SOMFY SONESSE2 28 Zigbee Short Installation Manual

EN
EN
SONESSE2 28 Zigbee
Short installation guide
O
RIGINAL INSTRUCTIONS
Complete instruction guide available online on www.somfy.info
1
To set the drive, download "TaHoma pro"
application available on stores
2
This drive does not require any maintenance operation.
UP
3
This reset deletes all programmed control points, all end limit settings,
resets the favourite (my) position for the drive and leaves the current
Zigbee network.
These instructions apply to all SONESSE2 28 Zigbee drive, the different versions of which are available in the current catalogue.
FIELD OF APPLICATION
The Sonesse 28 drives are designed to motorise all types of:
– Interior vertical blinds which front rail moves solely by gravity with a mass less than 15 kg.
LIABILITY
Please read these instructions carefully before
installing and using the drive. In addition to following
the instructions given in this guide, the instructions
detailed in the attached Safety instructions
document must also be observed.
The drive must be installed by a motorisation and
home automation professional, according to
instructions from Somfy and the regulations
applicable in the country in which it is commissioned.
It is prohibited to use the drive outside the field of
application described above. Such use, and any failure
to comply with the instructions given in this guide and
in the attached Safety instructions document,
absolves Somfy of any liability and invalidates the
warranty.
WARNING
To ensure electrical safety, this Class III drive must be powered by a «SELV» voltage source (Safety Extra Low Voltage).
The drive must be installed by a professionally qualified person (electrical specialist according to DIN VDE 1000-10) for drives and automations in the building services sector in accordance with the Somfy instructions
and the applicable regulations in the country of commissioning.
Using this drive with any products which are not listed in the attached «Compatibility matrix» document shall also render invalid any Somfy warranty and release Somfy from any liability.
For the purposes of recharging the battery, only use the detachable supply unit provided with this appliance.
Improper using battery pack may cause overheat, fire, explosion, resulting in serious injury or death.
Do not expose the drive or battery to excessive temperatures.
There is a risk if terminals of the battery-operated drive or battery being short circuited by metal objects.
Ensure battery is fully charged prior to installation on site.
Do not unplug the battery when the motor works.
START UP
STOP
INSTRUCTIONS TO BE RESPECTED
The installer must inform its customers of the
operating and maintenance conditions for the drive
and must provide them with the instructions for use
and maintenance, and the attached Safety
instructions document, after installing the drive. Any
After-Sales Service operation on the drive must be
performed by a motorisation and home automation
professional.
If in doubt when installing the drive, or to obtain
additional information, contact a Somfy adviser or go
to the website www.somfy.com.
Once the "TaHoma pro" application is downloaded,
open the app and follow the instructions to set the drive.
USE
x2
DRIVE RESETTING
SAFETY INSTRUCTIONS FOR WIRING
Cables which pass through a metal wall must be protected and isolated using a sheath or sleeve.
Attach cables to prevent any contact with moving parts.
If the drive is used outdoors, and if the power supply cable is a type H05-VVF cable, the cable should be
installed in a UV-resistant duct, e.g. under a gland.
Leave the drive power supply cable accessible: the product must be easily replaceable.
Always make a loop in the power supply cable to prevent water entering the drive.
From the Application
"Help me by Somfy"
scan the QR code here to
find complete setting
instructions.
"Help me by Somfy"
available on stores
DRIVE SETTING
MY DOWN
12 s
x3
