EFFILUX effi-Ring User Manual

Adjustable beam power ring
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Available languages

Available languages

Table of Contents

Please take a while to consider and read this brochure before using your new device.
If you have any doubt, please refer to the datasheet on the website or contact EFFILUX.
User security
Do not look directly or with any optical instrument the light beam
•
Avoid any contact with the LED or with the projection lens
•
IP65 Classification: Do not immerse the device in water or any other liquids. For extended use with water
•
please ensure to use a plastic cap on the unused connector (M8 or M12)
Operating environment: 0 to 40°C - Humidity: 20 to 85RH% (without condensation)
•
High humidity and high temperature could damage the device
•
Do not use the device in an environment with oil fumes and steam
•
Do never try to fix any damages to the product by yourself
•
Make sure you are using a correct power supply before connecting the device
•
The device must be powered by a 24V safety power supply in accordance to local Electrical Safety rules
•
Do not inverse electrical polarity – check the conventions before turning on the power supply
•
Make sure you consider an adapted connector to link the device to the power supply
•
Mini Parc du Verger – Bâtiment E
1 Rue de Terre Neuve
91940 LES ULIS, FRANCE
Adjustable beam power ring
Any improper use voids the warranty
Tel: +33 9 72 38 17 80
Fax: +33 9 72 11 21 69
Email: sales@effilux.fr
USER MANUAL EFFI-RING
Version 2.4.2022
Last update: February 23, 2022
UK Importer: Gardasoft Vision Ltd.
Trinity Court, Buckingway Business Park
Swavesey, Cambrige CB24 4UQ UK
Page 1 / 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the effi-Ring and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EFFILUX effi-Ring

Summary of Contents for EFFILUX effi-Ring

  • Page 1 Last update: February 23, 2022 Please take a while to consider and read this brochure before using your new device. If you have any doubt, please refer to the datasheet on the website or contact EFFILUX. User security Do not look directly or with any optical instrument the light beam •...

  • Page 2: Maintenance

    WUI (000+405+850) (1) For 365nm : There is NO lens and a special UV PMMA window Please note that with the polarizer accessory, the EFFI-Ring is IP50. For IP65 polarized version, choose -POL-IP option. Maintenance Regardless of maintenance, the product must be switch off.
  • Page 3 Last update: February 23, 2022 Electronical consideration CONTACT ARRANGEMENT The EFFI-Ring is supplied with a 24V constant voltage. The TRIG contact needs to be connected. Max Power consumption = 80W (cable length 2m). M12 connector – Smart control (AutoStrobe) Contact...

  • Page 4: Mechanical Consideration

    USER MANUAL EFFI-RING Adjustable beam power ring Version 2.4.2022 Last update: February 23, 2022 Mechanical consideration DIMENSIONS [in mm] FIXING [in mm] Mini Parc du Verger – Bâtiment E Tel: +33 9 72 38 17 80 UK Importer: Gardasoft Vision Ltd.

  • Page 5: Sécurité De L'utilisateur

    Avant l’utilisation merci de prendre connaissance des conseils et des précautions d’emploi contenues dans cette notice. Si vous avez un doute, consultez la datasheet sur le site internet ou contactez EFFILUX. Sécurité de l’utilisateur Ne pas regarder le faisceau lumineux directement ou par le biais de n’importe quel instrument optique •...
  • Page 6 WUI (000+405+850) (1) : A 365nm, pas de lentille, vitre transparente est en PMMA special UV. Merci de noter qu’avec l’accessoire polariseur, l’EFFI-Ring est IP50. Pour une version IP65, choisir l’option -POL-IP (polarisur directement collé sur la vitre transparente). Maintenance Le produit doit être HORS TENSION.
  • Page 7 Version 2.4.2022 MAJ: 23 février 2022 Caractéristiques électroniques BRANCHEMENT Le EFFI-Ring est alimenté avec une source de tension contante 24 V. Le contact TRIG doit être connecté. Connecteur M12 – Contrôle intelligent (AutoStrobe) Consommation électrique max = 80W Version Version RGB Version WUI Détails...

  • Page 8: Caractéristiques Mécaniques

    NOTICE EFFI-RING Annulaire de puissance à faisceau réglable Version 2.4.2022 MAJ: 23 février 2022 Caractéristiques mécaniques DIMENSIONS [en mm] FIXATIONS [en mm] Mini Parc du Verger – Bâtiment E Tel: +33 9 72 38 17 80 UK Importer: Gardasoft Vision Ltd.
