Insert a microSD card to record the clips when motion detected. Otherwise, you can only receive the notifications. Note: Initialize the SD card on the app before using it. - Page 16 3. Customize Camera Alarm settings. Choose Alarm Type (Sound/Light) 4. Customize Activity Zones and the camera will only detect motion in Alarm Sound (Siren/Tone), and set Alarm Schedule as needed. custom zones. Entire view is covered by default.
- Page 17 5. Adjust Motion Sensitivity (Low/Normal/High) as needed. Increased 6. After editing the detection settings for the camera, you can set the sensitivity results in more recordings and notifications. Recording Schedule for the motion detection.
- Page 18 7. On the Live View page, tap to find all recordings. The orange sections are recordings for motion detection. Note: The microSD card is needed for recordings. Initialize the SD card on the app before using it.
-
Page 19: 24-Hour Recordings
24-hour Recordings The microSD card is needed for 24-hour recording and it’s suggested to initialize the SD card on the app before using it. 2. Toggle on to enable the microSD Recording function and set the 1. On the Live View page, tap to enter the Camera Settings... - Page 20 3. On the Live View page, tap to find all recordings. The blue sections mean continuous recording. Note: The microSD card is needed for recordings. Initialize the SD card on the app before using it.
-
Page 21: Privacy Mode
Privacy Mode On the Live View page, tap to enable the Privacy Mode. When enabled, streaming and recording functions will be temporarily disabled to protect your privacy. -
Page 22: Authentication
2412MHz—2472MHz (20dBm) EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863. The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce RF Exposure Information This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way... - Page 23 L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. l’appareil ne doit pas produire de brouillage; 2.
- Page 24 • 請不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。 限用物質含有情況標示聲明書 設備名稱：Pan/Tilt Home Security Wi-Fi Camera 型號（型式）：Tapo C210 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 多溴二苯醚 鉛 汞 鎘 六價鉻 多溴聯苯 Polybrominated diphenyl ethers Lead Mercury Cadmium Hexavalent chromium Polybrominated biphenyls Unit...
- Page 25 Safety Information • Keep the device away from water, fire, humidity or hot environments. • Do not attempt to disassemble, repair, or modify the device. • Do not use damaged charger or USB cable to charge the device. • Do not use any other chargers than those recommended •...
