USER MANUAL
FLEX-IP69K
GENERAL PRODUCT INFORMATION
Une version française de cette notice est disponible à partir de la page 8 de ce document
Thank you for purchasing an Effilux's product. To ensure proper use of the product, please read this User manual before use and keep
it for your future reference. Any improper use voids the warranty. This product is an LED light used for machine vision and industrial
inspection. Do not use the product for other applications, and be sure to follow the instructions below.
Datasheets and drawings in PDF and/or CAD can be downloaded from the Effilux website:
The label(s) on the product always indicate(s) the reference, the power consumption and the serial number of the product. Be sure
to check the content before using the product and handle the label(s) with care. The date of manufacturing is included in the serial
number of the product: XXXXXXYYMM-ZZZ with YY corresponding to the year and MM to the month. If the label is missing or
damaged and the content cannot be checked, please contact Effilux.
GENERAL WARNINGS AND PRECAUTIONS OF USE
Maintenance
The product must be switch off during any maintenance operation. To remove marks on the lens or on the window: Use alcohol-free
lens cleaning fluid on a cleaning tissue. Few drops will suffice. Please clean gently. Always apply the fluid to a tissue rather than the
lens itself. To clean optical components: Please wear gloves and use compressed air if there is dust.
Usage and storage environment
Operating environment
Storage environment
Informations
Except if a specific IP rating is given for your product (refer to the «Dust and Water resistance (IP rating) » section), please install the
product to locations with following conditions (Incorrect installation location may causes product failure) :
Well-ventilated places with minimal dust.
Places free from corrosive or combustible gas.
Places away from water taps, boilers, humidifiers, air conditioners, heaters or stoves.
User security
Incorrect use of the product may result in fire, electric shock, or other serious damages. Please ensure to follow below conditions. If an
abnormal condition occurs (fuming, heat, noises, etc.), stop using the product immediately and turn the power off.
Do not disassemble or modify the product.
Do not try to fix any damages on the product by yourself.
Do not touch the product with wet hands.
Wire and keep the flying leads cables in a dry area (regardless of the product's
degree of protection).
Make sure the power supply and the cable/connector are adapted to the
product specifications.
Do not inverse electrical polarity - check your connections and the conventions. The product packaging must be removed before use.
USER MANUAL-V3.0-EFFI-FLEX-IP69K
Temperature:
0 to 40°C - Humidity: 20 to 85RH% (without condensation) - Altitude: Up to 2000m
Temperature: -20 to 60°C - Humidity: 20 to 85RH% (without condensation)
Overvoltage category I - Protective class III - Pollution degree 3
Places free from any liquid, chemical product or steam.
Places that are not subject to sudden temperature changes.
Do not look directly at the LED light without protection.
Make sure special protective glasses are used with UV products (<420nm).
Do not use homemade cables.
Make sure the product does not show any moisture or liquid inside before
switching it ON.
The device must be powered by a 24V safety power supply in accordance to
local Electrical Safety rules
1/14
www.effilux.com
www.effilux.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the effi-FLEX-IP69K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EFFILUX effi-FLEX-IP69K

  • Page 1 Une version française de cette notice est disponible à partir de la page 8 de ce document Thank you for purchasing an Effilux’s product. To ensure proper use of the product, please read this User manual before use and keep it for your future reference.
  • Page 2 PART NUMBERING STANDARD version EFFI-FLEX-IP69K - Number of LED Wavelength Windows Lens position Connectors 365* TR: Transparent FL2 (Standard): (UV) (20 mm) XXX > 55 LEDs SD: Semi-diffuse IN2 (FOOD): (UV) (60 mm) XXX > 20 LEDs OP: Opaline (Blue)
  • Page 3 (*) AIC (Analog Intensity Control) for the ELS version. • The EFFI-FLEX-IP69K requires 24V DC input power. • PNP trigger pin needs to be connected either to a trigger signal for AutoStrobe and Strobe or to a continuous signal for Continuous mode.
  • Page 4 (AIC instead of PNP) EFFI-FLEX-IP69K-XXX-ZZZ-WW-PP(-V) EFFI-FLEX-IP69K-XXX-ZZZ-WW-PP-ELS-VVV-UUU(-V) AutoStrobe 300% Intensity controlled Continuous mode Continuous mode by AIC signal 100% (between 20% and 100%) TRIG signal IN TRIG signal IN Notes: Respect a duty cycle lower than 30% in strobe mode. USER MANUAL-V3.0-EFFI-FLEX-IP69K 4/14 www.effilux.com...
  • Page 5 • ELS-IN-350-5V: Output intensity decreasing between 0-5V / ELS-IN-350-10V: Output intensity decreasing between 0-10V. LED current & maximum duty cycle Part number: Output current (mA) [0-100%] Max duty cycle EFFI-FLEX-IP69K Max duty cycle EFFI-FLEX-IP69K-L2 (standard) 0-350 mA 100% 0-500 mA...
  • Page 6 CABLE LENGTH 10M FLYING LEADS OPTICAL LENGTH +36,7 EFFI-FLEX-IP69K-XXX-YYY-WW-PP OPTICAL LENGTH + 36.7 4 x M5 - 6H 4 x M5 - 6H OPTICAL LENGTH + 47 OPTICAL LENGTH CABLE LENGTH 10M M12-5PINS CONNECTOR OPTICAL LENGTH +36.7 USER MANUAL-V3.0-EFFI-FLEX-IP69K 6/14 www.effilux.com...
  • Page 7 China, to clearly disclose contents of the 6 restricted substances listed below. WARRANTY EFFILUX products come with a warranty of 2 years (one year for radiant quantity), starting from EFFILUX shipping date. Any improper use voids the warranty. Exceptions: UV products (<420nm): 1-year warranty / Chillers: 1-year warranty / Polarizers are excluded from warranty.
  • Page 8 INFORMATIONS GÉNÉRALES Effilux vous remercie de votre achat. Afin d’assurer le bon usage du produit, nous vous invitons à prendre connaissance de cette notice (User manual) avant utilisation et de la conserver pour vos futurs produits. Tout utilisation inapropriée entraine une invalidation de la garantie.
  • Page 9 PART NUMBERING Version STANDARD EFFI-FLEX-IP69K - Longueur Positions des Nombre de LED Vitres Connecteurs d’ondes lentilles 365* TR: Transparent FL2 (Standard): (UV) (20 mm) XXX > 55 LEDs SD: Semi-diffuse IN2 (FOOD): (UV) (60 mm) XXX > 20 LEDs OP: Opaline...
  • Page 10 (*) AIC (Analog Intensity Control) pour la version ELS. • L’EFFI-FLEX-IP69K nécessite une alimentation de 24 V. • La pin de déclenchement PNP doit être connectée soit à un signal de déclenchement pour les modes AutoStrobe et Strobe, soit à un signal continu pour le mode Continu.
  • Page 11 Comment connecter l’EFFI-FLEX-IP69K? Version standard IP69K CONSOMMATION MAXIMALE D’ÉNERGIE EN WATTS +/-5%) - LED blanche - câble de 10m Nombre de LEDs Standard Peak_2s (Autostrobe) ELS-700 ELS-500 ELS-350 Fils nus - 1 entrée Fils nus - 2 entrées Notes : Pour les produits plus volumineux avec l’option ELS, veuillez nous contacter.
  • Page 12 ELS-IN-350-5V : intensité de sortie décroissante entre 0-5V / ELS-IN-350-10V : intensité de sortie décroissante entre 0-10V. Courant de la LED et rapport cyclique maximal Max du rapport cyclique de Numéro de pièce: Courant de sortie (mA) [0-100%] Max du rapport cyclique de l’EFFI-FLEX-IP69K l’EFFI-FLEX-IP69K-L2 (standard) 0-350 mA 100%...
  • Page 13 CABLE LENGTH 10M FLYING LEADS OPTICAL LENGTH +36,7 EFFI-FLEX-IP69K-XXX-YYY-WW-PP OPTICAL LENGTH + 36.7 4 x M5 - 6H 4 x M5 - 6H OPTICAL LENGTH + 47 OPTICAL LENGTH CABLE LENGTH 10M M12-5PINS CONNECTOR OPTICAL LENGTH +36.7 USER MANUAL-V3.0-EFFI-FLEX-IP69K 13/14 www.effilux.com...
  • Page 14 énumérées ci-dessous dans les produits électroniques fabriqués ou importés, et vendus en Chine. GARANTIE Les produits EFFILUX sont garanties 2 ans (1 an pour le niveau d’intensité lumineuse). La garantie démarre à la date d’expédition d’EFFILUX. Tout usage non approprié entraine une invalidtité de la garantie.
