WASHLET C2
TCF23460***
TCF23410***
TCF23400***
■ Thank you for your recent purchase of this product.
Please read the enclosed information to ensure the safe use of your product.
■ Be sure to read this Instruction Manual before using your product and keep it in a safe place
for future reference.
2022.3.31
D07E80
Instruction Manual
